smsng-cv27 VESA adapter (V2)
Assembly
instructions
The VESA adapter is compatible with the following Samsung products
(samsung.com):
C24T550FDR, C27T550FDR, C27T550FDU, C32T550FD, C32T550FDR,
LC24T550FDR, LC24T550FDU, LC27T550FDR, LC327550FDRXEN,
LS27C390EAUXEN, S27C390EAU, S27C392EAN, S32C390EAU, S39C
Essentials, U32J590UQP
With the VESA adapter, you can easily attach your SAMSUNG monitor to a monitor
arm with a VESA hole pattern (75 x 75mm). Use the supplied screws and nuts for
this.
Direct wall mounting is NOT possible, as the VESA adapter already contains metric
threads through which no screws can be inserted for mounting to the wall.
support@3idee.eu | +352 661 26 72 76 | help.3idee.eu
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for 3idee SMSNG-CV27
Summary of Contents for 3idee SMSNG-CV27
- Page 1 VESA hole pattern (75 x 75mm). Use the supplied screws and nuts for this. Direct wall mounting is NOT possible, as the VESA adapter already contains metric threads through which no screws can be inserted for mounting to the wall. support@3idee.eu | +352 661 26 72 76 | help.3idee.eu...
- Page 2 Assembly instructions Important Safeguards Please read this manual carefully and keep it for future reference. If you pass the product on to third parties, this manual should always be included. Ignoring these instructions may result in injuries or damage to people and products, for which we cannot accept any liability.
- Page 3 For the disposal of this product we recommend to contact the responsible local authorities or disposal services. They can provide you with detailed information on available disposal options and recycling centers in your area. 4. Manufacturer Information 3idee S.à r.l. 19 Rue de Bitbourg L-1273 Luxembourg Luxembourg mail: info@3idee.eu...
- Page 4 Assembly instructions Scope of Delivery Accessories 4x M4x14 screw with cross recess (SP2)
- Page 5 Assembly instructions Horizontal / Vertical Alignment Please note: Not all VESA adapters and monitors are designed for vertical (upright) orientation. This limitation is often due to the specific geometry of the adapter or monitor. Do not ignore this information, as the load limit of the adapter can quickly be exceeded if not installed properly. We are continuously working on developing monitors and adapters that are also suitable for vertical orientation.
- Page 6 Assembly instructions Video assembly instructions...
- Page 7 Remove the base of your Samsung Curved monitor. We also recommend that you remove the round cover on the back of the monitor before you start mounting the VESA adapter and reattach it before you mount the 3idee VESA adapter. Step 2 Now attach the 3idee VESA adapter to your Samsung monitor as shown.
- Page 8 Assembly instructions ATTENTION: Make sure you use the right screws! (Figure 3) Step 5 Now please check if the monitor is correctly screwed to the monitor arm. This should look something like the picture. (Figure 4) There is a little space at the marked position. This is correct. Figure 4...
