Tucsen Dhyana 9KTDI User Manual

Hide thumbs Also See for Dhyana 9KTDI:

Advertisement

Quick Links

Download this manual
Dhyana 9KTDI
User Manual
V1.3.3
Copyright (c) 2011-2023 Tucsen Photonics Co., Ltd.
All Rights Reserved.
Technical Support Email: service@tucsen.com
TEL: +86-591-28055080-818
Fax: +86-591-28055080-826

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dhyana 9KTDI and is the answer not in the manual?

Questions and answers

Related Manuals for Tucsen Dhyana 9KTDI

Summary of Contents for Tucsen Dhyana 9KTDI

  • Page 1 Dhyana 9KTDI User Manual V1.3.3 Copyright (c) 2011-2023 Tucsen Photonics Co., Ltd. All Rights Reserved. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 2 4.2. Spectral Response Curve ................35 4.3. Operation Mode and TDI Stages ..............35 4.4. DeviceScanType ..................36 4.5. Scan Direction ..................... 37 4.6. Pixel Format ....................38 4.7. Horizontal Flipped ..................38 Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 3 5.2. image capture ....................51 5.3. Parameters ....................53 5.3.1. DeviceControl ..................56 5.3.2. ImageFormatControl ................. 57 5.3.3. AcquisitionControl ................60 5.3.4. DigitalIOControl .................64 5.3.5. AnalogControl ..................64 5.3.6. LUTControl ..................65 5.3.7. CoolControl ..................67 5.3.8. DSNU ....................69 Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 4 7. After-sales ......................89 Appendix 1: Table of dew point corresponding to temperature and humidity .... 90 Appendix 2: Structural Dimensions ................91 Appendix 3: Camera Parameter Table ...............92 Appendix 4: Update Log .................... 94 Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 5 Under no circumstances shall TUCSEN be held liable for any losses or damages, whether direct, indirect, special, incidental, consequential, or otherwise, whether in tort or otherwise, resulting from or connected with the unauthorized use of the contents of this document.
  • Page 6 The trademarks 鑫图, TUCSEN, and any other related marks are the property of Tucsen. No one shall infringe the trademark rights of Tucsen. All other trademarks belong to their respective trademark owners, and Tucsen is not responsible for infringement by others.
  • Page 7 We wish you a pleasant user experience. Thank you! Tucsen Photonics Co., Ltd. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 8  Please ensure that there is at least a 20cm gap around the vents to allow proper airflow. Blocking the vents may cause overheating Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 9  If the voltage applied to the camera is higher or lower than the rated voltage, it may result in damage to the camera or cause it to Caution malfunction.  Please refer to the specification sheet included with the camera for the rated voltage. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 10 2. Product Specifications This section will introduce the specifications of the Dhyana 9KTDI camera, including the packing list, camera overview, chip characteristics, interface functions, and accessory list. 2.1. Package List Items Specification/ Model Pictures TDI Camera Dhyana 9KTDI Power cables...
  • Page 11 TDI levels and provides line frequencies of 510kHz at 8-bit, 368kHZ at 10-bit, and 299kHZ at 12-bit with full resolution output. The Dhyana 9KTDI camera can be easily programmed and updated in the field, adhering to the GenICam standard. Users can quickly operate the camera to acquire images that cater to diverse application scenarios.
  • Page 12 2.3. Interface and Functionality The Interfaces of the Dhyana 9KTDI are shown in Figure 2-2, and the corresponding Functional Descriptions are shown in Table 2-1. The pin definitions for the power and trigger interfaces, are shown in Figure 2-3, and the trigger input and output circuit diagrams are shown in Figure 2-4 and Figure 2-5."...
  • Page 13 CXP12 correspond to the frame grabber interface one by one. Description of the trigger interface Figure 2-2 Power and trigger pin definitions Default: rising edge trigger Figure 2-3 Trigger input circuit diagram Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 14 2) When the trigger level is higher than 2.6V, it is judged as high level; when the trigger level is lower than 0.6V, it is judged as low level; and 0.6-2.5V is an indeterminate state, which may indicate a disordered trigger state. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 15 3.1. Recommended Computer Configurations The computer configurations shown in this section are those that have been tested by our company and can support the highest resolution and highest line frequency of Dhyana 9KTDI Pro. It is for reference only. Configuration I Main components Details Intel Xeon Gold 5218 @ 2.30GHz...
  • Page 16 The brands and models of frame currently supported by the test are shown in Table Tab 3-2 Supported Frame Grabber Brand Model Firmware Driver Samadhi Quad CXP12 TUCSEN 1d1s TucsenSetup1.1.4.11.exe Frame Grabber Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 17 Connect one end of the CXP cable to the frame grabber and the other end to the Dhyana 9KTDI camera (it is recommended to use a removal tool to assist in installing the CXP cable). Lock the retaining ring, then plug in the power cable and turn on the power switch to see the light come on.
