- Page 1 IMILAB C22 Home Security Camera User Manual Scan the QR code for the tutorial on how to use the camera. Read this manual carefully before use, and retain it for future reference.
-
Page 2: Product Introduction
Product Introduction • Package List IMILAB C22 Power adapter (optional) Charging cable Wall mounting pack User manual • Product Appearance Indicator light Lens Speaker MicroSD card Reset slot (Can be RESET revealed by pushing the Micro-USB lens upward) Charging port... -
Page 3: Connect To Power Source
Connect to Power Source • Power On Insert the power supply cable into the camera's power supply port. • Indicator Light Steady blue on: Connected/device status is normal Flashing blue: Network error Flashing orange rapidly: Waiting for connection Flashing orange slowly: System upgrade in progress... - Page 4 Smart home room home Sh Smart home room home Sh Scan 28° 28° Manual controls room room Open Open IMILAB C30 Dual Home Security Camera IMILAB C30 Dual Home Security Camera Automation Mi Home Smart Products Store Profile Mi Home Smart...
-
Page 5: Installing The Device
Note: Restoring the factory settings will not delete the contents of the MicroSD card. Installing the Device • Installing a MicroSD Card Ensure that the camera is disconnected from the power supply. Adjust the camera lens upward until the MicroSD card slot is revealed. Insert the MicroSD card into the card slot in the direction as illustrated. - Page 6 • Installing the Device The device can be placed on a number of horizontal surfaces, such as a writing desk, dining room table, and co ee table. It can also be mounted on the wall. Wall mounting： 1. Drill two holes on the wall by using the base of the camera as a template. It is recommended that you mark the locations of the hole with a pencil before drilling.
-
Page 7: Basic Parameters
Basic Parameters Product name: IMILAB C22 Power input: 5 V Model: CMSXJ60A Dimensions: 108 mm x 76 mm x 76 mm Net weight: 239 g Operating temperature: -10 °C ~ 40 °C Resolution: 2880 x 1620 Video code: H.265 Wireless Connectivity: Wi-Fi IEEE 802.11 b/g/n/ax 2.4 GHz Storage: MicroSD card (up to 256GB) Frequency Range: 2400–2483.5 MHz... -
Page 8: Fcc Statement
FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. -
Page 9: Weee Information
The full Declaration of Conformity can be found at https://www.imilabglobal.com/pages/psti-declaration. For any issues, please contact us at help@imilab.com or submit the Issue Feedback Form via the link above. - Page 10 Manufacturer: Shanghai Imilab Technology Co., Ltd. Address: Room 001A, Floor 11, Block 1, No. 588 Zixing Road, Minhang District, Shanghai, China For further information, please go to www.imilabglobal.com. Support: help@imilab.com Warranty: https://www.imilabglobal.com/pages/warranty...
