- Page 1 USER MANUAL ENGLISH Solaris 3.0 Product code: 51360 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
- Page 2 Solaris 3.0 ©2022 Showtec. All rights reserved. No part of this document may be copied, published or otherwise reproduced without the prior written consent of Highlite International. Design and product specifications are subject to change without prior notice. For the latest version of this document or other language versions, please visit our website www.highlite.com...
-
Page 3: Table Of Contents
Solaris 3.0 Table of contents Introduction ................................4 Before Using the Product ..........................4 Intended Use ............................... 4 Product Lifespan ..............................4 Text Conventions ..............................4 Acronyms and Abbreviations .......................... 4 Symbols and Signal Words ..........................5 Laser Hazard Labels ............................6 Symbols on the Information Label ........................ - Page 4 Solaris 3.0 Instructions for Transportation ........................28 Storage ................................28 10. Disposal ................................28 11. Approval ................................28 Product code: 51360...
-
Page 5: Introduction
The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. After unpacking, check the contents of the box. If any parts are missing or damaged, contact your Highlite International dealer. Your shipment includes: ● Showtec Solaris 3.0 ● Seetronic power cable ● Remote interlock ●... -
Page 6: Symbols And Signal Words
Solaris 3.0 Symbols and Signal Words Safety notes and warnings are indicated throughout the user manual by safety signs. Always follow the instructions provided in the user manual. Indicates an imminently hazardous situation which, if not avoided, will result in DANGER death or serious injury. -
Page 7: Laser Hazard Labels
Solaris 3.0 Laser Hazard Labels This device is a class 4 laser device and is provided with the following labels and hazard warnings. Refer to Fig. 02 and Fig. 03 for the position of the labels. DANGER Avoid exposure – laser... -
Page 8: Safety
Solaris 3.0 Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. Warnings and Safety Instructions... - Page 9 Solaris 3.0 WARNING Laser radiation Avoid eye or skin exposure to direct or scattered radiation. This device is a class 4 laser device according to the classification in NEN-EN-IEC 60825-1:2014. It emits visible radiation in the wavelength range 400–700 nm. Exposure to the direct or scattered laser beam can result in severe eye damage and serious skin injuries.
-
Page 10: Requirements For The User
Solaris 3.0 Attention For professional use only This device shall be used only for the purposes it is designed for. This device is designed to be used as a professional laser projector. Any incorrect use may lead to hazardous situations and result in injuries and material damage. -
Page 11: Laser Safety
Solaris 3.0 Laser Safety CAUTION Use of controls or adjustments, or performance of procedures, other than those specified in the user manual, may result in hazardous radiation exposure. Check all applicable national and international regulations concerning laser safety before using this device. -
Page 12: Description Of The Device
Solaris 3.0 Description of the Device The Solaris 3.0 is a 3000-mW RGB laser projector intended for professional use in large venues. By using linear analogue dimming modulation, the Solaris 3.0 can generate the full spectrum of colors. It comes with all necessary safety features, like scanning system overload protection, a key switch, scan-fail safety, an aperture masking plate, and a remote interlock. -
Page 13: Back View
Solaris 3.0 Back View Fig. 05 Interlock RJ45 connector I Power connector OUT, 100–240 V, 50–60 Hz, Interlock RJ45 connector II max 10 A Scan fail button (On/Off) with an LED indicator Power connector IN, 100–240 V, 50–60 Hz X-invert switch... -
Page 14: Product Specifications
Solaris 3.0 Product Specifications Model: Solaris 3.0 Electrical: Input voltage: 100–240 V AC, 50/60 Hz Power consumption: 150 W Fuse: 6,3 A, 250 V Physical: Dimensions: 284 x 188 x 220 mm (L x W x H) (without accessories) Weight:... -
Page 15: Dimensions
Solaris 3.0 Dimensions Fig. 07 Fig. 08 Product code: 51360... -
Page 16: Installation
Solaris 3.0 Installation Safety Instructions for Installation WARNING Incorrect installation can cause serious injuries and damage of property. If trussing systems are used, installation must be carried out only by instructed or skilled persons. ● Make sure that the device is rigidly mounted to prevent movement due to vibration or jarring. -
