Schwinn 470 Troubleshooting Manual
Schwinn 470 Troubleshooting Manual

Schwinn 470 Troubleshooting Manual

Having issues adjusting the incline on elliptical

Advertisement

Quick Links

3/12/24, 9:34 AM
Schwinn 470:  I'm having issues adjusting the incline on my elliptical
Follow this troubleshooting guide to help resolve incline issues on your Schwinn 470 Elliptical.
Some common complaints may include:
Can't adjust incline/incline not working
Incline buttons don't work
Incline adjusting erratically

Follow these steps to troubleshoot the issue

Tools you may need:
Phillips head screwdriver
6mm hex/Allen wrench, or the wrench from the hardware
card included with your machine
13mm open-ended wrench
Crank puller (if removing crank arms for troubleshooting)
1.
If the incline could be adjusted previously but is now stuck at max
accompanied by a "hot" smell as the motor is continually trying to raise the incline.
2.
Turn off the power to your elliptical using the power switch at the bottom of your machine. Turn your elliptical back
on. When the console displays the welcome screen, adjust the incline using the incline up and down buttons on the
console (reference 1). Watch to see if the incline changes. If the incline changes, inspect the console for damage. If
damage is present,
about:blank
Schwinn 470:  I'm having issues adjusting the incline on my elliptical
order a
Console [12829.A].
incline, order an
(Reference 1)
ID: 12829.1
MCB [12829.F]. This may be
1/4

Advertisement

loading
Need help?

Need help?

Do you have a question about the 470 and is the answer not in the manual?

Questions and answers

Summary of Contents for Schwinn 470

  • Page 1 Schwinn 470:  I'm having issues adjusting the incline on my elliptical Schwinn 470:  I'm having issues adjusting the incline on my elliptical ID: 12829.1 Follow this troubleshooting guide to help resolve incline issues on your Schwinn 470 Elliptical. Some common complaints may include: Can't adjust incline/incline not working...
  • Page 2 3/12/24, 9:34 AM Schwinn 470:  I'm having issues adjusting the incline on my elliptical Adjust the incline using the buttons circled in red and watch for changes to your machine's incline. If the issue persists or the console does not respond, order an Upper Console Cable [12829.B].
  • Page 3 A Customer Care Agent will be able to assess your current warranty eligibility and provide you with your options. Please note that if you did not purchase your machine directly from BowFlex, Schwinn, or Nautilus, we will need a copy of your purchase receipt in order to register your machine for warranty.
  • Page 4 3/12/24, 9:34 AM Schwinn 470:  I'm having issues adjusting the incline on my elliptical Console (2017 model) 8011277 Crank Puller 74025 Incline Motor 8003852 8003851 Upper Console Cable 8002697 3 Contact Tech Team / Advanced Troubleshooting If the issue was not resolved in the steps listed, contact the Tech Team or send an Advanced Troubleshooting case.
