Landoll Brillion PPF6-18 Operator's Manual

Floating ring pulverizer
Hide thumbs

Advertisement

Quick Links

Download this manual
'
Floating Ring Pulverizer
Models PPF6-18
Operator's and Parts Manual
LANDOLL COMPANY, LLC
1900 North Street
Marysville, Kansas 66508
(785) 562-5381
800-428-5655 ~ WWW.LANDOLL.COM
6K107-2408

Advertisement

loading
Need help?

Need help?

Do you have a question about the Brillion PPF6-18 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Landoll Brillion PPF6-18

Summary of Contents for Landoll Brillion PPF6-18

  • Page 1 ‘ Floating Ring Pulverizer Models PPF6-18 Operator’s and Parts Manual LANDOLL COMPANY, LLC 1900 North Street Marysville, Kansas 66508 (785) 562-5381 800-428-5655 ~ WWW.LANDOLL.COM 6K107-2408...
  • Page 2 Manuals for PPF Floating Ring Pulverizer Manual Number Manual Type 6K107 Operator’s and Parts Manual...
  • Page 3 DANGER DO NOT operate or perform any maintenance tasks on this equipment until you have completed the following: 1. Receive proper training to operate this equipment safely. 2. Read and understand the operator’s manual. 3. Be thoroughly trained on inspection and repair procedures. Failure to comply with this warning may result in serious injury or possibly death.
  • Page 5 INDEX Table of Contents Introduction and Safety Information Introduction ............1-1 Description of Unit .
  • Page 6 TABLE OF CONTENTS INDEX Warning Lamps ............4-4 Storage .
  • Page 7 Failure to comply with this warning can result in within 10 days of retail purchase, using the Landoll personal injury or death, damage to the Corporation Ag Products on-line registration process.
  • Page 8 TABLE OF CONTENTS INDEX Safety • Replace decals that become damaged or lost. Also, be sure that any new implement components installed during repair include decals which are assigned to NOTE them by the manufacturer. Investigation has shown that nearly 1/3 of all farm •...
  • Page 9 INDEX TABLE OF CONTENTS Safety Instructions for Towing Protective Equipment Vehicles • Wear protective clothing and equipment appropriate for the job. Avoid loose fitting clothing. The maximum travel speed is the lesser of • Because prolonged exposure to loud noise can •...
  • Page 10 TABLE OF CONTENTS INDEX Table provided for general use. NOTES: 6K107-2408...
  • Page 11 Chapter 2 INDEX TABLE OF CONTENTS Assembly IMPORTANT CAUTION All Harnesses must be firmly attached to machine Do not work on or under this machine unless frame members so they do not sag or become torn securely blocked and supported by a hoist or loose by field debris.
  • Page 12 TABLE OF CONTENTS INDEX 3-PT Hitch 3. Install SMV Mount 4" to 6" left of center on the back of the Frame Tube with 5/8-11 U-Bolt and Locknut. The PPF Floating Ring Pulverizer is shipped assembled Assemble SMV Sign to Mount with 5/16-18 x 1 Bolts, except for the Stand(s), SMV, Hitch Pins and Bushings, Flat Washers, and Locknuts.
