- Page 1 NCMS321M04 QUICK START GUIDE 4D MULTISENSOR NETWORK CAMERA...
-
Page 2: Installation
1. Installation Wall Wall Mount Wall Mounting template Bracket Step 1: Stick the mounting template to the wall, drill 4 screw holes and 1 tail cable hole. Step 3: Align the 4 anchors with the holes of the bracket, install the gasket and the spring washer, then lock all 4 nuts. - Page 3 Installation Method Wall Included Wall Mount Bracket AVM-DUAL-WMT-L1 AVM-DUAL-WMT-L1 Rivet 4D multisensor camera Accessories Step 5: After the tail cable of the camera passes through the bracket, align the notch of the adapter cover Included with the rivet position of the bracket and insert it into the bracket hole. AVM-DUAL-WMT-L1 Wall Bracket...
- Page 4 2. Camera Connection Diagram 3. Install the App • Search for “AVY Mobile One” in App Store or Google Play. • Scan the QR code below to download the App. Attention : There are 2 connection modes. 1. For non-PoE connection. please connect the camera to a PoE device then connect it to the NVR or the router. 2.
- Page 5 4. Camera Settings 4. Camera Settings If add the device successfully, you will see the following interface. Open “AVY Mobile One”, you will see the following interface to add the cameras. Please refer to “Help” section for more detailed instruction. Information can be set manually by selecting Manual Add.
- Page 6 3. Launch the web browser and enter the device’s IP address. Provide the username and password in the 1. Log in to www.al8.co and click “Device Search for Windows” to download the “AVYCON Device Tool” software. interface below to access the device.
- Page 7 6. MAC OS 1. Open your router web interface and log in. 2. Find the “Attached device” or “Connected device” menu. Find the device’s IP address according to its MAC address. The Mac address is labeled on the device. 3. Input the device’s IP address in Safari, log in with your username & password. 4.
- Page 8 Copyright @ AVYCON. All rights reserved. Specifications and pricing are subject to change without notice. phone: 949-752-7606 email: info@avycon.com social: @avycon_aivo website: avycon.com...
