TECHNICAL DATASHEET
Force-GT DIN Rail Power Supply
24 V 120 W 3 Phase / DRF-24V120W3GA
General Description
The Force-GT Series DIN rail industrial power supply features high power density and high efficiency. The Series offers overcurrent
protection in constant current mode, making it suitable for charging applications. Conformal coating is applied on the PCBAs to protect
against dust and pollutants often found in harsh industrial environments. The Series' electromagnetic radiated and conducted emissions
are compliant with heavy industrial Class B Emission standard and Immunity standard, and complies with environmental protection
standards RoHS Directive.
Model Information
Force-GT DIN Rail Power Supply
Model Number
DRF-24V120W3GA
Model Numbering
F –
DR
DIN Rail Product Series
F – Force
*
Options
B T*
All parameters are specified at 25°C ambient and AC input 3x unless otherwise indicated.
1
www.DeltaPSU.com (November 2023, Rev. 03)
Input Voltage Range
3 x 320-575 Vac (3-Phase) or
2 x 340-575 Vac (2-Phase)
24V
120W
Output Voltage Output Power Three Phase
Highlights & Features

Universal AC input voltage range

Built-in constant current circuit for charging applications

Full load operating temperature up to 55°C

Cold start at -40°C

Ultra-Slim design

Reduced no-load power consumption

Built-in DC OK relay and LED indicator

Conformal coating on PCBAs to protect against common dust
and pollutants
Safety Standards
CB Certified for worldwide use
Model Number:
Unit Weight:
Dimensions (H x W x D):
Rated Output Voltage
24 Vdc
3 G
G – General Type
DRF-24V120W3GA
0.54 kg (1.19 lb)
124 x 38 x 125.3 mm
(4.88 x 1.50 x 4.93 inch)
Rated Output Current
5.0 A

A
Connector Type Delta Standard
B – Screw Terminal
T – Spring Clamp
Terminal*