  • Page 13 INDEX TABLE OF CONTENTS Flat Washer,5/16 SMV Sign Bushing, Bolt,5/16-18 x 1 1-1/4 x 1-15/16 Nut,5/16-18 Locknut, Clevis Pin, U-Bolt,5/8-11 x 1 x 4-1/2 8-3/4 x 7-11/16 Nut,5/8-11 Klik Pin Stand Bracket Bolt, Pin Asm, 1-8 x 4-1/2 1-1/8 x 9 Spacer, Hairpin 1.315 x 2-1/8...
  • Page 14 TABLE OF CONTENTS INDEX Warning Lamp Installation 5. Tighten all hardware. 6. Bundle and secure excess cords with Tie Wraps. 1. Orient the Angle Brackets so that when they are attached to the frame the lamps are outward. IMPORTANT Assemble the Angle Brackets as far as possible to All Harnesses must be firmly attached to machine each end of the Frame Tube with Straps,1/2-13 x frame members, so they do not sag or become torn...
  • Page 15 Chapter 3 INDEX TABLE OF CONTENTS Operation DANGER DANGER Never allow anyone a ride on the Pulverizer at any Always lock the tractor drawbar in the center time. Allowing a person to ride on the machine position when transporting the unit. Failure to do can inflict serious personal injury or death to that so can result in serious injury or death and cause person.
  • Page 16 TABLE OF CONTENTS INDEX Tractor Preparation 6. Attach Pulverizer to the Tractor's 3-PT Free Link or Quick Coupler using the appropriate size pins and The Brillion Pulverizer is designed to be used with a 3-PT bushings. Be sure to use the correct hardware and Hitch Category 2 or 3 Free Link or a Category 2, 3, 3N that it is in good working order.
  • Page 17 INDEX TABLE OF CONTENTS Upper Ø1" Pin Spacer position 23" Lower 1-1/8 Pin 32-1/2" Spacer Spacer 38-3/8" CATEGORY 2 FREE LINK Upper Ø1-1/4" Bushing Spacer Upper position Ø1" Pin 26" Lower Spacer Spacer 1-1/8 Pin 38-1/8" 44" Lower Lower Ø1-7/16" Bushing Ø1-7/16"...
  • Page 18 TABLE OF CONTENTS INDEX Spacer position Upper Ø1-1/4" Upper Bushing Ø1" Pin 15" Lower 1-1/8 Pin 32-1/2" Spacer Spacer 38-3/8" Lower Lower CATEGORY 2 Ø1-7/16" Bushing Ø1-7/16" Bushing QUICK COUPLER Spacer position Upper Ø1-1/4" Bushing Upper Ø1" Pin 19" Lower 1-1/8 Pin 32-1/2"...
  • Page 19 INDEX TABLE OF CONTENTS General Operation • When the Roller Assembly is installed in reverse as shown in Figure 3-3, the Roller Wheels will act more 1. The minimum horsepower requirement is based on like a rotary hoe and will have a tendency to loosen the the Pulverizer width.
  • Page 20 TABLE OF CONTENTS INDEX Transport 5. Connect the Safety Warning Lights 7-Pin Plug into tractor 7-Pin outlet, routing cord by avoiding pinch 1. Check and follow all federal, state, and local points. requirements before transporting the Pulverizer. 6. Check to see the tractor hitch capacity is rated to 2.
  • Page 21 Chapter 4 INDEX TABLE OF CONTENTS Maintenance General Torque Specifications (rev. 4/97) This chart provides tightening torques for general purpose applications when special torques are not specified on process or drawing. Assembly torques apply to plated nuts and capscrews assembled without supplemental lubrication (as received condition). They do not apply if special graphite moly-disulfide or other extreme pressure lubricants are used.
