  • Page 1 008-4924 00803650 *00803650* Vitoo User Guide Original User Guide ENGLISH...

  • Page 2: Table Of Contents

    Roxell – 008 – 4924 Vitoo – Table of contents TABLE OF CONTENTS Disclaimer General information Instructions for the user ........................I-1 General safety rules ............................... I-1 General safety rules – winching systems ........................I-2 General introduction ..............................I-3 Layout of the circuit feeding system ..........................I-4 Directions for operating the system ..........................

  • Page 3: Disclaimer

    The original, authoritative version of this manual is the English version produced by ROXELL BV Subsequent changes to any manual made by any third party have not been reviewed nor authenticated by Roxell. Such changes may include, but are not limited to, translation into languages other than English, and additions to or deletions from the original content.

  • Page 4: General Information

    Roxell’s most current use and maintenance manuals; use of cleansing agents and disinfectants in violation with the instructions received from the suppliers;...
  • Page 5 In the European Union If you have used the product for commercial purposes and you want to dispose of it, contact Roxell, who will give you information about the return of the product. It is possible that you will have to pay a disposal charge for the return and recycling.
  • Page 6 Vitoo – General information Roxell – 008 – 4924 LOTOTO = Lock Out - Tag Out - Try Out Before you begin: Everyone needs his own lock and tag (label), which can’t be removed by other persons. Inform all the persons who are influenced by the procedure.
  • Page 7 Roxell – 008 – 4924 Vitoo – General information Information about the residual risks - used safety signs There are three levels of danger, which you can recognize from the following signal words: • DANGER • WARNING CAUTION • The nature and source of the imminent danger and possible consequences of not obeying warnings is stated here!

  • Page 9: Instructions For The User

    Roxell – 008 – 4924 Vitoo – Instructions for the user Instructions for the user General safety rules KiXoo/Vitoo/Boozzter nr: 008.../008.../002... Automatic pan feeding system for rearing and production of broiler breeders Winching system Winching system for feeding and drinking lines DANGER: Carefully read the instructions before you use the system.

  • Page 10: General Safety Rules - Winching Systems

    • Only adults may operate the winch. • Only use the winch to suspend Roxell feeding, heating or nesting lines/circuits. • Always check the condition of the winch and the cable before use. Immediately replace a ravelled, kinked or damaged cable.

  • Page 11: General Introduction

    This ensures uniformity of the flock. With the Vitoo feeder pan, it is possible to feed automatically from day one using a flooding system incorporated in the feeder pan.

  • Page 12: Layout Of The Circuit Feeding System

    Vitoo – Instructions for the user Roxell – 008 – 4924 Layout of the circuit feeding system General To optimise the use of the circuit feeding system, carefully plan and lay out the house. For example, it is crucial to determine the placement of the feed bins and the entry points for the feed into the house.
  • Page 13 Roxell – 008 – 4924 Vitoo – Instructions for the user Important measures IMPORTANT: These measures serve as guidelines. Consult the technical adviser at the hatchery for further assistance. Determine the location of the circuit, considering: Dimensions bird/feeder pan 44 cm...
  • Page 14 Vitoo – Instructions for the user Roxell – 008 – 4924 Type of feed supply There are 2 ways of supplying feed to the system: • From hoppers installed on the circuit • Directly from the feed bin outside the house using feed intake boots NOTE: The type of feed supply determines the type and capacity of the transport system.

  • Page 15: Directions For Operating The System

    Roxell – 008 – 4924 Vitoo – Instructions for the user Directions for operating the system First use of the system NOTE: At the beginning, the oil layer on the new auger and tubes slows down the feed transport. After some runs, the feed transport reaches its optimal operating speed.
  • Page 16 Vitoo – Instructions for the user Roxell – 008 – 4924 Pan settings Adjuster ring The adjuster ring: • adjusts the feed level in the inner pan. • controls the eating speed of the birds. • allows proportional distribution of the feed to all feeder pans.
  • Page 17 Roxell – 008 – 4924 Vitoo – Instructions for the user Option: Adjuster ring regulator – 09701806 Static pan content Reference Description Feeder pan content level 3 Feeder pan content level 14 The feed amount per feeder pan follows the eating speed of the birds. If there are more birds at one feeder pan, more feed will fall inside the feeder pan during the whole meal, as the feeder pan will be refilled faster.
  • Page 18 Vitoo – Instructions for the user Roxell – 008 – 4924 Height of the system IMPORTANT: • Adjust the circuit's height to prevent feed waste and ensure a comfortable eating position for the breeders, taking into consideration the birds' development.