  • Page 18 3.4. Installation of Frame Grabber’s Driver This section describes the driver installation for the three brands of frame Grabbers currently supported. 3.4.1.Samadhi The Samadhi frame grabber driver is supported for installation on the Windows Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 19 2) Select the installation language. The options include ’Simplified Chinese’ and 'English' Click 'OK'. Figure 3-4 3) Choose the installation location. If you want to select a different folder, click 'Browse' After selection, click 'Next'. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 20 4) Select additional tasks, deciding whether to create a desktop shortcut; it is not checked by default. After making your choice, click 'Next'. Figure 3-6 5) Prepare for installation confirmation, check if the settings are correct. Once confirmed, click 'Install'. Figure 3-7 Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 21 7) After the Samadhi driver installation is complete, open the Device Manager on your computer. When the driver is installed successfully, the Samadhi frame grabber will appear under Device Manager, displaying 'Samadhi Coaxlink QSFP+', as shown in the image below: Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 22 The Kaya frame grabber only supports Windows 10 (x64). Currently, the followi ng compatible version 2023.1 is the recommended: KAYA_Vision_Point_Setup_2 023.1_SP_3_Windows_64.exe. Operation Steps 1) Double-click the KAYA frame grabber driver to begin the installation; 2) Click "Next" to proceed with the installation guide; Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 23 Figure 3-10 3) Select the driver installation location, use the default configuration, and click "Next"; Figure 3-11 4) Select the components to install and click "Next" to proceed to the next step; Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 24 Users can also choose other folders according to their needs, and click "Next>" to proceed to the next step; Figure 3-13 6) Confirm that all settings are correct and click "Install" to start the driver installation Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 25 Figure 3-14 7) During the installation process, click "Next" to continue the installation according to the prompts; Figure 3-15 8) Click "Finish" to proceed to the next step; Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 26 Figure 3-16 9) After the installation is complete, the software system needs to be restarted for the driver to take effect. Figure 3-17 Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 27 1) Double click on the driver to begin the installation, select the path and click "Next" to proceed to the next step; Figure 3-19 2) Wait for the installation to complete, and then click "OK"; Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 28 Home Edition. We recommend using the Professional version or Ultimate Edition for optimal performance. The following operation instructions are based on the Windows 10 operating system Installation Sequence: 1) mlxv2102x64_fic.exe 2) MLiteXSP5B728EAx64 Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 29 2) Wait for the installation to complete, and click "OK" as shown in the picture to proceed to the next step; Figure 3-23 3) Select “Matrox Rapixo CXP” and click "Next" to wait for the installation to complete; Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 30 Figure 3-24 4) Select U118 for installation, open the frame grabber software after installation to update the firmware, and restart the computer. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 31 For software functions and operating instructions, please refer to Chapter Note: 1) When running for the first time, right-click on the SamplePro software icon, and select "Run as administrator" from the pop-up menu.; Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 32 Water-cooling Tubes Connection Steps 1) LLoosen the 2 M3 screws on the camera's cover and remove the water-cooled pipe protective cover, as shown in Figures 3-20 and 3-21. Figure 3-27 Figure 3-28 Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 33 When you are finished using it, press the left circular handle at the same time to detach the water tube. Figure 3-29 Figure 3-30 3) Connect to the water cooler with the connector shown below; Figure 3-31 Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 34 For example, when the ambient temperature is 25°C and the relative humidity is 70%, the water temperature should not be lower than 19°C. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 35 2) When imaging moving targets with TDI, it allows for increased scanning speed under limited light intensity or reduced brightness of the illumination source during constant-speed scanning. This reduces power consumption and lowers costs. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 36 256 implies that the line data has been integrated 256 times. On the other hand, in area mode, the "TDI Stages" parameter dictates the height of the Dhyana 9KTDI Pro. Specifically, setting the "Operation Mode" to "Area" and adjusting the "TDI Stages" to 256 enables the camera to capture images with a resolution of 9072×256.
  • Page 37 N lines. This increases the effective bandwidth, allowing the Areascan mode to operate at a higher line frequency with the same resolution and other configurations." Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 38 In TDI mode, the "Scan Direction" parameter is used to set the scanning direction of the Dhyana 9KTDI. The Dhyana 9KTDI scans in the default forward direction, as shown in Figure 4-4. Users can adjust the installation direction of the camera according to their usage environment.
