- Page 1 FL 9BW User Manual V1.0.0 Copyright 2011-2024 Tucsen Photonics Co., Ltd. All rights reserved. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
-
Page 2: Table Of Contents
3.15.2. Trigger Output Timing Diagram ....................... 25 3.16. Cooling ..............................26 4. Installation ..............................28 4.1. Camera installation ............................ 28 4.1.1. Camera USB driver installation ......................29 4.2. Software installation and uninstallation ....................31 Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... - Page 3 Appendix 1 : Dimensions ..........................41 Appendix 2 : Specifications ..........................42 Appendix 3 : Third party software applications ....................44 Appendix 4 : Third party certification ......................45 Appendix 5 : Update log ..........................46 Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
-
Page 4: Introduction
In any case, TUCSEN shall not be liable for any losses or damages arising from or related to the unauthorized use of the content of this document, whether direct, indirect, special, incidental, consequential or other reasons, whether caused by infringement or other reasons. - Page 5 3) This document may contain technical or printing errors. Under no circumstances shall TUCSEN be liable for any loss or damage caused by unauthorized use of the content of this document, whether direct, indirect, special, incidental, consequential or otherwise.
-
Page 6: Safety And Warning Information
⚫ Please ensure that there is at least 10 cm of space around the device ventilation opening to ensure airflow flow. Do not block the ventilation openings of the equipment during use, otherwise it may cause internal temperature to be too high and damage the equipment. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... - Page 7 ⚫ If the voltage applied to the camera is greater than or less than the nominal voltage of the camera, the camera may be damaged or malfunction. Caution ⚫ Please refer to the specification table for the nominal voltage of the camera. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
-
Page 8: Product Specifications
USB 3.0 data cable USB flash drive Software and Drivers Silver cross recessed pad screw (cross recessed M3*14 mm head with pad screw) M3*6+3 mm; Diameter of Hexagon socket cap screw opposite side:Ф4.7 mm Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... -
Page 9: Quantum Efficiency Curve
2.2. Quantum efficiency curve Figure 2-1 Quantum efficiency curve of FL 9BW 2.3. Window curve Figure 2-2 Transmission curve of a standard glass window Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... -
Page 10: Camera Power And Signal Connection
If the software has been shut down but the camera light remains orange, it indicates that the camera has not been fully released and needs to be completely exited from the camera thread or be repowered before the indicator light will return to red. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... -
Page 11: Features And Functions
3. Features and Functions 3.1. Camera Introduction FL 9BW is Tucsen's new generation deep-cooled CMOS camera developed specifically for long exposure applications. It utilizes Sony's latest back-illuminated CMOS chip technology, offering high sensitivity and speed typical of modern CMOS sensors. Integrated with advanced Tucsen cooling and noise reduction technologies, it achieves dark current levels comparable to traditional CCDs, supporting exposures as long as 60 minutes. -
Page 12: Shutter Mode
USB, Ethernet, etc. 3.3. Shutter Mode The FL 9BW camera uses a rolling shutter readout mode. In this mode, the camera reads out rows sequentially, with consistent exposure time for each row, but different starting exposure time point for different rows. -
Page 13: Front-Illuminated And Back-Illuminated Cmos Technology
Due to the thin photosensitive silicon layer of back-illuminated pixels, there are higher process requirements and production difficulties compared to front-illuminated ones. The FL 9BW camera adopts a back-illuminated chip, achieving a peak QE of around 92%. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818... -
Page 14: Readout Noise
CMOS camera chip—having less impact on the median than on the RMS—median values are generally lower than RMS values. Figure 3-5 Readout noise distribution of an typical CMOS camera Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... -
Page 15: Defective Pixel Correction (Dpc)
3.7. Gain Mode The FL 9BW camera has three gain modes: Low Noise (16Bit) mode, Low Noise (14Bit) mode and Standard mode. In each mode, there are four selectable gain values. Each mode has differences in line times and readout noise. -
Page 16: Region Of Interest Readout
4, and the column window must be a multiple of 8. Typical ROI area measured frame rate (fps) table for FL 9BW camera under USB 3.0 is as follows: Table 3-2... -
Page 17: Binning Readout
Note: 1) The minimum supported ROI for FL 9BW on Mosaic V3 is 32 (columns) × 32(rows). 2) Frame rates are affected by computer system configuration, and it is recommended to use a computer with an i5 processor or above and a 64-bit system. -
Page 18: Timestamp
.csv format files. Figure 3-8 Timestamp export schematic Note: Applications requiring timestamp functionality generally have high time precision requirements, and it is recommended to use the To RAM image storage mode. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... -
Page 19: Frame Rate Calculation
Vn: The number of rows selected vertically; : Line time; line : 19 fps(Maximum frame rate at full frame in U3) Table 3-3 Calculation of frame rate for FL 9BW camera in USB3.0 Gain mode Line time Calculation formula Horizontal... -
Page 20: Frame Rate Adjustment
Where:P represents the incident number of photons.DN is the grayscale value of the light signal. K is the system gain (refer to Table 3-1) in (DN/e-). Q(λ) corresponds to the quantum efficiency at the wavelength.Offset s the camera's background value in DN. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... -
Page 21: Acquisition Mode
Figure 3-11 In the acquisition module, users can set the save path, file name, total number of frames and other information, and the image can be taken after the setting is completed. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... -
Page 22: Software Trigger Mode
Hardware trigger mode waits for an external level trigger signal command to capture an image. The Mosaic V3 software provides configurations such as mode, frames/signal, exposure, edge, exposure delay, etc., to control the number of triggered images captured continuously Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... - Page 23 8 to 12 line times T from when the camera logic receives the trigger signal to when the first row starts actual exposure. Therefore, the total Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
- Page 24 Level trigger mode is not continuous shooting; it is commonly used to capture stationary or slowly moving objects. Figure 3-17 Level Trigger timing diagram Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
- Page 25 Figure 3-18 Edge Trigger timing diagram FL 9BW camera supports single-trigger multi-frame acquisition function, you can modify the number of triggering out of the picture by setting the frame/signal in the standard triggering...