  • Page 22 TABLE OF CONTENTS INDEX Replacing or Adding Roller CAUTION Wheels Do not work on or under this machine unless 1. Attach tractor to the Pulverizer. Raise the Pulverizer securely blocked and supported by a hoist or to the transport position. With the pulverizer in the tractor or by other sufficient means.
  • Page 23 INDEX TABLE OF CONTENTS Roller Wheel Drum Drum Contacting Roller Wheels Parked Tractor With Locked Brakes 2" Min Pillow Block Blocks Bearing Figure 4-2: Replacing or Adding Roller Wheels - Detail Bolt,5/8-11 x 9-1/2 (PPF10-18) Frame Bolt,5/8-11 x 7-1/2 (PPF6-8) 4-Hole Plate Bearing Support Drum...
  • Page 24 TABLE OF CONTENTS INDEX Warning Lamps When connecting the 7-Pin Warning Lamp Connector: 1. Make sure the Tractor has a good clean Receptacle, free of dirt and corrosion. 2. Make sure the 7-Pin Connector is inserted ALL the way in. With tighter fitting pins, operator may think the Connector is all the way in, but it really isn’t.
  • Page 25 Chapter 5 INDEX TABLE OF CONTENTS Specifications Product Attributes PPF6B12 PPF8B12 PPF10B12 PPF12B12 PPF14B12 Approximate Weight 1,601 lbs. (720 kg) 2,020 lbs. (909 kg) 2,580 lbs. (1,161 kg) 3,056 lbs. (1,375 kg) 3,490 lbs. (1,571 kg) Working Width 6 ft. 0 in. (1.8 m) 8 ft.
  • Page 26 TABLE OF CONTENTS INDEX Table provided for general use. NOTES: 6K107-2408...
  • Page 27 Chapter 6 INDEX TABLE OF CONTENTS Instructions for Ordering Parts ** Repair parts must be ordered through an Authorized Dealer ** DEALER INSTRUCTIONS FOR ORDERING PARTS FROM LANDOLL PARTS DISTRIBUTION CENTER Phone #: 800-423-4320 785-562-5381 Fax #: 888-527-3909 Order online: dealer.landoll.com...
  • Page 28 Chapter 7 TABLE OF CONTENTS INDEX Illustrated Parts List Frame, PPF6-8 Figure 7-1: Frame, PPF6-8 6K107-2408...
  • Page 29 INDEX TABLE OF CONTENTS Frame, PPF6-8 ITEM PART NUMBER DESCRIPTION QTY. 5K812 TUBE (87-1/2") (PPF6) 5K811 TUBE (111-1/2") (PPF8) 7J375 BRACKET WLDMT STAND 1J801 U-BOLT 5 X 7 1-512-010005-13 NUT,HEX SLFLKG GRB 5/8-11 9D047 STAND WELDMENT 3C335 CLEVIS PIN, BENT 6C400 HAIR PIN COTTER 1-557-010362-65...
  • Page 30 TABLE OF CONTENTS INDEX Frame, PPF10-18 Figure 7-2: Frame, PPF10-18 6K107-2408...
  • Page 31 INDEX TABLE OF CONTENTS Frame, PPF10-18 ITEM PART NUMBER DESCRIPTION QTY. 5K766 FRAME WLDMT PPF PULVERIZER 4K989 EXTENSION, 1 FT WLDMT 4K990 EXTENSION, 2 FT WLDMT 4K991 EXTENSION, 3 FT WLDMT 6K309 EXTENSION 4' WLDMT 1-654-010061-07 SCREW,HX CP 3/4-10UNCX2-1/2G5 1-512-010005-15 NUT,HEX,SLFLKG GRB 3/4-10 7J375 BRACKET WLDMT STAND...
  • Page 32 TABLE OF CONTENTS INDEX Roller to Frame Assembly Figure 7-3: Roller to Frame Assembly, PPF10-18 6K107-2408...
  • Page 33 INDEX TABLE OF CONTENTS Figure 7-4: Roller to Frame Assembly, PPF6-8 Roller to Frame Assembly ITEM PART NUMBER DESCRIPTION 5K810 ROLLER ASSY - PPF6B12 (SEE PAGE 7-7) 5K809 ROLLER ASSY - PPF8B12 (SEE PAGE 7-7) 5K066 ROLLER ASSY 10-20-12 (SEE PAGE 7-7) 5K067 ROLLER ASSY 12-20-12 (SEE PAGE 7-7) 5K068...
