REFRIGERATION
DM50NTE
Drawer Minibar
EN
Installation and Operating Manual. . . . . . . . 9
Schubfach-Minibar
DE
Montage- und Bedienungsanleitung . . . . .23
Minibar à tiroir
FR
Instructions de montage
et de service . . . . . . . . . . . . . . . . . . . . . . . . .38
Cajón minibar
ES
Instrucciones de montaje y de uso . . . . . . .53
Minibar de gaveta
PT
Instruções de montagem e manual de
instruções . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Cassetto del minibar
IT
Istruzioni di montaggio e d'uso . . . . . . . . .83
Lade minibar
NL
Montagehandleiding en
gebruiksaanwijzing . . . . . . . . . . . . . . . . . . .98
Skuffe minibar
DA
Monterings- og betjeningsvejledning . . . 112
MINI FRIDGES
Låda till minibar
SV
Monterings- och bruksanvisning . . . . . . . 126
Uttrekkbar minibar
NO
Monterings- og bruksanvisning . . . . . . . . 140
Vetolaatikkominibaari
FI
Asennus- ja käyttöohje . . . . . . . . . . . . . . . 154
Минибар с выдвижным ящиком
RU
Инструкция по монтажу и эксплуатации 168
Minibary szufladowe
PL
Instrukcja montażu i obsługi. . . . . . . . . . . 183
Minibar Drawer
SK
Návod na montáž a uvedenie
do prevádzky. . . . . . . . . . . . . . . . . . . . . . . 197
Minibar Drawer
CS
Návod k montáži a obsluze . . . . . . . . . . . 211
Fiókba szerelt minibár
HU
Szerelési és használati útmutató . . . . . . . 224

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DM50NTE and is the answer not in the manual?

Questions and answers

Related Manuals for Dometic DM50NTE

Summary of Contents for Dometic DM50NTE

  • Page 1 Минибар с выдвижным ящиком Инструкция по монтажу и эксплуатации 168 Minibary szufladowe Instrukcja montażu i obsługi... 183 DM50NTE Minibar Drawer Návod na montáž a uvedenie Drawer Minibar do prevádzky..... . . 197 Installation and Operating Manual.
  • Page 2 DM50NTE...
  • Page 3 DM50NTE...
  • Page 4 DM50NTE...
  • Page 5 DM50NTE ≥ 400 cm² ≥ 400 cm² ≥ 400 cm² ≥ 400cm² ≥ 400 cm² ≥ 400 cm² ≥ 400 cm² ≥ 400cm²...
  • Page 6 DM50NTE 473,5 121,5...
  • Page 7 DM50NTE...
  • Page 8 DM50NTE...

  • Page 9: Table Of Contents

    DM50NTE Please read this operating manual carefully before starting the device. Keep it in a safe place for future reference. If the device is passed on to another person, this operating manual must be handed over to the user along with it.

  • Page 10: Explanation Of Symbols

    Explanation of symbols DM50NTE Explanation of symbols WARNING! Safety instruction: Failure to observe this instruction can cause fatal or serious injury. CAUTION! Safety instruction: Failure to observe this instruction can lead to injury. NOTICE! Failure to observe this instruction can cause material damage and impair the function of the product.
  • Page 11 DM50NTE Safety instructions • If this device's power cable is damaged, it must be replaced by the manufacturer, customer service or a similarly qualified person in order to prevent safety hazards. • Do not store any explosive substances such as spray cans with a flammable propellant in the device.

  • Page 12: Scope Of Delivery

    DM50NTE Scope of delivery The following main alternatives are obtainable: • Minibar DM50NTE D with door panel, without lock • Minibar DM50NTE D with door panel, with lock • Minibar DM50NTE F without door panel, without lock • Minibar DM50NTE F without door panel, with lock...

  • Page 13: Proper Use

    Proper use Proper use The Minibars DM50NTE D and DM50NTE F are designed for use inside a piece of furniture and are suitable for cooling beverages and food. The device is designed for use with a 230 V AC mains supply.
  • Page 14 Description of the device Front panel No in Description fig. 1, page 2 Lock (optional) Handle (DM50NTE D only) Door panel (DM50NTE D only) Rear side No in Description fig. 2, page 2 Mains adaptor 12 Vg socket Drip tray...

  • Page 15: Installation

    • The cut-out dimensions H x W x D are: – DM50NTE D: 438 x 570 x 504 mm – DM50NTE F: 438 x 570 x (502 + d) mm d is the thickness of the hotel‘s own decor • The clearance between the minibar‘s back and the furniture wall should be approx.
  • Page 16 ✓ The Power Status LED lights up. ✓ The lamp lights up and the minibar starts cooling the interior. Mounting hotel's own door decor (DM50NTE F only) The hotel's own door decor has to comply with the following requirements: • Maximum weight: 2 kg •...
  • Page 17 ➤ Drill a hole (A 1) with a diameter of 23.6 mm through the decor (only DM50NTE D) and the door. ➤ Unscrew the twelve screws (B 1) of the decor frame (B 2) (only DM50NTE D). ➤ Remove the decor frame (only DM50NTE D).

  • Page 18: Operation

    Operation DM50NTE Assembling the drawer (fig. c, page 8) ➤ Push the gasket (1) on the decor frame (2). ➤ Screw the door handle (4) onto the door. ➤ Push the plugs (3) on the screws of the door handle (4).
  • Page 19 DM50NTE Operation Using the temperature setting function The minibar is set by default to a cooling temperature of 7 °C at an ambient temperature of 25 °C. You can use the setting button (fig. 3 4, page 3) to set the cooling temperature to one of three values (5 °C, 12 °C and 7 °C).

  • Page 20: Troubleshooting

    Troubleshooting DM50NTE Troubleshooting Fault Possible cause Suggested remedy Device does not No voltage present in Try using another plug socket. function, Power Status the AC voltage socket. LED does not glow. The mains adapter is This can only be repaired by an defective.

  • Page 21: Cleaning And Maintenance

    DM50NTE Cleaning and maintenance Cleaning and maintenance WARNING! Always disconnect the device from the power supply before you clean and service it. NOTICE! Risk of damage • Never clean the cooler under running water or in dish water. • Do not use abrasive cleaning agents or hard objects during cleaning as these can damage the cooler.

  • Page 22: Technical Data

    Technical data DM50NTE Technical data DM50NTE D DM50NTE F Voltage: 100 – 240 Vw, 50 – 60 Hz Cooling capacity: max. 21 °C below ambient temperature (adjustable in three steps: 5 °C, 7 °C, 12 °C) Category: 2 (Cellar) Gross capacity:...
  • Page 23 Dometic (Pty) Ltd. Dometic Austria GmbH MEXICO Regional Office Neudorferstraße 108 Dometic Mx, S. de R. L. de C. V. South Africa & Sub-Saharan Africa A-2353 Guntramsdorf Circuito Médicos No. 6 Local 1 2 Avalon Road  +43 2236 908070 Colonia Ciudad Satélite...