Page 17: Personal Protective Equipment
Solaris 3.0 Attention Make sure that there is enough space for ventilation around the device. ● Do not block the ventilation openings. Without proper heat dissipation and air circulation, the internal components may overheat. This can result in product damage. -
Page 18: Rigging
Solaris 3.0 Rigging The device is only for overhead mounting. The device can be positioned on a flat surface or mounted to a truss or other rigging structure. Make sure that all loads are within the pre-determined limits of the supporting structure. -
Page 19: Angle Adjustment
Solaris 3.0 Angle Adjustment You can adjust the angle of the device with the adjustment screws (02). 01) Turn the adjustment screws (02) counterclockwise to release them. Tilt the device at the desired angle (see Fig. 12). Turn the adjustment screws (02) clockwise to tighten them. Make sure that the device cannot move freely after the adjustment screws (02) are tightened. -
Page 20: Power Linking Of Multiple Devices
● Do not link more devices on one power link than the maximum recommended number. Maximum recommended number of devices: ● at 100–120 V: 5 devices Solaris 3.0 ● at 200–240 V: 10 devices Solaris 3.0 Product code: 51360... -
Page 21: Setup
Solaris 3.0 Setup Warnings and Precautions WARNING Laser radiation Avoid eye or skin exposure to direct or scattered radiation. Attention Use laser protective eyewear during alignment and setup. During alignment and setup the access of unauthorized persons to the area, where the laser radiation exceeds the spectator MPE, must be restricted. -
Page 22: Setup Example With One Device
Solaris 3.0 Setup Example with One Device Fig. 14 shows a typical setup with one device. Follow the steps below to connect the device to a laser controller and the remote interlock: Connect the laser controller to the ILDA-compatible DB-25 connector INPUT (15) of the device with an ILDA-compatible DB-25 cable. -
Page 23: Setup Example With Multiple Devices
Solaris 3.0 Setup Example with Multiple Devices Fig. 15 shows a typical setup with multiple devices. Follow the steps below to connect the device to a laser controller, to the remote interlock, and to other devices: Connect the laser controller to the ILDA-compatible DB-25 connector INPUT (15) of the device with an ILDA-compatible DB-25 cable. -
Page 24: Using The Safety Devices
Solaris 3.0 Using the Safety Devices The device is equipped with a key switch, a scan fail function and is supplied with a remote interlock with a key switch. Key Switch The key switch prevents that unauthorized and untrained persons can operate the device. If the key is removed, you cannot operate the device. -
Page 25: Operation
Solaris 3.0 Operation Safety Instructions for Operation WARNING Laser radiation Avoid eye or skin exposure to direct or scattered radiation. This device is a class 4 laser device according to the classification in NEN-EN-IEC 60825-1:2014. It emits visible radiation in the wavelength range 400–700 nm. Exposure to the direct or scattered laser beam can result in severe eye damage and serious skin injuries. -
Page 26: Control Modes
Solaris 3.0 Control Modes You will need an ILDA-compatible laser controller in order to control the device. Refer to the user manual of the software supplied with the laser controller for more information on how to control the device. The device is equipped with ILDA-compatible DB-25 connectors. Refer to 5.3. Setup Example with One Device on page 21 and 5.4. -
Page 27: Maintenance
Solaris 3.0 Maintenance Safety Instructions for Maintenance DANGER Electric shock caused by dangerous voltage inside Disconnect power supply before servicing or cleaning. WARNING Laser radiation Avoid exposure to beam. This device is a class 4 laser device according to the classification in NEN-EN-IEC 60825-1:2014. -
Page 28: Corrective Maintenance
Solaris 3.0 Corrective Maintenance The device does not contain user-serviceable parts. Do not open the device and do not modify the device. Refer repairs and servicing to skilled persons. Contact your Highlite International dealer for more information. Replacing the Fuse... -
Page 29: Deinstallation, Transportation And Storage
Solaris 3.0 Deinstallation, Transportation and Storage Instructions for Deinstallation WARNING Incorrect deinstallation can cause serious injuries and damage of property. ● Let the device cool down before dismounting. ● Disconnect power supply before deinstallation. ● Always observe the national and site-specific regulations during deinstallation and derigging of the device. - Page 30 Solaris 3.0 Product code: 51360...
- Page 31 Solaris 3.0 Product code: 51360...
- Page 32 ©2022 Showtec...