  • Page 19: Control Unit

    Roxell – 008 – 4924 Vitoo – Instructions for the user Control unit The tubes of the circuit are filled with feed, ensuring that all feeder pans are filled simultaneously. The control unit ensures there is feed in all feeder pans and keeps all tubes consistently full.
  • Page 20 Vitoo – Instructions for the user Roxell – 008 – 4924 Frontal filling Reference Description Control unit Feed direction Functionality of the control unit The sensor in the control unit is activated when it detects no feed. The feeding system starts.

  • Page 21: Operation Of The System

    Roxell – 008 – 4924 Vitoo – Instructions for the user If everything is OK, the birds will automatically spread evenly throughout the house. ATTENTION: Ensure that enough birds are eating from the control unit. ATTENTION: Ensure that the control unit hangs at the end of a circuit and that the connection cable of the sensor is long enough.

  • Page 22: Cleaning And Maintenance

    Vitoo – Instructions for the user Roxell – 008 – 4924 Fill the feeder pans by allowing the circuit to stop automatically using its sensor (control unit). Check the good operation of the sensor. The birds now have enough feed for the first day(s).
  • Page 23 Roxell – 008 – 4924 Vitoo – Instructions for the user...
  • Page 24 Vitoo – Instructions for the user Roxell – 008 – 4924 Push the feeder pan down with both thumbs until it hinges out of the grille. Clean the feeder pans one after another with a high-pressure cleaner (maximum 100 bar).
  • Page 25 Roxell – 008 – 4924 Vitoo – Instructions for the user • Rinse carefully with pure water to remove all residues after cleaning and disinfecting. • Rinse carefully between the use of different cleaning and disinfecting products. • Remove all residual water from the feeder pans by allowing the pans to drip after cleaning and disinfecting, and ensure they are dry before closing.

  • Page 26: Door Components On Ccp

    Vitoo – Instructions for the user Roxell – 008 – 4924 Door components on CCP CCP without iQon 3x400V 00813404-Copy HAL1 HAL2 00 00 801 mm SFA1 SFA2 I:on II:off 800 mm Reference Description Automatic start HAL1 Attention: Switches not in automatic...
  • Page 27 Roxell – 008 – 4924 Vitoo – Instructions for the user CCP with iQon 3x400V+N 04913310-Copy USB1 HAL1 801 mm SRES1 SFA2 SFA3 800 mm Reference Description Touchscreen USB1 USB port HAL1 Attention: Motor alarm SRES1 Attention: Safety alarm + release system...

  • Page 28: Example: House Layout

    Vitoo – Instructions for the user Roxell – 008 – 4924 Example: House layout NOTE: For illustration purposes only. MFA1 M1.1 M1.2 M2.1 SCRX1 M2.2 MFA3 Reference Description Main bin MFA1 FA main bin to day bin Day bin Day bin weigher Load cells M1.1...

  • Page 29: Maintenance Instructions

    Roxell – 008 – 4924 Vitoo – Instructions for the user Maintenance instructions DANGER: Turn off the main switch first. Ensure you use personal protective equipment (protective gloves, anti-slip safety shoes, safety glasses, dust mask...). ATTENTION: Actions on a grey background must be done by a technically trained person.

  • Page 30: Maintenance Instructions - Daily Winching

    Vitoo – Instructions for the user Roxell – 008 – 4924 Maintenance instructions – daily winching DANGER: Turn off the main switch first. Ensure you use personal protective equipment (protective gloves, anti-slip safety shoes, safety glasses, dust mask...). • Remove all dirt and dust after each flock or at least every 6 months.

  • Page 31: Troubleshooting Guide

    Roxell – 008 – 4924 Vitoo – Instructions for the user Troubleshooting guide DANGER: Turn off the main switch first. Ensure you use personal protective equipment (protective gloves, anti-slip safety shoes, safety glasses, dust mask...). ATTENTION: During automatic operation, none of the yellow lamps should be illuminated.
  • Page 32 Vitoo – Instructions for the user Roxell – 008 – 4924 Issue Yellow lamp Possible cause Corrective action DANGER: If the auger of the circuit is blocked due to one of the above problems, it may be under spring tension, so exercise extreme caution and follow the instructions provided below on this section.

  • Page 33: Sensor List

    Yellow • Minimum detection: drop tube for daily winch • Maximum detection: Discaflex 14919361 Blue • Control unit: Vitoo In line, KiXoo In line • Maximum detection: feed bin in overhead setup 14919377 Gray • Control unit: Boozzter 14919385 White •...

