Schwinn 470:  Why is the resistance not changing when adjusted?
Follow this troubleshooting guide to help resolve resistance issues on your Schwinn 470 Elliptical.
Some common complaints may include:
Resistance isn't changing
Can't adjust resistance
Resistance buttons not working
Too easy to pedal
Too difficult to pedal

Follow these steps to troubleshoot the issue

Tools you may need:
Phillips head screwdriver
Flathead screwdriver
(2) 6mm hex/Allen wrenches or the wrench from the
hardware card included with your machine
Voltmeter
1.
Inspect the cables at the console. Unplug your machine from power. Use a Phillips head screwdriver to remove the 4
screws connecting the console to the mast and lift the console/handlebars up to expose the cables (reference 1).
Disconnect and inspect the cables and connections coming from the console and the frame for damage, such as
crimps, cuts, or bent pins. If the cables are undamaged, plug them back in, ensuring they are oriented in the correct
direction, and retest your machine [12818.A]. If the console is damaged,
coming from the frame is damaged,
about:blank
Schwinn 470:  Why is the resistance not changing when adjusted?
order an Upper Console
(Reference 1)
order a
Console [12818.B]. If the cable
Cable [12818.C].
ID: 12818.1
1/7

Advertisement

loading
Need help?

Need help?

Do you have a question about the 470 and is the answer not in the manual?

Questions and answers

Summary of Contents for Schwinn 470

  • Page 1 Schwinn 470:  Why is the resistance not changing when adjusted? Schwinn 470:  Why is the resistance not changing when adjusted? ID: 12818.1 Follow this troubleshooting guide to help resolve resistance issues on your Schwinn 470 Elliptical. Some common complaints may include: Resistance isn't changing...
  • Page 2 3/12/24, 9:33 AM Schwinn 470:  Why is the resistance not changing when adjusted? The bolts circled in red need to be removed to access the cables between the console and the console mast. Inspect the cables circled in teal for damage.
  • Page 3 3/12/24, 9:33 AM Schwinn 470:  Why is the resistance not changing when adjusted? The mast to servo cable is highlighted in red and the servo motor is labeled 'A.' Inspect the entire length for damage and a secure connection. With the shrouds still removed, plug your machine back in and use the console to begin a workout. Adjust the resistance level using the Quick Resistance and/or increase/decrease buttons (reference 3).
  • Page 4 3/12/24, 9:33 AM Schwinn 470:  Why is the resistance not changing when adjusted? Start a workout and attempt to increase the resistance using the buttons circled in red. Your console may look different from what is pictured. The console in this image is from the 2013 model. Listen for servo motor movement.
  • Page 5 3/12/24, 9:33 AM Schwinn 470:  Why is the resistance not changing when adjusted? The servo motor is circled in red. Watch the motor for movement as you adjust the resistance. If the servo motor is not responding appropriately to console commands, test the cable from the servo motor with a voltmeter.
  • Page 6 A Customer Care Agent will be able to assess your current warranty eligibility and provide you with your options. Please note that if you did not purchase your machine directly from BowFlex, Schwinn, or Nautilus, we will need a copy of your purchase receipt in order to register your machine for warranty.
  • Page 7 3/12/24, 9:33 AM Schwinn 470:  Why is the resistance not changing when adjusted?   Part Description Part SKU Console (2013 model) 8002118 Console (2017 model) 8011277 Crank Puller 74025 Eddy Brake Assembly 8002344 Mast Cable 8002693 Servo Motor 8002336 Servo Motor Cable...
