7.
OPERATIONS BY LAN
(NEAR END)
55
On this local Web, the real-time device data will be updated once two seconds.
7.1. Connecting the EMS to the Computer
Procedure
1. Prepare an RJ45 cable.
2. Open the EMS box.
3. Connect one end of the cable to either of the following ports in the EMS:
⚫
Ethernet port on the switch. To locate the switch, refer to Section 2.6 "Internal Structure".
⚫
NET2 port on the eManager-C1-1 module. To locate the NET2 port, see Section 2.7.1 "Front view".
4. Connect the other end of the cable to your computer.
---End
7.2. Logging In to the Local Web
1.
Open your computer, set the IP address, subnet mask, and default gateway.
a.
In Settings, select Network & internet on the left navigation pane and then select Advanced
network settings on the right pane.
eManager-C1 Pro
56
