Assembly Instructions
Potting Bench
SKU 629643
Thank you for your purchase. If you have any questions pertaining to the assembly of this
furniture piece, please contact the nearest World Market store. If you are not near a store,
please call our customer service call center free at 877-967-5362 for assistance.
ALL PRODUCTS SOLD AT WORLD MARKET ARE NOT
FOR COMMERCIAL USE AND ARE INTENDED FOR
RESIDENTIAL USE ONLY.
2024.07.05
PAGE 1
PAGE 1
Advertisement
Related Manuals for World Market 629643
Summary of Contents for World Market 629643
- Page 1 Thank you for your purchase. If you have any questions pertaining to the assembly of this furniture piece, please contact the nearest World Market store. If you are not near a store, please call our customer service call center free at 877-967-5362 for assistance.
- Page 2 Component List QTY. PICTURE DESCRIPTION LABEL Left Side Frame Right Side Frame Left Back Frame Right Back Frame Bottom Frame FRONT Center Partition Shelf Frame FRONT BOTTOM Front Rail Support FRONT Back Rail Support FRONT Top Frame FRONT Sliding Door Top Cover Cap PAGE 2...
- Page 3 Hardware List DESCRIPTION QTY. LABEL PICTURE Short Allen Bolt M6 x 35 mm Spring Washer 1 x 7/10 mm Flat Washer 1 x 6.5/14 mm Long Allen Bolt M6 x 50 mm Screw 3.5 x 15 mm Metal Bracket 1.2 x 12 x 45 mm Metal Angle Bracket 18 x 27 x 27 mm Plastic Tub 120 x 300 x 365 mm Loop Strap...
- Page 4 Assemble on a clean non-marring surface (such as the product’s packing foam). Do not discard any packaging until the product has been fully assembled. In case of missing parts, please contact your nearest World Market store or call our customer service call center at 1-877-967-5362.
- Page 5 Assembly Steps Step 1 (H-1) Short Allen Bolt x 2 (H-2) Spring Washer x 4 (H-3) Flat Washer x 4 (H-4) Long Allen Bolt x 2 (T-1) Allen Key FRONT IMPORTANT: Please make note of the different hard ware sizes and ensure you are using the correct size hardware (bolts, screws, and washers)
- Page 6 Assembly Steps Step 2 (H-1) Short Allen Bolt x 2 (H-2) Spring Washer x 4 (H-3) Flat Washer x 4 (H-4) Long Allen Bolt x 2 (T-1) Allen Key FRONT Using a second person to assist you, hold the Right/Left Rail Support (H/K) and Bottom Frame (E) steady and carefully position the Right Side Frame (B) on top of the assembly using the tenons and mortises and a guide.
- Page 7 Assembly Steps Step 3 (H-1) Short Allen Bolt x 4 (H-2) Spring Washer x 4 (H-3) Flat Washer x 4 (T-1) Allen Key FRONT FRONT Using a second person to assist you, carefully place the assembly onto a padded, non-marring surface on its back.
- Page 8 Assembly Steps Step 4 (H-5) Screw x 16 (H-6) Metal Bracket x 6 (H-7) Metal Angle Bracket x 2 (T-2, not included ) Phillips Screwdriver FRONT Carefully place Left/Right Back Frames (B/C) onto the assembly as shown above, ensuring they are oriented correctly.
- Page 9 Assembly Steps Step 5 (H-1) Short Allen Bolt x 4 (H-2) Spring Washer x 4 (H-3) Flat Washer x 4 (T-1) Allen Key FRONT Using a second person to assist you, carefully position Top Frame (L) onto the assembly as shown above.
- Page 10 Assembly Steps Step 6 (T-2, not included ) Phillips Screwdriver OPEN CLOSE With your screwdriver, adjust the Door up or down FRONT Attach Sliding Door (M) to Bottom Frame (E) and Front Rail Support (H) by placing the door's wheels into the sliding track.
- Page 11 Assembly Steps Step 7 FRONT LEFT RIGHT FRONT LEFT OR RIGHT The Shelf Frame (G) can be placed on either the right side or the left side of the assembly. Turn at an angle and insert into the assembly so it rests evenly. Slide Sliding Door (M) left or right to assemble the shelf according to your needs.
- Page 12 Assembly Steps Step 9 ADJUSTABLE LEVELER Levelers are located on the bottom of each leg and may be used for additional adjustment if needed for uneven surfaces. Ensure all hardware is fully tightened at this time. Assembly is now complete and the product is ready for use. Adjustable levelers are located on the bottom of each leg and may be adjusted by turning outwards, counter-clockwise to help account for uneven surfaces.
- Page 13 Anti-Tip Measures WARNING Furniture tip overs can result in death or serious injuries. To reduce the likelihood of tip over, this product should be used with the enclosed Anti-Tip Kit. This Anti-Tip Kit is only a deterrent. It is not a substitute for proper adult supervision.
- Page 14 NOTE: World Market outdoor cushions provide a firm seat experience on initial use. This is normal and by design–with time and continued use, the cushions will break in and become softer. Always store the cushions when they are not in use.
- Page 15 Service Call Center, Toll Free at 877-967-5362. For valid warranty claims, World Market will repair or replace the product, or offer a full or partial credit, in the sole discretion of World Market. This LIMITED ONE-YEAR WARRANTY gives you specific legal rights and you may also have other rights which vary from state to state.
