- Page 1 Cosel LDA30F-5 AC-DC Power Supply Limited Availability Used and in Excellent Condition Open Web Page https://www.artisantg.com/59690-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
- Page 2 Basic Characteristics Data Basic Characteristics Data Series/Parallel Inrush Switching Input PCB/Pattern Rated operation availability current Model Circuit method frequency current protection input fuse Single Double Series Parallel Material [kHz] operation operation circuit sided sided LDA10F Flyback converter 45 - 400 0.25 250V 2A Thermistor...
- Page 3 AC-DC Power Supplies Open Frame/Enclosed type Instruction Manual Terminal Block LDA-20 Function LDA-21 LDA-21 Input voltage range LDA-21 Inrush current limiting LDA-21 Overcurrent protection LDA-21 Overvoltage protection LDA-22 Output voltage adjustment range LDA-22 Isolation LDA-22 Remote ON/OFF LDA-22 Remote sensing Series Operation and Parallel Operation LDA-23 Assembling and Installation Method...
- Page 4 Instruction Manual AC-DC Power Supplies Open Frame/Enclosed type lLDA75F 1 Terminal Block lLDA10F AC(L) AC(N) +Output -Output Frame ground lLDA100W AC(L) -Output AC(N) Frame ground +Output lLDA15F AC(L) AC(N) +Output -Output Frame ground lLDA150W AC(L) -Output AC(N) Frame ground +Output lLDA30F AC(L) AC(N)
- Page 5 Instruction Manual AC-DC Power Supplies Open Frame/Enclosed type 2.3 Overcurrent protection 2 Function Overcurrent protection is built-in and comes into effect at over 105% of the rated current. Overcurrent protection prevents the unit from short circuit and overcurrent condition. The unit auto- 2.1 Input voltage range matically recovers when the fault condition is cleared.
- Page 6 Instruction Manual AC-DC Power Supplies Open Frame/Enclosed type nWhen external power source is in the range of 4.5 - 12V 2.5 Output voltage adjustment range (LDA300W : 4.5 - 12.5V), current limit resistance R is not re- LDA10F - LDA75F quired.
- Page 7 Instruction Manual AC-DC Power Supplies Open Frame/Enclosed type (2) When using remote sensing function Even a slight difference in output voltage can affect the balance between the values of I and I . Use twisted-pair wire or shielded wire Please make sure that the value of I does not exceed the rated current of a power supply.
- Page 8 Instruction Manual AC-DC Power Supplies Open Frame/Enclosed type lLDA15F 4 Assembling and Installation Method 4.1 Installation method When two or more power supplies are used side by side, position them with proper intervals to allow enough air ventilation. Ambient temperature around each power supply should not exceed the temperature range shown in derating curve.
- Page 9 Instruction Manual AC-DC Power Supplies Open Frame/Enclosed type lLDA100W Mounting method Normal position lLDA150W lLDA300W Part A Note: Ventilation is required so that part A of heat sink is below 85 lLDA300W any case. Please flow air to the components to the direction of Air or Air .
- Page 10 Instruction Manual AC-DC Power Supplies Open Frame/Enclosed type lLDA15F - LDA50F lLDA10F LDA15F lLDA75F - LDA150W lLDA30F - LDA75F lLDA100W - LDA300W lLDA300W 26 10 Unit[mm] 6 Others nKeep isolation distance between screw and internal components in case of option ”-S”, ”-SN”, as below chart. This power supply is the rugged PCB type.
