- Page 1 REFRIGERATION DESIGN DM50CD, DM50CF Drawer Minibar Installation and Operating Manual...
- Page 2 © 18.10.24 Dometic Group. The visual appearance of the contents of this manual is protected by copyright and design law. The underlying technical design and the products contained herein may be protected by design, patent or pending patent. The trademarks mentioned in this manual belong to Dometic Sweden AB. All rights...
- Page 3 DM50CD, DM50CF Explanation of symbols Please read these instructions carefully and follow all instructions, guidelines, and warnings included in this product manual in order to ensure that you install, use, and maintain the product properly at all times. These instructions MUST stay with this product.
- Page 4 Electrocution hazard • Ensure that the minibar has been installed by a qualified technician in accordance with the Dometic installation manual. • Do not operate the minibar if it is visibly damaged. • If this minibars power cable is damaged, it must be replaced by the manufacturer, service agent or a similarly qualified person in order to prevent safety hazards.
- Page 5 DM50CD, DM50CF Safety instructions • The refrigerant circuit contains a small quantity of an environmentally friendly but flammable refrigerant. It does not damage the ozone layer and does not increase the greenhouse effect. Any leaking refrigerant may ignite. • Keep the installation recess for the minibar free of any electrical com- ponents and light sources which during normal or abnormal operation produce sparks or arcs (i.e., relays or fuse boxes).
- Page 6 Safety instructions DM50CD, DM50CF CAUTION! Failure to obey these cautions could result in minor or moderate injury. Risk of crushing • Do not put your fingers into the hinge. Health hazard • Foodstuff may only be stored in its original packaging or in suitable containers.
- Page 7 • Ensure that foodstuffs do not touch the walls of the cooling area. Scope of delivery The following main alternatives are obtainable: • Minibar DM50CD with door panel, without lock • Minibar DM50CD with door panel, with lock • Minibar DM50CF without door panel, without lock •...
- Page 8 Intended use DM50CD, DM50CF Quantity Description Lock decor (Wooden panel) DM50CF wooden version with lock only Lock version only Installation and Operating manual Intended use The refrigeration appliance (also referred to as minibar) is intended to be used in household and similar applications such as: •...
- Page 9 The main drawer has room for 23 bottles with a maximum height of 27.5 cm. The minibar DM50CD comes with a anthracite panel and pull handle. The minibar DM50CF is delivered without panel and is prepared for fitting the hotel's own door decor.
- Page 10 Technical description DM50CD, DM50CF Rear side Item Description Stopper AC connection cable Drip tray...
- Page 11 DM50CD, DM50CF Technical description Control panel (inside the device) Press“SET”to enter SLEEP mode Item Description Lamp Error LED Status LED Setting button...
- Page 12 Technical description DM50CD, DM50CF Main drawer Item Description Small bottle holder Wide divider Separator Bottle finger Small divider...
- Page 13 DM50CD, DM50CF Technical description Mini drawer Item Description Rotatable divider Miniature bottle holder Dimensions 508 mm (20 in.) 480 mm (18.9 in.) 450 (17.7 in.) 30 mm (1.2 in.) 10 mm (0.4 in.) 71.2 mm (2.8 in.) 150 mm (5.9 in.)
- Page 14 Installation DM50CD, DM50CF Installation CAUTION! Health hazard To avoid a hazard due to instability of the device, it must be fixed in accordance with the instructions. Mounting the minibar into a piece of furniture NOTICE! Damage hazard Air passing through the inlet air duct must not be heated.
- Page 15 DM50CD, DM50CF Installation Installation alternatives 200 cm² 200 cm² 31 in² 31 in² 200 cm² 200 cm² 31 in² 31 in² 200 cm² 31 in² 200 cm² 31 in² 200 cm² 200 cm² 31 in² 31 in²...
- Page 16 Installation DM50CD, DM50CF Installation recess 443 mm 570 mm 490 mm DM50CD 17.4 in 22.4 in 19.3 in 443 mm 570 mm 488+d mm DM50CF 17.4 in 22.4 in 19.2+d in C (+d) Air flow Ventilation openings Air inlet Air outlet 200 cm²...
- Page 17 DM50CD, DM50CF Installation Item Description Screw ø 4 x 45 mm Plug 6. Fasten the minibar with the four screws (fig. a 1, page 17). 7. Insert the four plugs (fig. a 2, page 17) into the boring. Connecting the minibar electrically ➤...
- Page 18 Operation DM50CD, DM50CF Operation Saving energy • Only open the minibar as often and for as long as necessary. • Avoid unnecessarily low temperature settings. • For optimal energy consumption, position the shelves and drawers according to their position on delivery.
- Page 19 DM50CD, DM50CF Operation Entering “SLEEP” mode: ➤ Press briefly the setting button (1). ✔ The internal lamp (3) turns off, the status LED (2) is still on. The minibar stops cooling. Leaving “SLEEP” mode: ➤ Press briefly the setting button (1).
- Page 20 Cleaning and maintenance DM50CD, DM50CF You can use the setting button (1) to set the cooling temperature to one of three values: 4 °C, 7 °C and 12 °C. Thereby the temperature will be changed in the order 4 °C … 7 °C … 12 °C … 4 °C etc.
- Page 21 Warranty If the product does not work as it should, please contact your retailer or the manufacturer's branch in your country (see dometic.com/dealer). The warranty applicable to your product is 2 year(s). For repair and warranty processing, please include the following documents when you send in the device: •...
- Page 22 This warranty policy is subject to the conditions and guarantees which are mandatory as implied by the Consumer Guarantees Act 1993(NZ). Local support Please find local support at the following link address: dometic.com/dealer Disposal Recycling packaging material ➤ Place the packaging material in the appropriate recycling waste bins wher- ever possible.
- Page 23 DM50CD, DM50CF Technical data Technical data DM50CD DM50CF Voltage: 220 – 240 Vw, 50 Hz – 60 Hz Cooling capacity: max. 40 °C below ambient temperature (adjustable in three steps: 4 °C, 7 °C, 12 °C) Total volume: 50 l...
