Assembly instructions
DE
ACHTUNG! WICHTIGE SICHERHEITSANWEISUNGEN!
Den Hinweisen auf Seite 3 dieser Montageanleitung ist Folge zu
leisten.
GB
ATTENTION! IMPORTANT SAFETY INFORMATION!
Follow the instructions on page 3 of this manual.
FR
ATTENTION! IMPORTANTES INDICATIONS DE SÉCURITÉ!
Les instructions de la page 3 de cette notice de montage doivent
être observées strictement,
NL
LET OP! BELANGRIJKE VEILIGHEIDSINSTRUCTIES!
Volg de instructies op pagina 3 van deze montagehandleiding
op.
IT
ATTENZIONE! INDICAZIONI SULLA SICUREZZA
IMPORTANTI!
Prestare attenzione alle note alla pagina 3 delle presenti
istruzioni di montaggio.
ES
ATENCIÓN INDICACIONES IMPORTANTES DE SEGURIDAD!
Deben seguirse las indicaciones detalladas en página 3 de
estas instrucciones de montaje.
Installation, commissioning, utilization and maintenance
Attention
Important Safety
Information
These instructions must
be observed to ensure
personal safety.
Store these instructions
safely.

Advertisement

loading
Need help?

Need help?

Do you have a question about the TST FUZ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Feig Electronic TST FUZ