-
Page 26: Trigger Output
The camera uses a Hirose interface for trigger output, with the trigger output signal corresponding to pin 4, pin 5, and pin 6. It can output the following five types of signal timing. Figure 3-21 Trigger output timing diagram Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... -
Page 27: Cooling
The cooling module is placed close to the chip to lower the chip's temperature and reduce dark current, while the hot end is connected to a metal heat sink to dissipate heat efficiently. FL 9BW camera supports air cooling modes，the inlet and outlet vents are indicated as shown in the figure. - Page 28 In applications with high environmental temperature and humidity (e.g., >70%), the FL 9BW will not condense if the temperature difference is within 50°C as the cooling temperature lowers (by default, -25°C will not cause condensation).
-
Page 29: Installation
4. Installation 4.1. Camera installation Figure 4-1 FL 9BW camera connection diagram ① FL 9BW camera ② Power adapter ③ USB 3.0 data cable Connect one end of the USB 3.0 data cable or CameraLink data cable to the PC, and connect the USB to the USB 3.0 interface on the back of the host. -
Page 30: Camera Usb Driver Installation
(4) Selecting the contents of the installation, by default check the box to install Microsoft runtime libraries vcredist_2008 and vcredist_2013, unchecking the box may result in the software or third-party plug-ins not working; Figure 4-3 Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... - Page 31 If a yellow symbol appears, it indicates that the driver needs to be reinstalled. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
-
Page 32: Software Installation And Uninstallation
(3) Select the installation content. By default, select the option to install drivers and Microsoft runtime library vc-redist_2015, canceling the installation can result in the camera not being recognized by the software; Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... - Page 33 Figure 4-8 (4) Configure installation parameters and select whether to generate desktop shortcuts; Figure 4-9 (5) After confirming all installation parameters, click "Install" to start executing the installation action; Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
-
Page 34: Uninstallation
There are three ways to uninstall Mosaic software: (1) By uninstalling through the installation package, the existing version on the computer will be uninstalled when the installation package runs, and the default C drive path will take effect; Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... - Page 35 (2) Under the installation path, find unins000.exe to uninstall, double-click uninstall; Figure 4-13 (3) Uninstall from the computer program management interface; Note: After uninstalling and reinstalling the software, all software configuration information and calibration table data will be deleted. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
-
Page 36: Maintenance
3) Use dust-free cotton swabs dipped in an appropriate amount of anhydrous ethanol to wipe along the surface of the window film, do not use too much force when wiping, and always in one direction, avoid back and forth wipe; Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... - Page 37 2) If the dirt still exists after following the above steps, try wiping again by following the above steps. If this does not solve the problem, consider that the chip is internally dirty. Please be sure to contact us at this time. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
-
Page 38: Troubleshooting
2) Confirm whether the exposure time affects the frame rate, and set the minimum exposure time to confirm the frame rate; 3) The frame rate in the table is the measured frame rate under ideal bandwidth, and the Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... - Page 39 4) If you are using the USB3.0 interface but have switched to HUB/extension/expansion operations, it will also result in the inability to achieve the nominal frame rate; Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
-
Page 40: Faqs
If it is an ambient light source, switching off the illumination source is sufficient. If from an irradiated sample light source, a regulated light source is required for illumination. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... -
Page 41: After-Sales Support
3) Contact professionals for technical support: ⚫ TEL: +86-591-28055080-818 ⚫ Email: service@tucsen.com ⚫ Visiting the official website to leave a message: http://www.tucsen.com 4) Please prepare the following information in advance: ⚫ Camera model and S/N (product serial number); ⚫ Software version number and computer system information;... -
Page 42: Appendix 1 : Dimensions
Appendix 1 : Dimensions Unit: mm, Diameter: ø. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... -
Page 43: Appendix 2 : Specifications
Binning 2 x 2 , 3 x 3 , 4 x 4 , 6 x 6 , 8 x 8 , 12 x 12 , 16 x 16 , 24 x 24 Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... - Page 44 C, C++, C#, Python Operating System Windows/Linux Operating: Temperature 0~40℃, Humidity 10~85% Operating Environment Storage: Temperature -10~60℃, Humidity 0~85% Note: The parameters in this table are typical values and are subject to change without notice. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
-
Page 45: Appendix 3 : Third Party Software Applications
Appendix 3 : Third party software applications Provide plugins for calling third-party software (LabVIEW, Matlab, Micro-Manager, etc.), please Tucsen camera software download - click on the link to download the configuration: Tucsen Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... -
Page 46: Appendix 4 : Third Party Certification
Appendix 4 : Third party certification Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826... -
Page 47: Appendix 5 : Update Log
Appendix 5 : Update log Version Date Modified Content V1.0.0 2024-2-26 Create this document. Technical Support Email: service@tucsen.com TEL: +86-591-28055080-818 Fax: +86-591-28055080-826...
