SAJ eManager-C1 Pro User Manual page 8

The eManager-C1 Pro provides the following functions:
⚫ All-in-one compact design
⚫ Smart and flexible support
- Support for RS485, Ethernet, 4G, and Bluetooth communication
- Support for data collection/transmission/storage for energy meters, conditioners, fire protection
devices, sensors, and other equipment
- Support for communication and monitoring on a maximum of 10 inverters
⚫ Convenient operation and maintenance
- Batch parameter settings and firmware updates for inverters
- 24-hour local and remote monitoring
- Remote operation: PV-plant maintenance on Web
Easy operation
⚫
- All-in-one compact design for easy installation
- IP65 protection box enclosure for easy maintenance
2.3. Dimension
Figure 3. 2
Dimension
7
2.4. Port Introduction
Figure 3. 3
Ports
Silkscreen
LAN
POWER AC_IN
COM 0
COM 1
COM 2
Table 3. 1
Ports
2.5. Datasheet
General parameters
Application
Communication
Data collection interval (Min)
Firmware update
Data access
Electrical parameters
Input AC voltage
Input DC voltage
eManager-C1 Pro
Description
Ethernet port (waterproof)
AC power cable port (waterproof)
Reserved Ethernet/antenna port (waterproof)
DC power cable port
Reserved
Commercial project monitoring
Bluetooth, 4G, Ethernet, or RS485
1 – 30 (optional); 5 (standard)
Ethernet, USB, or remote update
App, Web, or local Web
176 – 300 V AC
9 – 36 V
8
