- Page 1 V1.5 G900 Pro MIRROR DASH CAM User Manual wolfbox.com The information in this manual is subject to change without notice.
- Page 2 Content Precautions ......Warnings ......Product Overview .
- Page 3 • Keep small accessories out of the reach of children. If this product is damaged or malfunctions, stop using it immediately and contact WOLFBOX support. Continue use may cause fire, electric shock or vehicle failure. • This product is intended to be used as reference material in the event of an accident.
- Page 4 Product Overview • Thank you for choosing WOLFBOX G900 Pro Mirror Dash Cam. This product provides a high-quality image and captures irrefutable evidence in the event of an accident, and records the beauty along the way for you. • WOLFBOX is a professional automotive supplies manufacturing company.
- Page 5 Product Specifications DDR3 8GB Display Type Video Format Image Format Front Camera 4K (3840*2160) Rear Camera 2.5K Rear Display Size 12'' 30fps Lens FPS External, Power USB Type-C 3.5mm headphone Interface interface Wi-Fi Supported Voice Control Supported Connection Operating Full Touch -4°F ~158°F Supported Temperature...
- Page 6 Package Contents •4K Mirror Dash Cam • 2.5K Rear Camera • GPS • Power Supply Cable • Rear Cam Cable with Car Charger • Adhesive • Rubber Straps*4 • Cable Clips*5 • User Manual...
- Page 7 Appearance Name Description Lens Front lens, records the front view of the car USB Type-C Port Port for power supply/connection Rear camera Port used to connect the rear camera connector TF card slot Provides expandable storage (class 10 Max 512GB) Used to connect GPS module GPS connector (GPS function requires optional GPS antenna)
- Page 8 User Interface Overview icon Description Speed & Driving Direction: Once GPS is connected, the proper information will be displayed Date & Time Turn on/off the device sound Turn on/off Wi-Fi View voice command entries Start / Stop Recording Adjust the screen brighten Switching between front,rear and split-screen camera view Snapshot: Take a Snapshot Recording Status: Flashing yellow indicates Lock-Recording...
- Page 9 icon Description File Playback: Playback the video & photo Turn on/off audio recording Settings: Tap to enter the settings menu • Playback Mode When you power on the dash cam, it will start recording auto- matically. Click/select to enter playback mode. Stores images captured Stores images captured by the front camera...
- Page 10 Feature Overview Click the setting icon to enter the function menu, where you can adjust various functions and parameters of the entire machine. Function Option Description 4K+2.5K /4K+1080P Video resolution selection. /2.5K+2.5K Resolution /... Set the default video recording F-cam/R-cam interface display screen upon /Split Screen startup.
- Page 11 Function Option Description Set the status of the device's Wi- OFF/2.4G/5.8G Fi connection. Wi-Fi OFF/Low/Medium Set the volume level of the device. /High Volunme Setting ON/OFF Set the switch for key tones. Click Tone OFF/10 Seconds Set the activation time for the /30 Seconds screen saver.
- Page 12 Function Option Description Adjust the vertical flip of the rear ON/OFF camera image. Mirror Flip Adjust the up-down flip of the ON/OFF rear camera image. Rear cam Flip Set the switch for the reversing ON/OFF line display function. Reversing Line /G-Trigger Recording /12H Time-lapse recording...
- Page 13 Function Option Description ON/OFF Set the switch for time watermark. Date Stamp Set the switch for speed ON/OFF watermark. Speed Stamp ON/OFF Set the switch for GPS watermark. GPS Stamp KM/H / MPH Set the unit for speed display. Speed Unit English/Français/ Deutsch/Italiano/ Set the language for the device.
- Page 14 Function Option Description 12 Hours/24 Hours Set the time display system. Time Style Adjust the time zone based on geographical location. Time Zone Set the switch for daylight saving ON/OFF time. 50 Hz/60 Hz Set the screen refresh rate. Flicker Set the reminder for formatting /Each 15 days the SD card.
- Page 15 Function Option Description Restore all settings to factory defaults. Reset Setup Display QR code for downloading the app. Display device information. Product Information Note: Parking Mode requires a hardwire kit (purchased separately) in order to activate. With the hardwire kit connected and Parking Mode enabled, the dash cam will enter Lapse Recording mode when the car turns off.
- Page 16 Voice Control Feature Fast control through simple voice commands. When the recording interface displays a white icon , it means that the Voice Control feature is activated. You can enable/disable the voice control feature through the "Voice Control" in the menu. lock the video take picture turn on audio...
- Page 17 Here you can view, download and share your videos easily with your friends and family. The app “WOLFBOX” is a free app that allows you to operate this WLAN built-in drive recorder from your smartphone. • How to connect Wi-Fi? 1.
- Page 18 • Download, edit and share your video clip via Wolfbox App In the app, you can view and edit downloaded local albums and share them with others. How to play video on computer We recommend the application “GPS Media Player” to watch and play dash cam videos, and view Google Maps.
- Page 19 Video play window (Front) Video play window (Rear) Map and track display Play control panel Speed and driving state indication Play list Note: If you record the front and rear dash cam videos simultaneously and add them to the playlist, you can play them side by side in split-screen mode.
- Page 20 • The Back view of the host •Unit installation 1. Place the head unit (WOLFBOX Mirror) on the rear-view mirror by hand, and be sure to separate the silicone brackets on both sides of the rearview mirror. Buckle the device to the rearview mirror with the rubber straps.
- Page 21 2. Connect the car charger to the charger adapter to supply power for the dash cam. Pillar A • Power ON/OFF • Short press the power button to turn on, long press the power button to turn off. • When using the car charger, if the cigarette lighter port is ACC, the dash cam will automatically turn on when the car is started.
- Page 22 Rear Camera Wiring Instructions ・ Dash camera Connected to reversing light Outside the car bracket Inside the car bracket Note: The rear camera has two wire routing options, both of which conceal the wire along the edges of the door. 1.
- Page 23 2. Rear camera cable routing Route the rear camera cable to the rear of the car, leaving some slack. Insert the cable into the gap in the front windshield and along the upper end of the door using the included tool. If you choose to install the rear camera inside your car, fix it on the rear windshield after routing the wiring.
- Page 24 4. Fix the rear camera and connect the cables Fix the rear camera near the license plate light with 3M glue, and connect the rear camera cable through the license plate light hole to the rear camera cable. 5. Connect the red wire to the reverse light's positive terminal Find the positive terminal of the reverse light.
- Page 25 •GPS Installation Position 1: Install the dash cam in the right corner of the central console and hide the wiring along the edge of the front windshield using double-sided tape. • Considering the use effect and installation convenience, we usually recommend customers install it at position 1. •...
- Page 26 ・ Can rear camera images be transmitted wirelessly? The G900 Pro Wi-Fi comes with a rear camera cable through which the rear camera video is transmitted. The Wi-Fi feature is only used to connect the phone to the dash cam.
- Page 27 Customer Service Center If you have any problems with the function or installation, please contact us with any questions. Help Center WhatsApp WOLFBOX For more information: service@wolfbox.com www.wolfbox.com https://wolfbox.com/contact-us...
- Page 28 Check us out here! Product and service are the foundation of WOLFBOX. Email: service@wolfbox.com Phone: +1 888 296 8399 www.wolfbox.com...