Summary of Contents for Feig Electronic TST FUZ

  • Page 1 Assembly instructions Installation, commissioning, utilization and maintenance Attention Important Safety Information These instructions must be observed to ensure personal safety. Store these instructions safely. ACHTUNG! WICHTIGE SICHERHEITSANWEISUNGEN! Den Hinweisen auf Seite 3 dieser Montageanleitung ist Folge zu leisten. ATTENTION! IMPORTANT SAFETY INFORMATION! Follow the instructions on page 3 of this manual.
  • Page 2 This Manual is directed especially at persons involved with starting up / commissioning the TST FUZ door controller of FEIG ELECTRONIC GmbH. The installation and commissioning of the controller shall only be carried out by officially trained electrical experts who are familiar with the safety standards of electrical drive and automation technology.
  • Page 3 Voor de veiligheid van personen is het belangrijk om deze aanwijzingen op te volgen. Deze aanwijzingen dienen bewaard te worden. Deze montagehandleiding kunt u vinden als download op www.feig.de. Gelieve de volgende toegangsgegevens te gebruiken: gebruikersnaam: Download / wachtwoord: feig FEIG ELECTRONIC GmbH Page 3 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 4 … with absolute encoder or incremental encoder..............25 … with mechanical limit switches .................... 26 Renewed request for "learning" end positions............... 27 Boost / increase in performance for low speeds ..............27 FEIG ELECTRONIC GmbH Page 4 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 5 Pre limit switch setting ......................31 10.4 Ramp configuration ........................31 10.5 Correction of the final positions ....................31 10.6 Speed-distance profile ....................... 31 Overview of messages Information messages Specifications EC- Declaration of conformity FEIG ELECTRONIC GmbH Page 5 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 6 EN 13241. A fully integrated frequency converter with power output stage can gently control the door with variable opening and closing speeds. The control system TST FUZ is designed to handle electrical induction motors with a power consumption of up to 0,75 kW and a 230 V supply.
  • Page 7 The manufacturer has carefully checked and inspected the device hardware and software, but no warranty is given for a complete absence of errors Dispose of the product at the end of its life cycle in accordance with the applicable statutory provisions. FEIG ELECTRONIC GmbH Page 7 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 8 • It is important to ensure that the controller is installed with the wall spacers that are supplied to guarantee that the power stage can dissipate heat as necessary. FEIG ELECTRONIC GmbH Page 8 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 9 When moving the door in deadman mode, ensure that the operator has an unobstructed view of the door area, since in this mode safety equipment such as safety edge and photo eyes are defeated. FEIG ELECTRONIC GmbH Page 9 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 10 Assembly Instructions FUZ-A 4.1 Installation position of the cover Figure 1: Foil key pad connection FEIG ELECTRONIC GmbH Seite 10 von 45 FUZ-A_Montageanleitung_5_GB...
  • Page 11 1 2 3 PE PE PE PE The power plug must be visible and accessible from the control system. CEE plug 3-poles, Fuse blue 16 A / K-Typ Figure 2: Connecting the power cable FEIG ELECTRONIC GmbH Page 11 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 12 In the case of drive units with an electronic brake, ensure that the brake is equipped with adequate suppression. We recommend the use of RC-elements for interference suppression purposes. FEIG ELECTRONIC GmbH Seite 12 von 45 FUZ-A_Montageanleitung_5_GB...
  • Page 13 If no safety edge is connected, automatic closing of the door is not possible. Use of additional types of safety edges is possible. Please contact the door manufacturer in this respect. FEIG ELECTRONIC GmbH Seite 13 von 45 FUZ-A_Montageanleitung_5_GB...
  • Page 14 FUZ-A 4.5 Limit switch connection Different limit switch systems can be used with the TST FUZ gate control system. The default setting uses an absolute encoder as the limit switch. In addition, mechanical cam limit switches may be used. 4.5.1...
  • Page 15 à Terminal 36 Wire 3: GND à Terminal 34 Wire 4: Channel A Wire 5: Emergency stop à Terminal 32 à Terminal 33 Wire 6: 12 VDC Figure 6: Connection absolute encoder DES FEIG ELECTRONIC GmbH Page 15 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 16 63 64 31 32 Crank switch Thermo pill Emergency limit switch Open Emergency limit switch Close Figure 8: Connecting cam switches Alternately the pre-limit switches can also be connected as normally closed contacts. FEIG ELECTRONIC GmbH Seite 16 von 45 FUZ-A_Montageanleitung_5_GB...
  • Page 17 Assembly Instructions FUZ-A 4.6 Photo eye 4.7 External triggering devices Figure 9: Photo eye connection Figure 10: External triggering devices FEIG ELECTRONIC GmbH Seite 17 von 45 FUZ-A_Montageanleitung_5_GB...
  • Page 18 When a motor brake is being used, relay K2 is already occupied and it can not be used to control a traffic light.genutzt werden. IMPORTENT before you start the controller, check the electrical connection once more. Incorrect connections may damage the unit. FEIG ELECTRONIC GmbH Page 18 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 19 Assembly Instructions FUZ-A Overview of outputs Door is Door is OPEN CLOSE Figure 12: Overview of the relay outputs Contrary to the mentioned standard settings, the relay function is selectable FEIG ELECTRONIC GmbH Seite 19 von 45 FUZ-A_Montageanleitung_5_GB...
  • Page 20 Assembly Instructions FUZ-A Overview of inputs 41 42 41 42 Figure 13: Overview of inputs FEIG ELECTRONIC GmbH Seite 20 von 45 FUZ-A_Montageanleitung_5_GB...