  • Page 39 When selecting Mono10 and Mono12, the image properties display as 16 bits (zero-padded high bits). 4.7. Horizontal Flipped The Dhyana 9KTDI camera can achieve horizontal mirroring through the "Reverse X" function, which can be used in Area and TDI modes. Figure 4-5 Original image Figure 4-6 “Reverse X”...
  • Page 40 BinningVertical supports X1, X2, X4, and X8. When set to X2, the image resolution remains unchanged while the frame rate is halved. SensorBinning supports X1 and X2. When set to X2, both the image resolution and frame rate remain unchanged. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 41 AnalogGain modes. 4.10. Gain & Black Level The "Gain" parameter adjusts the slope of the Dhyana 9KTDI's light response curve, thereby enhancing or reducing the grayscale values of the camera's output image. When it is difficult to see the object to be photographed under weak signal conditions, you can increase the "Gain"...
  • Page 42 255-14=241. Different chips may have slightly different specific values. If a gray value of 255 is required, DSNU should be turned off or BlackLevel should be used with the corresponding value. The same applies for 12bit. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 43 Figure 4-7 LUT at Gamma=0.8 4.12. Dark Field Correction (DSNU) Dhyana 9KTDI provides DSNU correction function and storage of DSNU correction values. When a camera captures an image in complete darkness, in an ideal image, all pixel grayscale values should be close to zero and equal. However, in practice, when a Technical Support Email: service@tucsen.com...
  • Page 44 Figure 4-8 dark field gray value without corrected Figure 4-9 dark field gray value with corrected 4.13. Bright Field Correction(PRNU) Dhyana 9KTDI provides PRNU correction function and storage of PRNU correction values. When a camera captures a uniform, light-colored target in bright light, in an ideal image, all pixel grayscale values should be close to the maximum grayscale value and equal.
  • Page 45 (effective under Timed). 4.15. Test Patterns To check the status of the camera, the Dhyana 9KTDI can output a test pattern created internally. There are three types of test modes:  Grey Horizontal Ramp: the preview is a static grayscale gradient in the horizontal direction.
  • Page 46  Grey Diagonal Ramp Moving: preview as a grayscale gradient map of the movement in the horizontal diagonal diagonal direction. Direction Figure 4-14 Horizontal grayscale diagonal moving gradient test pattern  Sensor Test Image:Preview is a horizontal static grayscale gradient.。 Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 47 4.16. Firmware Upgrade The Dhyana9KTDI camera can be updated with firmware online through the "UpdateTool" software. Figure 4-16 Update Tool interface Tool Preparation: Software: UpdateTool; Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 48 4) After the update is complete, power off and restart the camera for the new firmware to take effect, or use the software's "DeviceReset" to restart it; 5) After the camera is rebooted, confirm that the DeviceVersion matches the firmware being upgraded, indicating a successful upgrade. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 49 The main interface of SamplePro software consists of five parts: "Preview Window", "Software Window", "Image Capture", "Device Parameters" ,”Software Log” and "Image Adjustment", as shown in Figure 5-2. This section briefly introduces the functions of each window. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 50 The preview window displays the live camera feed under the streaming module. The preview window supports real-time zooming, allowing users to enlarge or shrink the preview window image through the mouse wheel based on their actual needs. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 51 Users can expand and use the corresponding function modules according to their needs. 5.1.5.Image Adjustment Users can adjust the image gamma value, contrast value, and set left and right color Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 52 This section provides a detailed introduction to the functions of the image capture module, including the steps for some functions. As shown in Figure 5-6, the image capture module supports the basic camera functions of taking pictures and recording videos. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 53 1) When storing RAW format images, the first 1024 bytes of data are header information for the image, which needs to be skipped. 2) When storing tif format images, all image adjustment algorithms need to be set to Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 54 "Device Properties" is the parameter setting module for the camera, and "Steam Properties" is the parameter setting module for the frame grabber. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 55 Every time LIVE opens the stream, it needs to skip the first 3000 lines (8&10bit) or 1500 lines (12bit). Because the sensor is always exposed, the charge will keep accumulating, leading to overexposure of the first 300 lines. Waiting for 3000 lines or Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 56 5) Apply: When multiple cameras are connected, you can apply the current camera's device parameters to other cameras while in a stopped state. