Advantech TPC-310W User Manual

Advantech TPC-310W User Manual

10.1" touch panel computer
Hide thumbs

Advertisement

Quick Links

Download this manual
User Manual
TPC-310W
10.1" Touch Panel Computer
製造商: 研華股份有限公司
地址:
台北市內湖區陽光街365巷33號
電話:
02-27927818

Advertisement

loading
Need help?

Need help?

Do you have a question about the TPC-310W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech TPC-310W

Summary of Contents for Advantech TPC-310W

  • Page 1 User Manual TPC-310W 10.1" Touch Panel Computer 製造商: 研華股份有限公司 地址: 台北市內湖區陽光街365巷33號 電話: 02-27927818...
  • Page 2 The documentation and the software included with this product are copyrighted 2023 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.

  • Page 3: Product Warranty (2 Years)

    Product Warranty (2 years) Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper installation.

  • Page 4: Technical Support And Assistance

    此為甲類資訊技術設備，於居住環境中使用時，可能會造成射頻干擾，在此種情況 下，使用者會被要求採取某些適當的對策。 Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service cen- ter for technical support if you need additional assistance. Please have the following information ready before you call: –...

  • Page 5: Safety Instructions

    22. This product is intended to be supplied by a UL listed (Certificate) power supply with a mating connector, output rated 24Vdc, 2.5A, Tma 60 degree C minimum and alti- tude 2000m. If need further assistance, please contact manufacture or UL File owner or brand owner for additional information. TPC-310W User Manual...
  • Page 6 Don't touch any components on the CPU card or other cards while the PC is on. ◼ Disconnect power before making any configuration changes. The sudden rush of power as you connect a jumper or install a card may damage sensitive electronic components. TPC-310W User Manual...

  • Page 7: Table Of Contents

    Figure 2.8 Cabinet Installation 2.4.2 System Wiring ................ 10 System configuration ................11 2.5.1 Rear Bracket Removal ............11 2.5.2 AT/ATX Jumper Setting (PSON1) .......... 12 Table 2.1: AT/ATX Function Chapter 3 BIOS Setup ........13 BIOS Setup .................... 14 TPC-310W User Manual...
  • Page 8 COM2 RS-232/422/485 Connector (COM2) ......40 Table A.12: COM2 RS-232/422/485 Connector (COM2) A.3.7 Power Input Connector (DCIN1) ..........40 Table A.13: Power Input Connector (DCIN1) A.3.8 M.2 E-Key Connector (M2E1) ..........40 Table A.14: M.2 E-Key Connector (M2E1) viii TPC-310W User Manual...
  • Page 9 A.3.9 M.2 M-Key Connector (M2_M1) ..........42 Table A.15: M.2 M-Key Connector (M2_M1) TPC-310W User Manual...

  • Page 11: General Information

    Chapter General Information TPC-310W User Manual...

  • Page 12: Introduction

    Introduction The TPC-310W Elkhart Lake series touch panel computer is a human machine interface (HMI) equipped with an Intel Atom x6425E quad core processor. ◼ Industrial-grade 10.1" WXGA TFT LCD with 50K lifetime and LED backlight Intel® Elkhart Lake (EHL) Atom™ x6425E 2.00 GHz, quad core processor ◼...

  • Page 13: Lcd Panel

    Power Consumption: 19.2 W (typical) 1.2.9 External I/O The arrangement of I/O ports is shown below. A. Power receptor E. RS-232/422/485 (COM 2) B. USB 2.0 F. LAN (10/100/1000) C. USB 3.0 G. Line Out D. RS-232 (COM 1) TPC-310W User Manual...

  • Page 14: Dimensions And Cutout

    Dimensions and Cutout ◼ Dimensions (W x H x D): 260.5 x 179.1 x 50mm (10.25 x 7.05 x 1.96 inch) ◼ Cutout Dimensions: 251.1 x 169.7 mm (9.88 x 6.68 inch) Corner=R5mm (±0.5mm) TPC-310W User Manual...

  • Page 15: System Setup

    Chapter System Setup TPC-310W User Manual...

  • Page 16: Transport And Unpacking

    12 hours must be allowed to make sure the TPC is com- pletely dry before the TPC is switched on. 2.1.2 Unpacking and Setup Follow these steps to setup the TPC-310W device: Unbox the TPC-310W device. Adjust the power mode if necessary (default: AT mode), refer to Section 2.5 for details.
  • Page 17 MC420, MC421 (1C) 16-26 B, C 2(105), 4* Figure 2.2 Power Connector Power on the system. The power LED turns to blue. LED Indicator: Off - “dark” ON - “blue” Standby - “orange” Figure 2.3 Power LED Calibrate the touchscreen. TPC-310W User Manual...

  • Page 18: Panel Mount

    Panel Mount Before installing the TPC-310W panel computer into the panel opening, ensure that the adhesive waterproof gasket on the front bezel is correctly positioned. Install the TPC into the panel opening, ensuring adequate air circulation with a required clearance on all sides. Refer to the diagram for the mini- mum clearance (100mm), air inlet and outlet directions (blue arrows), and a suggested mounting panel thickness of less than 6mm (0.236").

