AJAX Hub 2 2G User Manual page 8

Hub – server connection mode is enabled by default. The hub LED has a
list of indications showing the system state or events occurring. The Ajax
logo on the front side of the hub can light up red, white, purple, yellow,
blue, or green, depending on the state.
The hub LED has a list of indications showing the system state or events
occurring. The Ajax logo on the front side of the hub can light up red,
white, purple, yellow, blue, or green, depending on the state.
Indication
Lights up white.
Lights up green.
Lights up red.
Lights up 180 seconds after
the loss of power, then
flashes every 10 seconds.
Event
Two communication
channels are connected:
Ethernet and SIM card.
One communication
channel is connected:
Ethernet or SIM card.
The hub is not connected to
the internet or there is no
connection with the Ajax
Cloud service.
The external power supply
is disconnected.
Note
If the external power supply
is off, the indicator will flash
every 10 seconds.
After a loss of power, the
hub will not light up
immediately, but will start
flashing in 180 seconds.
If the external power supply
is off, the indicator will flash
every 10 seconds.
After a loss of power, the
hub will not light up
immediately, but will start
flashing in 180 seconds.
If the external power supply
is off, the indicator will flash
every 10 seconds.
After a loss of power, the
hub will not light up
immediately, but will start
flashing in 180 seconds.
The LED indication colour
depends on the number of
communication channels
connected.