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 57 5.3.1.DeviceControl Figure 5-8 It is used to display camera parameter information and settings, including basic information (read-only), UserID settings, camera reset, temperature display for the Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 58 This module can be used to set the width, starting OffsetX, OffsetY, horizontal, vertical binning, horizontal mirroring, bit depth switching, test mode, line scanning direction, TDI stage, and other settings for images. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 59 Height: Set the vertical height of the image. It cannot be set to 1 in Linescan. The actual vertical resolution of the image is Height * BufferHeight. Areascan can be set to a maximum of 32768. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 60 LineIn (externally triggered control) modes. Users can switch modes based on actual usage scenarios to match the line scanning direction. TDIStagesP1: TDI stage P1 array setting. Supports 4, 8, 16, 32, 64, 96, 128, 160, 192, Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 61 This module is used to set the camera's motion mode, line frequency, external trigger mode, trigger readjustment, and output mode, as well as trigger statistics display, etc. The settings interface is shown in Figure 5-10. Figure 5-10 Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 62 13.9ns. For instance, when set to 100 in 12bit, the actual value is: 100/13.9 ≈ 7.2 >> 13.9*7 = 97.3ns. This means that the reversing signal must last for 97.3 ns to trigger a change in direction. Increasing this value will result in a synchronous increase in the Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 63 OperationMode: Mode selection, supports TDI and Area modes. Area mode is recommended for focusing on fixed object distances for still images. ExposureTime: exposure time adjustment in the Area mode, can be entered from 1 to 10000ms; SoftTrigger:Soft trigger command button; Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 64 2) This situation can also occur when the signal is within a reasonable range, but due to the quality of signal transmission, the time interval between the two trigger edges is less than the minimum line period; Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 65 StrobeDuration:High-level output signal time (effective under Timed mode)us; 5.3.5.AnalogControl This function module is used to set the analog and digital gain of the camera and adjust the black level as shown in Figure 5-13. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 66 LUTIndex: Input value, which is automatically loaded with the output value corresponding to the applied curve after input, in the range 0 to 4095; LUTValue: Output value, loaded according to the inputted LUTIndex value, can be Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 67 Download: Configuration of the currently applied LUT curve into the camera; Upload: Loading and reading the applied LUT curve from the camera (the LUT curve needs to be saved in SamplePro before it can be loaded and read); Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 68 3) Click “Apply” to apply the selected curve; 4) Click “Download” to configure the curve into the camera. 5.3.7.CoolControl It is used to set the cooling function of the camera. The setting interface is shown in Figure 5-16. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 69 "Temperature" mode, while other modes continue to run at 100% and the TEC continues to turn off until the parameters are reset; 3) When set to the "Temperature" mode, the FanDutyFactor and TECDutyFactor are not applicable. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 70 DSNUSave: Save the current DSNU results to non-volatile memory, which will not be lost during power off. The next time, the saved DSNU data can be directly loaded and used from the non-volatile memory; DSNULoad: loads the saved DSNU data from non-volatile storage; Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 71 3) If you choose DSNUGenerate, you need to re-calibrate DSNU when switching gain modes or bit depth; 5.3.9.PRNU DSNU is used to calibrate the Photo Response Non-Uniformity of the camera, and the settings interface is shown in Figure 5-18. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 72 PRNUSave: Save the current PRNU results to non-volatile memory and bind with the selected PRNUSelector parameters; PRNULoad: Load the PRNU correction data of the selected PRNU number from the non-volatile memory into the memory based on the PRNUSelector selection; Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 73 4) Correction should be performed under bright uniform light brightness. 5.3.10. CorrectionControl The CorrectionControl module is used to modify the corrected DSNU and RPNU values. The setup interface is shown in Figure 5-19; Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 74 (example: under PRNU, the average gray value of the image is 2000, set PRNUCoef=1.024, then after Correction, the average gray value of the image is 2048); PRNUCoefSet: Configuration according to the set PRNUCoef value; Note: Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 75 This module is used to display and set up the connection to the CXP. The setup interface is shown in Figure 5-20. Figure 5-20 :CXP default connection setting; :CXP mode switching, default CXP12_X4, Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 76 UserSetSave: Saves the modified configuration parameters in the camera configuration selected by UserSetSelector. Saving is invalid when Default is selected; UserSetDefault: A set of user configurations that are loaded by default after the Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 77 The maximum BufferHeight can be set to 65535. When the camera mode is set to "Area", the BufferHeight value is recommended to be set to an integer multiple of 256. