RED Compact EVF Operation Guide
Product Management
March 01, 2024 14:14
This article outlines the processes for using the RED Compact EVF, DSMC2 Adapter A, RED EVF
Mount and RED EVF Extension Arm.
For FAQ's see
DSMC3 EVF -
RED Compact EVF
The RED Compact EVF is a single cable monitoring solution for DSMC3 camera systems. It
features a 1080p micro-OLED display and user-assignable buttons to quickly access tools such as
peaking and magnify, or to control the camera's settings such as ISO, FPS, and White Balance.
The RED Compact EVF also features an adjustable diopter, a quick-connect mount for use with the
RED EVF Mount or a 1/4-20 mount plate for use with third-party options, and an updated eyecup
mounting system that allows for a more secure fit while maintaining easy eyecup replacement (refer
to RED EVF
Mount).
NOTE:
• Camera control is only supported on DSMC3 systems.
• The DSMC3 Adapter A is required to use the RED Compact EVF on DSMC3 cameras.
• DC Power is provided by the camera through the DSMC3 Adapter A (refer
A).
WARNING: DO NOT point the RED Compact EVF eyepiece at direct sunlight. Continued
exposure to direct sunlight may damage the EVF. Point the eyepiece away from sunlight when not
https://support.red.com/hc/en-us/articles/26937072145171-RED-Compact-EVF-Operation-Guide
RED Compact EVF Operation Guide – RED Support
›
V-RAPTOR Ecosystem
FAQs.
FOLLOW
to DSMC3 Adapter
1/14
Advertisement
Related Manuals for RED Compact EVF
Summary of Contents for RED Compact EVF
- Page 1 RED Compact EVF Operation Guide Product Management FOLLOW March 01, 2024 14:14 This article outlines the processes for using the RED Compact EVF, DSMC2 Adapter A, RED EVF Mount and RED EVF Extension Arm. For FAQ’s see DSMC3 EVF - FAQs.
- Page 2 8/12/24, 1:21 PM RED Compact EVF Operation Guide – RED Support in use. Damage to the RED Compact EVF caused by continued exposure to direct sunlight is not covered under warranty. DIMENSIONS 2.43" x 2.46 x 4.8" WEIGHT 0.8lbs MATERIAL...
- Page 3 The RED Compact EVF is configured to use the ‘FN Toggle’ feature to control the camera. This allows the operator to change the camera's FPS, Iris (with compatible lens), Shutter Angle, ISO/ Gain, White Balance, and ND (with RED RF to PL Adapter w/ Electronic ND) by using the buttons on the EVF.
- Page 4 8/12/24, 1:21 PM RED Compact EVF Operation Guide – RED Support EVF BUTTONS Press each EVF button to enable a user-assigned camera function. • The default setting for EVF button 1 is Top EVF Magnify Toggle. • The default setting for EVF button 2 is False Color Exposure Toggle.
- Page 5 8/12/24, 1:21 PM RED Compact EVF Operation Guide – RED Support 3. Press EVF buttons 1 or 2 to increase or decrease the value. https://support.red.com/hc/en-us/articles/26937072145171-RED-Compact-EVF-Operation-Guide 5/14...
- Page 6 8/12/24, 1:21 PM RED Compact EVF Operation Guide – RED Support 4. Press EVF buttons 1+2 to move to the next value. NOTE: Function control will time out if there are no button presses for 5 seconds. CHANGING THE BUTTON FUNCTIONS https://support.red.com/hc/en-us/articles/26937072145171-RED-Compact-EVF-Operation-Guide...
- Page 7 FN Toggle CLEANING THE EVF SCREEN NOTE: This section describes only how to clean the OLED screen on the RED Compact EVF and DSMC2 RED EVF, and not how to clean the entire device. This section explains how to clean the screen on the RED Compact EVF and DSMC2 RED EVF.
- Page 8 RED Compact EVF Operation Guide – RED Support surface. PROHIBITED EVF SCREEN CLEANERS DO NOT use any of the items listed below to clean the screen on the EVF. These products have not been tested on RED products and may cause damage or streaking. Compressed air Gas dusters Solvents...
- Page 9 RED Compact EVF Operation Guide – RED Support The DSMC3 Adapter A attaches to the top of KOMODO-X, V-RAPTOR, or V-RAPTOR XL, and provides a 16-pin output that provides power, video, and control to the RED Compact EVF and DSMC2 RED EVF (OLED).
- Page 10 RED EVF Extension Arm (sold separately). NOTES: The 15 mm bracket is not included, refer to RED 15 mm Top Handle Bracket and V-RAPTOR XL Top 15 mm LWS Rod Support Bracket for DSMC3 mounting options.
- Page 11 For attaching and removal of the EVF to the Mount. To attach the RED Compact EVF or DSMC2 OLED EVF align the locator pin on the RED EVF Mount with the corresponding locator on the EVF and rotate the locking wheel anti-clockwise until tight.
- Page 12 RED Compact EVF Operation Guide – RED Support The EVF Cable Right-to-Straight 12(18,32)” is compatible with the DSMC3 Adapter A to support and use the RED Compact EVF, with one 90 degree and one straight connector that provides a high- resolution video feed.
- Page 13 8/12/24, 1:21 PM RED Compact EVF Operation Guide – RED Support Articles in this section RED Compact EVF Operation Guide V-RAPTOR [X] UPGRADE FAQ RF to PL Adapter w/ Electronic ND - Lens Compatibility DSMC3 EVF - FAQs V-RAPTOR [X] - Extended Highlights DSMC3 RED TOUCH 7.0”...
- Page 14 8/12/24, 1:21 PM RED Compact EVF Operation Guide – RED Support Copyright © 2004-2024 RED Digital Cinema, LLC. All rights reserved. https://support.red.com/hc/en-us/articles/26937072145171-RED-Compact-EVF-Operation-Guide 14/14...