  • Page 34: Electrical Connection

    Clockwise: to increase the sensitivity • Anticlockwise: to reduce the sensitivity ATTENTION: Always rotate slowly. Preset by Roxell, slight tuning may be needed (see Sensor location (page I-27). Visualisation of the sensitivity and sensor status (from left to right): •...

  • Page 35: Sensor Location

    Roxell – 008 – 4924 Vitoo – Instructions for the user Sensor location If the sensor is installed on a drop tube, ensure that the sensor is placed on the same side as where the feed arrives (orange) and as far as possible from the feed flow (at least 50 cm from the horizontal tube).
  • Page 36 Vitoo – Instructions for the user Roxell – 008 – 4924 Sensor tuning NOTE: Sensor tuning is factory set. In certain circumstances, manual tuning may be required. Follow the instructions below. In case no feed is present in front of the sensor Ensure that the sensor is properly installed.
  • Page 37 Roxell – 008 – 4924 Vitoo – Instructions for the user In case feed is present in front of the sensor Ensure that the sensor is properly installed. Slowly rotate button B (anticlockwise) until the 5 th or 6 th green LED lights up.
  • Page 38 Vitoo – Instructions for the user Roxell – 008 – 4924 IMPORTANT: Ensure that the sensor is tuned in such a way that the green LEDs light up symmetrically around the status LED while switching between the states "feed present in front of the sensor" (1) and "no feed present in front of the sensor" (2).

  • Page 39: Troubleshooting Guide - Daily Winching

    Roxell – 008 – 4924 Vitoo – Instructions for the user Troubleshooting guide – daily winching DANGER: Turn off the main switch first. Ensure you use personal protective equipment (protective gloves, anti-slip safety shoes, safety glasses, dust mask...). DANGER: Ensure that you first remove any element that may obstruct the safe operation of the system.

  • Page 40: House Chart

    Roxell-008-4924 Vitoo- Instructions for the user House Chart Rearing Age of birds 0–2 weeks 2–3 weeks 3–6 weeks 6–21 weeks Pan height 1 cm Feeding stage Ad libitum Moderate restriction Severe restriction Position of feed Open Closed windows Operation control unit...
  • Page 41 Roxell-008-4924 Vitoo- Instructions for the user Daily winching of the feeding system light out Cleaning Mating Winching down Winching up Feeding Feeding Waiting time Pan filling Sleeping Eating Mating Activity Description Winching down The feeding system is winched down from mating position to feeding position.

  • Page 42: Declaration Of Incorporation Of Partly Completed Machinery

    Tel: + 32 50 72 91 72 Fax: + 32 50 71 67 21 “This part may only be filled out if all built-in subparts are delivered by Roxell” Verklaart geheel onder eigen verantwoordelijkheid dat het product: EG-verklaring van overeenstemming (Richtlijn 2006/42/EG, Bijlage I.1.A)
  • Page 43 Supply of Machinery (Safety) Regulations 2008 Manufacturer: Roxell BV, Industrielaan 13, 9990 Maldegem “This part may only be filled out if all built-in subparts are delivered by Roxell” Tel: +32 50 72 91 72 Fax: +32 50 71 67 21...

  • Page 44: Ec Declaration Of Conformity

    EG-verklaring van overeenstemming(Richtlijn 2006/42/EG, Bijlage II.1.A) EC-declaration of conformity (Directive 2006/42/EC, Annex II.1.A) Fabrikant/Manufacturer: Roxell BV, Industrielaan 13, 9990 Maldegem Tel: + 32 50 72 91 72 Fax: + 32 50 71 67 21 Verklaart geheel onder eigen verantwoordelijkheid dat het product:...
  • Page 45 UK Declaration of Conformity Supply of Machinery (Safety) Regulations 2008 Manufacturer: Roxell BV, Industrielaan 13, 9990 Maldegem Tel: +32 50 72 91 72 Fax: +32 50 71 67 21 Declares on its own responsibility that the product: Winching system Nr: 00102368 / 00102087 Winching system for feed- and drink lines;...
  • Page 46 Roxell USA Inc. - 720 Industrial Park Road, Anderson MO 64831 (USA) Tel. +1 417 845 6065 - info.usa@roxell.com - www.roxell.com Roxell Malaysia - No. 49, Jalan Permata 2/KS9, Taman Perindustrian Air Hitam, 41200 Klang, Selangor (Malaysia) Tel. +60 3 3123 1767 - info.malaysia@roxell.com - www.roxell.com...
