CAMDEN CX-MA0614-25 Installation Instructions

Electrified Locks, Relays and Timers
CX-MA0614-25 & CX-MA1214-25
Spacer for 600 and 1200 LB Magnetic Locks
INSTALLATION INSTRUCTIONS
THIS PACKAGE INCLUDES:
1 - CX-MA0614-25(D)/CX-MA1214-25(D)
3 - Metal Screws #12
3 - M4 Screws (CX-MA0614-25)
1. GENERAL DESCRIPTION
The Camden CX-MA0614-25(D)/CX-MA1214-25(D) is a Spacer bar
that allows a 600 or 1200 LB (Single/Double Door) Magnetic Lock to
mount onto Door Frames with a narrow depth between the header
jamb and stop.
2. SPECIFICATIONS
There are four Spacer models .
CX-MA0614-25
CX-MA0614-25D
CX-MA1214-25
CX-MA1214-25D
4. DIMENSIONS
CX-MA0614-25
Notch for wiring
19 ⁄ "
(500mm)
7 ⁄ "
(199.8mm)
CX-MA0614-25D
Notch for wiring
12 Threaded Holes #8
6 - M4 Screws (CX-MA0614-25D)
8 - M4 Screws (CX-MA1214-25)
16 - M4 Screws (CX-MA1214-25D)
600 LB Single Door
600 LB Double Door
1200 LB Single Door
1200 LB Double Door
9 ⁄ "
(250mm)
3 ⁄ "
(90.2mm)
3 ⁄ "
(80mm)
6 Threaded
Holes #8
7 ⁄ "
(199.8mm)
(25.4mm)
1 - Installation Manual
3. APPLICATION
Door Frame
Door
Figure 4.1 Dimensions
CX-MA1214-25
Notch for wiring
1"
(25.4mm)
1"
(25.4mm)
CX-MA1214-25D
Notch for wiring
1"
(25.4mm)
1"
CX-MA0614/MA1214
SPACER
(Single/Double Door)
MOUNTING PLATE
MAGNETIC LOCK
ARMATURE PLATE
Figure 3.1 Application (Side View)
10 ⁄ "
(266mm)
4 ⁄ "
(117.9mm)
20 ⁄ "
14 Threaded
(532mm)
7 ⁄ " Holes #8
(201.9mm)
7 ⁄ "
(201.9mm)
28 Threaded Holes #8
4 ⁄ "
(117.9mm)
1"
(25.4mm)
1"
(25.4mm)
1"
(25.4mm)
1"
(25.4mm)
Page 1 of 2
