SIP Series

L130

SIP Corded 1-line Assisted Living Telephone

User Manual

Need help?

Do you have a question about the SIP Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Snom SIP Series

Page 1 SIP Series L130 SIP Corded 1-line Assisted Living Telephone User Manual...
Page 2 Important safety instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of ﬁre, electric shock and injury, including the following: 1. This product should be installed by a premises, consult your dealer or local qualiﬁed technician.
Page 3 instructions. Improper adjustment of plugged into a ceiling, under-the-table other controls may result in damage or cabinet outlet. and often requires extensive work by 19. Use only the power cord and batteries an authorized technician to restore the indicated in this manual. Do not dispose product to normal operation.
Page 4 Instructions de sécurité importantes Lorsque vous utilisez votre équipement téléphonique, des précautions de base doivent toujours être prises pour réduire les risques d’incendie, d’électrocution et de blessure, notamment les suivantes : 1. Ce produit doit être installé par un technicien compagnie d’électricité...
Page 5 autorisé pour remettre le produit en état locales les éventuelles instructions spéciales de fonctionnement. d’élimination. • Si le produit est tombé et que le socle 20. En position de montage mural, veillez à du téléphone et/ou le combiné ont été monter le socle du téléphone sur le mur en endommagés.
Page 6 Table of contents Important safety instructions ....2 Instructions de sécurité importantes ..4 Parts check list ........7 Telephone layout ........8 Installation ..........12 Set up ........... 17 Photo speed dial ..........18 Auto answer ............20 Call block ............21 Star Code ............23 Operation ..........24 Appendix ..........26...
Page 7 Parts check list Items contained in the corded telephone package: Parts included Model Model name number Ethernet cable | Base stand & Telephone base Corded handset Telephone Base Mounting bracket Power Adapter SIP Corded 1-line Assisted L130 Living Telephone EN - 7...
Page 8 Telephone layout Telephone base • On when the telephone is in use. Visual ringer indicator • Flashes to indicate an incoming call. • Photo speed dial memory key 4 is tailored for emergency calls. Emergency SOS speed dial key • Store your emergency contact’s telephone number for quick dial. Photo speed •...
Page 9 • You can choose whether the digits are to be announced whenever TALKING DIGITS you press the number keys. • Turn TALKING DIGITS key on/off. Ringer • Adjust the base ringer volume while in idle. control REDIAL key • Press to redial the last number. •...
Page 10 Telephone layout Telephone base Ethernet cable Jack 15 Power adapter input 16 Groove for handset cord 17 Coiled handset cord jack Base stand & Mounting bracket Groove for Ethernet cable and power cable 19 PRESS TO RELEASE tabs EN - 10...
Page 11 Telephone layout Corded Handset 20 Handset earpiece Slot for handset tab • For optional wall mounting 22 Handset microphone 23 Coiled handset cord EN - 11...
Page 12 Installation Telephone base installation Installation option - desktop position 1. Turn the telephone base over with the rear side facing up. Slide the right peg of the base stand leftward and push the left peg down into the two clasps on the telephone base until they lock securely as shown below.
Page 13 Telephone base installation Installation option - wall mount position To mount the telephone base on the wall 1. On the rear side of the telephone base, press the tabs of the wall-mount bracket to release it from the tabletop orientation. 2.
Page 14 3. Connect the Ethernet cable, power cable and coiled handset cord to the telephone adapter base and route them along the groove accordingly. Install the telephone base as shown below. Ethernet cable jack Power adapter input Ethernet cable wall jack Power adapter Coiled handset cord jack...
Page 15 5. Mount the telephone base on the wall by positioning the eyelets on the mounting bracket against the mounting studs. Then, slide the telephone base down on both mounting studs until it locks into place. 6. Place the corded handset on the telephone base cradle. EN - 15...
Page 16 wall mount bracket dimensions Unit: mm EN - 16...
Page 17 Set up All telephone settings are programmed through the administrative web portal. Please refer to the SIP Phone Conﬁguration Guide for details. EN - 17...
