- Page 1 NDAA SERIES QUICK START GUIDE IP CAMERAS...
-
Page 2: Table Of Contents
TABLE OF CONTENT 1. INTRODUCTION........................2. SAFETY INSTRUCTIONS....................3. INSTALLATION........................3.1 Installation of Bullet Cameras..................3.2 Installation of Mini Dome Cameras................3.3 Installation of Vandal-Proof Dome Cameras..............3.4 Installation of Bullet Cameras..................14 4. CONNECTING CABLES...................... 5. I/O ALARM WIRING DIAGRAM..................6. -
Page 3: Introduction
(not due to defect of the product) and impair useful life of the camera. 6) Avoid use of the equipment in any environment other than suggest in this manual. 7) Prevent water or any other liquid from flowing into the equipment. IP CAMERAS | NDAA SERIES... - Page 4 , or similar components which have the same specification. Change any part in the device without authorization is not permit. Operating Environment Power Supply DC12V±10% Temperature -30°C~60°C Humidity 10%~95% Altitude -60m~3000m Atmosphere 86kpa~106kpa IP CAMERAS | NDAA SERIES...
-
Page 5: Installation
3. Installation Installation of Bullet Cameras a. Ceiling Mounting Expansion Bolt Locking Screw IP CAMERAS | NDAA SERIES... - Page 6 Insert three expansion bolts in place into the ceiling and fix the equipment with three locking screws. Completion of Installation b. Wall Mounting Locking Screw Expansion Bolt IP CAMERAS | NDAA SERIES...
-
Page 7: Installation Of Mini Dome Cameras
Insert three expansion bolts in place into the wall and fix the equipment with three locking screws. Completion of Installation Installation of Mini Dome Cameras Ceiling Mounting IP CAMERAS | NDAA SERIES... - Page 8 Setup of Sticker Paste the sticker in place at the proper position as selected. Mini Dome Camera IP CAMERAS | NDAA SERIES...
- Page 9 Collar Remove the collar off the camera by rotating it down Expansion Bolt Locking Screw IP CAMERAS | NDAA SERIES...
- Page 10 Fix the pedestal by drilling locking holes around the sticker and inserting three expansion bolts into the holes and fastening it with three locking screws. Adjust it to an appropriate angle. Mount the collar back by rotating it up IP CAMERAS | NDAA SERIES...
-
Page 11: Installation Of Vandal-Proof Dome Cameras
Completion of Installation Installation of Vandal-Proof Dome Cameras Ceiling Mounting Setup of Sticker Paste the sticker in place at the proper position as selected. IP CAMERAS | NDAA SERIES... - Page 12 Locking Screw Remove the front component by loosening the three locking screws with a screwdriver. Expansion Bolt Locking Screw IP CAMERAS | NDAA SERIES...
- Page 13 Fix the pedestal by drilling locking holes around the sticker and inserting four expansion bolts into the holes and fastening it with four locking screws. Adjust it to an appropriate angle. Locking Screw IP CAMERAS | NDAA SERIES...
- Page 14 Fix the front component on the pedestal by tightening the three locking screws. Completion of Installation IP CAMERAS | NDAA SERIES...
-
Page 15: Installation Of Bullet Cameras
Installation of Indoor Dome Cameras Ceiling Mounting Setup of Sticker Paste the sticker in place at the proper position as selected. IP CAMERAS | NDAA SERIES... - Page 16 Expansion Bolt Locking Screw Fix the base by drilling locking holes around the sticker and inserting three expansion bolts into the holes and fastening it with three locking screws. Adjust it to an appropriate angle. IP CAMERAS | NDAA SERIES...
- Page 17 After angle adjustment, mount the shield back by rotating the collar up. Completion of Installation IP CAMERAS | NDAA SERIES...
-
Page 18: Connecting Cables
4. Connecting Cables Client Adaptable Cable Waterproof structure, which must be installed and tightened! Steps Thread cable Make crystal head BNC Output Reset Button ALARM OUT ALARM IN Audio INPUT Audio OUTPUT Connection for Multiple Functions IP CAMERAS | NDAA SERIES... -
Page 19: I/O Alarm Wiring Diagram
Standard models only have basic functions. Full function models have all connectors. CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. I/O ALARM WIRING DIAGRAM IP CAMERAS | NDAA SERIES... -
Page 20: Login System
Windows 2003/Windows XP/Windows 2000 (only 32-bit) Display: 1024 × 768 or higher resolution IE: IE 6.0 or higher version 2) Network Connection Configuration The default static IP address for the equipment is: 192.168.1.168 Procedure for Login Web interface: IP CAMERAS | NDAA SERIES... - Page 21 Step 1: Run to Control Panel > Network Connection and Sharing > Local Connection in Windows 7 system, and set your PC in the same network segment where the camera is located, as shown below. IP CAMERAS | NDAA SERIES...
- Page 22 IP CAMERAS | NDAA SERIES...
- Page 23 NOTE: : In case that access to IE by the equipment may fail due to IP address conflict, the IP address has to be changed. Changing procedure: Select the IP address to change > put down the correct parameters > enter the password > click Change. IP CAMERAS | NDAA SERIES...
- Page 24 In a pop-up plug-in installation dialog box, choose an installation option to perform the installation process. IPC Plugin Step 5: Open IE and enter the IP address of the equipment in the address bar and press ENTER. IP CAMERAS | NDAA SERIES...
- Page 25 Step 6: Enter the user name and password (the default user name and password are both "admin"), and click "Login" to log in. Step 7: After successful login, The default preview page will be displayed. IP CAMERAS | NDAA SERIES...
- Page 26 Copyright © AVYCON. All rights reserved. Specifications and pricing are subject to change without notice. phone: 949-752-7606 email: info@avycon.com social: @avycon_aivo website: avycon.com...
