- Page 1 Assembly Instructions BUNDLE - ADIRONDACK ROCKER 3PC SET SKU 1090N, 1090G 2x ADIRONDACK ROCKING CHAIRS 1x ADIRONDACK SIDE TABLE See following pages for individual component assembly instructions...
- Page 2 Thank you for your purchase. If you have any questions pertaining to the assembly of this furniture piece, please contact the nearest World Market store. If you are not near a store, please call our customer service call center free at 877-967-5362 for assistance.
-
Page 3: Component List
Component List QTY. PICTURE DESCRIPTION LABEL FRONT Seat Slat Seat Left Leg Right Leg Backrest Left Armrest Right Armrest Left Rocker Right Rocker Hardware List DESCRIPTION QTY. LABEL PICTURE Allen Bolt M6 x 35 mm Spring Washer 1 x 7/10 mm Flat Washer 1 x 6.5/14 mm Wood Dowel 8 x 20 mm Screw M6 x 90mm... -
Page 4: Assembly Preparation
Assemble on a clean non-marring surface (such as the product’s packing foam). Do not discard any packaging until the product has been fully assembled. In case of missing parts, please contact your nearest World Market store or call our customer service call center at 1-877-967-5362. -
Page 5: Assembly Steps
Assembly Steps Step 1 (H-1) Allen Bolt x 2 (H-4) Wood Dowel x 4 (T-1) Allen Key IMPORTANT: Please make note of the different hard ware sizes and ensure you are using the correct size hardware (bolts, FRONT screws, and washers) for each step. - Page 6 Assembly Steps Step 3 (H-1) Allen Bolt x 6 (H-2) Spring Washer x 6 (H-3) Flat Washer x 6 (H-4) Wood Dowel x 2 (T-1) Allen Key FRONT Attach the Right Leg (D) to the seat assembly using three Allen Bolt (H-1), three Spring Washers (H-2) and three Flat Washers (H-3).
- Page 7 Assembly Steps Step 5 (H-1) Allen Bolt x 4 (T-1) Allen Key Attach Backrest (E) to each end of the Seat (B) assembly and both Armrests (C/D). Engage all of the bolts by hand, then tighten them using the Allen Key (T-1). DO NOT over-tighten the bolts.
-
Page 8: Assembly Instruction
Thank you for your purchase. If you have any questions pertaining to the assembly of this furniture piece, please contact the nearest World Market store. If you are not near a store, please call our customer service call center free at 877-967-5362 for assistance. - Page 9 Component List QTY. PICTURE DESCRIPTION LABEL Table Top Hardware List PICTURE DESCRIPTION QTY. LABEL Allen Bolt M6 x 40mm Spring Washer 1 x 7/10 mm Washer 1x6.5x14 mm Tool List DESCRIPTION QTY. LABEL PICTURE Allen Key 4 x 110 x 30 mm PAGE 2...
- Page 10 Assemble on a clean non-marring surface (such as the product’s packing foam). Do not discard any packaging until the product has been fully assembled. In case of missing parts, please contact your nearest World Market store or call our customer service call center at 1-877-967-5362.
- Page 11 Assembly Steps Step 1 Place Table Top (B) upside down on a padded non-marring surface. Position the Legs (A) to the Table Top (B) by sliding the notch (tenon) into the slot (mortise). Make sure the leg's drill holes are facing inward. Step 2 (H-1) Allen Bolt x 8 (H-2) Spring Washer x 8...
- Page 12 Assembly Steps Step 3 Place the table upright. Assembly is now complete and the product is ready for use. NOTE: Hardware may loosen over time. Periodically check that all connections remain tight and adjust as needed. PAGE 5...
- Page 13 NOTE: World Market outdoor cushions provide a firm seat experience on initial use. This is normal and by design–with time and continued use, the cushions will break in and become softer. Always store the cushions when they are not in use.
- Page 14 Service Call Center, Toll Free at 877-967-5362. For valid warranty claims, World Market will repair or replace the product, or offer a full or partial credit, in the sole discretion of World Market. This LIMITED ONE-YEAR WARRANTY gives you specific legal rights and you may also have other rights which vary from state to state.