  • Page 19: Vesa Mount

    Figure 2.6 Panel Mounting – Fixing VESA Mount The rear cover of the TPC-310W includes four VESA mounting (75 x 75 mm) holes. Install the VESA mounting kit using 4 M4x10L screws. Ensure proper mounting equipment is used to prevent the risk of injury.

  • Page 20: Cabinet Installation And Earth Grounding Setup

    Cabinet Installation and Earth Grounding Setup Follow these steps to set up the TPC-310W system, ensuring that the Ground pin of the TPC-310W system is properly connected to the earth ground. This connec- tion is crucial for optimizing the performance of the TPC-310W system, including enhanced EMI immunity, ESD immunity, surge immunity, and system isolation.

  • Page 21: System Configuration

    System configuration TPC-310W is a compact touch panel featuring IIoT functions designed for indus- trial applications. While the initial system setup is performed by the dealer or sys- tem integrator before delivery, users may require access to adjust configuration such as interfaces or boot modes. Before powering on, open the rear bracket and ensure the correct power mode is selected.

  • Page 22: At/Atx Jumper Setting (Pson1)

    2.5.2 AT/ATX Jumper Setting (PSON1) This jumper on the TPC-310W motherboard, as indicated below, allows for the adjustment of the power mode Table 2.1: AT/ATX Function Description This jumper is used to select Power ON mode Default (1-2) (2-3) (1-2)

  • Page 23: Bios Setup

    Chapter BIOS Setup TPC-310W User Manual...

  • Page 24: Bios Setup

    BIOS supports your CPU. If there is no num- ber assigned to the patch code, contact an Advantech application engineer to obtain an up-to-date patch code file. This will ensure that the CPU status is valid.

  • Page 25: Main Setup

    System Date using the <Arrow> keys. Enter new values through the key- board. Press the <Tab> key or the <Arrow> keys to move between fields. The date must be entered in MM/DD/YY format. The time must be entered in HH:MM:SS format. TPC-310W User Manual...

  • Page 26: Advanced Bios Features Setup

    Advanced BIOS Setup option by highlighting it using the <Arrow> keys. All Advanced BIOS Setup options are described in this section. The Ad- vanced BIOS Setup screen is shown below. The sub menus are described on the following pages. TPC-310W User Manual...
  • Page 27 To turn on/off prefetching of adjacent cache lines ◼ Intel (VMX) Virtualization Technology When enabled, a VMX can utilize the additional hardware capabilities pro- vided by Vanderpool Technology ◼ Active Processor Cores Number of cores to enable in each processor package TPC-310W User Manual...
  • Page 28 This item allows more than two frequency ranges to be supported. ◼ Intel(R) Speed Shift Technology This item allows users to enable/disable Intel® Speed Shift Technology sup- port. Enabling it will expose the CPPC v2 interface to allow for hardware controlled Pstates. TPC-310W User Manual...
  • Page 29 CPU to go to C states when not 100% utilized. 3.2.2.3 PCH-FW Configuration ◼ ME State When this item is disabled, ME will be put into ME Temporarily Disabled Mode. ◼ Firmware Update Configuration This item allows users to configure the management engine technology pa- rameters. TPC-310W User Manual...
  • Page 30 This item allows users to enable/disable endorsement hierarchy. ◼ TPM2.0 UEFI Spec Version This item allows users to select the TCG2 spec version supported. TCG_1_2: The compatible mode for Win8/10. TCG_2: Supports new TCG2 protocol and event formats for Win10 or later. TPC-310W User Manual...
  • Page 31 This item allows users to enable or disable System ability to hibernate (OS/S4 sleep state). This option may be not effective with some OS. ACPI Sleep State ◼ This item allows users to select the ACPI sleep state. The system will enter when the SUSPEND button is pressed. TPC-310W User Manual...
  • Page 32 3.2.2.6 NCT61260 Super I/O Configuration ◼ Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA). ◼ Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB). TPC-310W User Manual...
  • Page 33 3.2.2.7 NCT61260 Hardware Monitor TPC-310W User Manual...
  • Page 34 This item allows users to Set the maximum time the device will take before reporting itself to the Host Controller. The Auto option uses the default value, which is 100 ms for a Root port. For a Hub port, the delay time is ob- tained from the Hub descriptor. TPC-310W User Manual...
  • Page 35 3.2.2.9 Network Stack Configuration ◼ Network Stack This item allows users to enable or disable the UEFI network stack. TPC-310W User Manual...
  • Page 36 3.2.2.10 NVMe Configuration TPC-310W User Manual...