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 78 FPGA. 3.3-V io_out[0] Optically isolated outputs LVTTL 3.3-V io_out[1] Optically isolated outputs LVTTL 3.3-V io_out[2] Optically isolated outputs LVTTL 3.3-V io_out[3] Optically isolated outputs LVTTL io_in[0] 3.3-V Optically isolated inputs Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 79 Reference ground signal - Board GND gpio_vt[0] gpio_vt[1] gpio_vt[2] gpio_vt[3] 3.3-V gpio[0] LVTTL General Purpose IO 3.3-V gpio[1] LVTTL 3.3-V gpio[2] LVTTL 3.3-V gpio[3] LVTTL Figure 5-24 KAYA Frame Grabber Interface Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 80 Figure 5-25 1) Under Camera Trigger Activation, select the trigger polarity RisingEdge, FallingEdge, and AllEdge according to the trigger needs; Select according to interface definition under Camera Trigger Source (TTL1 is recommended). Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 81 TTL input/output #12 Ground DIN11- High-speed differential input #11- Negative pole DIN11+ High-speed differential input #11 - Positive pole IIN12- Isolated input #12 - Negative pole IOUT11- Isolated contact output #11 - Negative pole Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 82 25TTLIO11, ground pin connected to 24GND; 2) Open the Eureysys acquisition card Demo software setting interface as follows; 3) Under Device, you need to set CameraControlMethod to RC (frame grabber trigger mode); Figure 5-27 Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 83 Figure 5-28 5) Under Stream, the corresponding setting is LIN1; Figure 5-29 After the setup, configure the bit depth and resolution of the camera, and use the trigger board to generate an image. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 84 Default: Clicking the "Default" button will restore the parameters of the image adjustment module to the default values set by the software. Note: When capturing images in the TIFF format, it is necessary to set the parameters to Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 85 "Default" to ensure that the saved images are not processed by any algorithms. Otherwise, the saved images will be processed and may not reflect the original captured data. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 86 Transmission bandwidth: The default is CXP12_X4. When the bandwidth is insufficient, the software will automatically reduce it, and the line speed will be limited.limited. When the TDI Stage is less than 256, which rows of data on Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 87 What is the maximum length of CXP cable? The recommended maximum distance is 20 meters. For longer distances, consider the Dhyana 9KTDI, which uses a fiber optic port to support longer distances. How is the frame rate calculated in Area mode? Actual results may vary due to computer performance fluctuations Technical Support Email: service@tucsen.com...
  • Page 88 Frame period = FPGA internal logic time + exposure time FPGA internal logic time = (4096 / maximum line frequency * 0.9) ms For example, Dhyana 9KTDI PRO quad channel (CXP12*2), TDI stage is 256, resolution 2272 (W) * 10000 (H), exposure time is 10ms FPGA internal logic time = (4096 / 600 * 0.9) = 7.585185 ms...
  • Page 89 This is a normal phenomenon due to the inherent characteristics of the sensor. When the camera outputs an 8-bit image, how is each gray value converted from 10-bit to 8-bit? Take the upper 8 bits of the 10-bit data. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 90 3) Contact a professional for technical support:  Tel: 400-075-8880 +86 591-88194580-811  Email: service@tucsen.com  Tucsen's website to leave a message: http://www.tucsen.com . 4) Please prepare the following information in advance:  Camera model and S/N (product serial number);...
  • Page 91 20.3 22.3 10.5 13.9 16.7 19.1 21.3 23.2 11.4 14.8 17.6 20.1 22.3 24.2 12.3 15.7 18.6 21.1 23.3 25.2 13.2 16.6 19.5 22.0 24.2 26.2 14.0 17.5 20.4 23.0 25.2 27.2 Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 92 Appendix 2: Structural Dimensions Unit: mm，Diameter: ø Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 93 ~ x10 step 1 DSNU 1.5e-@12bit; 3.5e-@10bit(Typ.) PRNU 0.3% (Typ.) Cooling Method AIr & liquid cooling Air 20 ℃ (ambient temperature 25 ℃); Temperature Differences Water 35 ℃ (water temperature 20 ℃) Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 94 8bit; 10bit; 12bit Optiona Interface M72 x1 Power Supply 12V±1V/5A Dimensions 86mm*86mm*109mm Software SamplePro; Matlab Operating System Windows; Linux Operating Environment Temperature: 0-40°C，Humidity: 0%-90% * Values are estimated based on the QE curve. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 95 7. Added description of the threshold adjustment function for scanning signal trigger high levels. 8. Added description of the DSNU/PRNU operation counter function. 9. Added Description of skipping the first part of the data before opening the flow. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
  • Page 96 1. Added compatibility information for the Samadhi capture card; V1.3.3 20241024 2. Updated user manual for the new version of Samplepro; 3. Added explanation for the Sensor Binning feature； 4. Corrected TDI stage information; Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