Page 18 Photo speed dial There are eight photo speed dial memory keys numbered 1 to 8 on the telephone base. You can store the telephone numbers you wish to quick dial to the photo speed dial keys. Photo speed memory key 4 is tailored for emergency calls. •...
Page 19 Insert photos for speed dial keys You can insert photos into the photo speed dial compartments, or write the contact names on cards and insert them into the compartments. NOTE • The telephone base is shipped with protective stickers covering the photo speed dial compartments. Remove the protective sticker before use.
Page 20 Auto answer You can store the telephone numbers you wish the phone to automatically answer to the auto answer list. The auto answer List can store up to 10 entries. When there is an incoming call from an auto answer number, the phone will automatically pick up the call. Add or store a call block number 1.
Page 21 Call block You can store the telephone numbers you wish to block to the call block list. The call block List can store up to 10 entries. When a call is blocked, the telephone will not ring. Add or store a call block number 1.
Page 22 NOTE • When the phone is in the programming mode, press DELETE/CANCEL key at any time to cancel and quit the programming process. • When getting an incoming call while the phone is in programming mode, the phone will automatically exit the programming mode. •...
Page 23 Star Code The star code enables you to use the telephone base to query and change phone settings. Set factory default When the phone is on-hook, press this key sequence on the telephone base: *990000#. The Visual ringer indicator will flash if entered successfully, and the device will factory reset. Retrieve the IP address of your phone When the phone is on-hook, press this key sequence on the telephone base: *471233#.
Page 24 Operation Volume Ringer volume and listening volume can be Receive a call adjusted from the telephone base. When there is an incoming call, the telephone rings and the Visual ringer indicator flashes. To answer a call: Press SPEAKER or lift the corded handset from the telephone base to answer.
Page 25 Mute Photo/memory speed dial If you have set any speed dial numbers, you can Mute the microphone press a photo speed dial key to quickly dial the 1. During a call, press MUTE key. preset number. • The MUTE key illuminates when the mute For details on setting photo/memory speed dial, function is turned on.
Page 26 Appendix Troubleshooting If you have difﬁculty with the telephones, please try the suggestions below. In case of malfunction, contact authorized service personnel, your seller, or Snom. For corded telephone Question Suggestions • Make sure a Cat-5 network cable is plugged...
Page 27 Question Suggestions • Try all the above suggestions. • A preﬁx may be required for dialling some internal or external calls • Make sure there is a dial tone before dialling. 5. I cannot dial out. • Check your server settings. If other telephones in your hotel are having the same problem, the problem is in the wiring or network server.
Page 28 Question Suggestions • If your telephone is plugged in with a modem or a surge protector, plug the telephone (or modem/surge protector) into a different location. If this doesn’t solve the problem, relocate your telephone or modem farther apart from each other, or use a different surge protector.
Page 29 FCC, ACTA and IC regulations FCC Part 68 and ACTA FCC Part 15 This equipment complies with Part 68 of the FCC rules and with technical requirements adopted This equipment has been tested and found by the Administrative Council for Terminal to comply with the requirements for a Class Attachments (ACTA).
Page 30 Your telephone service provider is required Industry Canada to notify you before interrupting service. If This product meets the applicable Innovation, advance notice is not practical, you will be Science and Economic Development Canada notiﬁed as soon as possible. You will be given technical speciﬁcations.
Page 31 ISEDC Warning This device complies with Innovation, Science, and Economic Development Canada licence- exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Page 32 Maintenance Disclaimer and Limitation of Liability VTech Communications, Inc. and its suppliers Taking care of your telephone assume no responsibility for any damage or Your telephone contains sophisticated electronic loss resulting from the use of this user’s manual. parts, so it must be treated with care. VTech Communications, Inc.