  • Page 37: Chipset Configuration

    System Agent (SA) Configuration ◼ Memory Configuration This item allows users to view the memory parameters. ◼ Graphics Configuration This item allows users to set graphics configuration parameters ◼ VT-d This item allows users to enable or disable VT-d capability TPC-310W User Manual...
  • Page 38 This item allows users to enable or disable the PCIe device to wake up the system from S3/S4/S5 state. ErP Function ◼ When this option is disabled, the wake on function can be selected. ◼ PinCntrl Driver GPIO Scheme This item allows users to enable or disable PinCntrl Driver GPIO Scheme. TPC-310W User Manual...

  • Page 39: Security

    3.2.4 Security Administrator Password ◼ Set Administrator Password ◼ Secure Boot This item allows users to access a submenu to configure secure boot set- tings. TPC-310W User Manual...

  • Page 40: Boot

    This item allows users to set the number of seconds to wait for setup activa- tion key. 65535 (oxFFFF) means indefinite waiting. ◼ Bootup NumLock State This item allows users to select the keyboard NumLock state. Quiet Boot ◼ This item allows users to enable/disable quiet boot option. TPC-310W User Manual...

  • Page 41: Save & Exit

    This item allows you to restore/load default values for all the options. ◼ Save as User Defaults This item allows you to save the changes done so far as user defaults. ◼ Restore User Defaults This item allows you to restore the user defaults to all the options. TPC-310W User Manual...
  • Page 42 TPC-310W User Manual...

  • Page 43: Appendix A Connectors

    Appendix Connectors TPC-310W User Manual...

  • Page 44: Jumper And Connector Location

    USB2H2 Internal USB connector 2 LED1 LED indicator connector BAT1 RTC battery connector COM1 COM1 RS-232 connector COM2 COM2 RS-232/422/485 connector USB3C1 USB 3.0 connector USB2C1 USB 2.0 connector DCIN1 Power input connector LAN12 LAN RJ45 connectors TPC-310W User Manual...

  • Page 45: Jumper Settings And Descriptions

    (1-2) CLR RTC Register (2-3) Normal, default (3-4) Clear CMOS A.2.2 COM2 Signal Select (SW2) Table A.3: COM2 Signal Select Description This switch is used to select COM2 signal Default (1-2) OFF COM2_422_485_TX (1) OFF COM2_422_RX (2) OFF TPC-310W User Manual...

  • Page 46: Lcd Resolution Select (Sw1)

    Table A.5: COM1 Pin 9 Power Select Description This jumper is used to select COM1 pin 9 power Default (1-2) (1-2) COM1 RI (Default) (2-3) COM1 Pin9 5V (4-5) COM1 Pin9 12V A.2.5 LCD Power Select (JP6) TPC-310W User Manual...

  • Page 47: Connector Pin Definition

    Table A.6: LCD Power Select Description This jumper is used to select LCD power Default (1-2) (1-2) 5V (Default) (2-3) 3.3V (1-2) 5V (2-3) 3.3V Connector Pin Definition A.3.1 Power Button Connector (BTN1) Table A.7:Power Button Connector (BTN1) Signal ATX_PWRBTN# TPC-310W User Manual...

  • Page 48: Internal Usb Connector (Usb2H1 & Usb2H2)

    A.3.2 Internal USB Connector (USB2H1 & USB2H2) Table A.8: Internal USB Connector (USB2H1 & USB2H2) Signal A.3.3 LED Indicator Connector (LED1) Table A.9: LED Indicator Connector (LED1) Signal Orange light Blue light TPC-310W User Manual...

  • Page 49: Rtc Battery Connector (Bat1)

    A.3.4 RTC Battery Connector (BAT1) Table A.10: RTC Battery Connector (BAT1) Signal +VBAT A.3.5 COM1 RS-232 Connector (COM1) Table A.11: Internal COM Port Connector (COM1) Signal DCD# DTR# RTS# CTS# TPC-310W User Manual...

  • Page 50: Com2 Rs-232/422/485 Connector (Com2)

    Data- Data+ A.3.7 Power Input Connector (DCIN1) Table A.13: Power Input Connector (DCIN1) Signal Power In V+ Power In V- (GND) GND_EARTH A.3.8 M.2 E-Key Connector (M2E1) Table A.14: M.2 E-Key Connector (M2E1) Signal Signal 3.3V 3.3V TPC-310W User Manual...
  • Page 51 W_DISABLE1# W_DISABLE2# PEWAKE0# PERST0# CLKREQ0# SUSCLK REFCLKn REFCLKp PERn0 PERp0 PETn0 PETp0 3.3V USB_D- 3.3V USB_D+ TPC-310W User Manual...
  • Page 52 Table A.15: M.2 M-Key Connector (M2_M1) Signal Signal 3.3V 3.3V 3.3V SUSCLK PEDET(NC-PCIe/GND-SATA) PEWAKE0# REFCLKp CLKREQ0# REFCLKn PERST0# PETp0 / SATA-A+ PETn0 / SATA-A- PERp0 / SATA-B- PERn0 / SATA-B+ DEVSLP PETp1 PETn1 PERp1 PERn1 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V TPC-310W User Manual...
  • Page 53 TPC-310W User Manual...