  • Page 34 TABLE OF CONTENTS INDEX Roller Assembly Drum Length Figure 7-1: Roller Assembly Roller Assembly ITEM PART NUMBER DESCRIPTION MODELS 5K810 ROLLER ASSY - PPF6B12 5K809 ROLLER ASSY - PPF8B12 5K066 ROLLER ASSY 10-20-12 5K067 ROLLER ASSY 12-20-12 5K068 ROLLER ASSY 14-20-12 5K069 ROLLER ASSY 16-20-12 5K070...
  • Page 35 INDEX TABLE OF CONTENTS Warning Lamps Figure 7-2: Warning Lamps Warning Lamps ITEM PART NUMBER DESCRIPTION 4K938 WARNING LIGHT KIT - BRS/BRH (INCL. ITEMS 1-11, 13-14) 4K774 ANGLE 142758 AG LAMP, DUAL LH 142759 AG LAMP, DUAL RH - - - - - 15' WISHBONE AG HARNESS (2515) (NOT AVAILABLE) 4K936 10' AG HARNESS (NOT SHOWN)
  • Page 36 MANUFACTURERS A S S O C I A T I O N P/N: 232188 ITEM 5 ITEM 6 2P151 ITEM 7 2-573-010198 232188 Landoll Company, LLC Marysville, Kansas www.landoll.com MODEL # mile/h SERIAL # 144193 MADE IN USA 1-573-010006 ITEM 8...
  • Page 37 INDEX TABLE OF CONTENTS Decals ITEM PART NUMBER DESCRIPTION 8J309 DECAL - 'CAUTION' 528934 REFLECTOR - YELLOW (OLD 2J431) 528933 REFLECTOR - RED (OLD 2J430) 4K103 DECAL-BRILLION(3 3/4 X 16 3/4) 164678 MOUNT, SMV 2-573-010198 DECAL, MEMBER FEMA 232188 DECAL, QR CODE PULVERIZER 144193 DECAL, SIS 20 MPH 1-573-010006...
  • Page 38 TABLE OF CONTENTS INDEX Decal Locations Figure 7-4: Decal Locations, PPF6-8 7-11 6K107-2408...
  • Page 39 INDEX TABLE OF CONTENTS Figure 7-5: Decal Locations, PPF10-18 6K107-2408 7-12...
  • Page 40 TABLE OF CONTENTS INDEX Table provided for general use. NOTES: 7-13 6K107-2408...
  • Page 41 Chapter 12 INDEX TABLE OF CONTENTS Glossary For clarity this glossary of industry standard abbreviations and their definitions are provided. HHCS ....Hex Head Cap Screw HCS .
  • Page 42 TABLE OF CONTENTS INDEX RH ....... . Righthand RND ....... . . Round SER .
  • Page 43 Chapter 9 TABLE OF CONTENTS Index Numerics 2P151 ......7-2, 7-4 3C335 .
  • Page 44 TABLE OF CONTENTS INDEX 5K810 ......7-6, 7-7 5K811 ........7-2 5K812 .
  • Page 45 INDEX TABLE OF CONTENTS Table provided for general use. NOTES: 6K107-2408...
  • Page 46 Instructions for Ordering Parts ** Repair parts must be ordered through an Authorized Dealer ** DEALER INSTRUCTIONS FOR ORDERING PARTS FROM LANDOLL PARTS DISTRIBUTION CENTER Phone #: 800-423-4320 785-562-5381 Fax #: 888-527-3909 Order online: dealer.landoll.com DATA PLATE The Data Plate, which lists the model number and serial number, is located on the left side of the Floating Ring Pulvi-Mulcher.
  • Page 47 Document Control Revision Log: Date Form # Improvement(s): Description and Comments 11/2010 6K107-1110 Landoll Branding 08/2024 6K107-2408 ECN 50088 - Add Decals: QR Code, FEMA, 20MPH Update Template *Revised Format (Year/Month)
  • Page 48 Equipment from Landoll Company, LLC is built to exacting standards ensured by ISO 9001:2015 registration at all Landoll manufacturing facilities. Floating Ring Pulverizer Models PPF6-18 Operator’s and Parts Manual Re-Order Part Number 6K107 LANDOLL COMPANY, LLC 1900 North Street Marysville, Kansas 66508 (785) 562-5381 800-428-5655 ~ WWW.LANDOLL.COM...