  • Page 21 Use the arrow keys to select the required parameter. P: Keep open1 P.010 010= 10 s ATTENTION Not all the parameters are visible or may be changed immediately; this always depends on the password and the type of position set. FEIG ELECTRONIC GmbH Seite 21 von 45 FUZ-A_Montageanleitung_5_GB...
  • Page 22 0001 # parameter must be set for this: P.999 = 2 (extended commissioning mode) P: Password 0001 999= 0001# P: Password     999= 0002?# P: Password P.999 999= 0002# FEIG ELECTRONIC GmbH Seite 22 von 45 FUZ-A_Montageanleitung_5_GB...
  • Page 23 (limit switches and pre-limit switches are normally closed) P.205: 0300 = Absolute encoder DES-A (GfA) P.205: 0700 = Absolute encoder DES-B (Kostal) P.205: 0800 = Absolute encoder TST PD / TST PE FEIG ELECTRONIC GmbH Seite 23 von 45 FUZ-A_Montageanleitung_5_GB...
  • Page 24  The automatic retrieval of basic data can be interrupted by pressing the OPEN button when the controller is being turned ON. This causes a direct jump to the parameter configuration mode. FEIG ELECTRONIC GmbH Page 24 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 25 Door is Opening I.515 Now press , repeat the process until the correction travel is completed. I.515 Calib.Run (Display I.510 = OK) I.510 Correc. OK I.510 Door is Opening @AUF Door is Closing  FEIG ELECTRONIC GmbH Page 25 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 26 To prevent the door from moving unintentionally, adjust the limit switches only when the Emergency-STOP is activated or with the controller turned off ! 12. The door may now be operated in Automatic mode. FEIG ELECTRONIC GmbH Page 26 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 27 You can use diagnostic parameter P.910 = 2 to display the actual motor current. The boost should be set so that the motor current remains as low as possible. FEIG ELECTRONIC GmbH Page 27 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 28 At this point it reduces the speed of the door to creep speed using ramp "r2”. The door now moves at creep speed until the limit switch OPEN is reached. At this point the door is stopped (ro). FEIG ELECTRONIC GmbH Page 28 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 29 At this point the door is braked to the creep speed frequency using ramp “r6”. The door now moves at creep speed until the limit switch CLOSE is reached. At this point the door is stopped (ru). FEIG ELECTRONIC GmbH Page 29 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 31 P.39F = 0: deactivated P.39F = 1: slow acceleration of the door P.39F = 2: medium acceleration of the door P.39F = 3: fast acceleration of the door FEIG ELECTRONIC GmbH Page 31 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 32 • The pre-limit switch for the light barrier remains activated even in the middle end position or upper end position. barrier) F.060 Breakaway recognized • Breakaway was detected but not fixed • The automatic lead in after breakaway has failed F.080 Fault: Maintenance is required • Service counter has expired FEIG ELECTRONIC GmbH Page 32 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 33 • No module plugged in but was reported as present by a parameter (coding pin or parameter • The controller was started up with another module than the one currently plugged in setting) FEIG ELECTRONIC GmbH Page 33 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 34 • Ambient temperature too low for controller operation • Clock frequency of final stage too high (Parameter P.160) F.435 Housing temperature high • The temperature inside the controller housing is to high FEIG ELECTRONIC GmbH Page 34 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 35 Housing temperature high • The temperature inside the controller housing is to high F.540 Overcurrent in DC-bus Limit 2 • Boost not adjusted • Motor incorrectly dimensioned for door • Door sticks FEIG ELECTRONIC GmbH Page 35 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 36 • Input 1 of the mobile unit was tested wrong mobile unit TST FSx • The device which is connected to the input does not work correct • The mobile unit is defective FEIG ELECTRONIC GmbH Page 36 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 37 F.823 Wrong parameter setting input • The device which is connected to input 3 of the mobile unit does not fit to the settings 3 of mobile unit • Check Parameter P.F3F FEIG ELECTRONIC GmbH Page 37 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 38 The software versions of the stationary and the mobile unit are not compatible. No safe trip possible. F.860 Internal fault stationary unit Internal system fault on the stationary unit. F.861 Internal fault mobile unit Internal system fault on the mobile unit. FEIG ELECTRONIC GmbH Page 38 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 39 • The programmed software does not know the hardware version • The controller hardware is broken F.970 Plausibility Param.block error • New EPROM version • Controller not yet initialized • Some parameter is implausible FEIG ELECTRONIC GmbH Page 39 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 40 Measuring rotation factor not ready I.700 In timer limit switch operating mode (typ. after power on) the door position is not available. Deadman speed is maintained until the actual position becomes available again. FEIG ELECTRONIC GmbH Page 40 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 41 Information messages during the parameter configuration noEr Error memory: no error saved Er-- Error memory: if error but without associated message being found Prog Programming message while carrying out original parameter or default set FEIG ELECTRONIC GmbH Seite 41 von 45 FUZ-A_Montageanleitung_5_GB...
  • Page 42 Input 2 of mobile unit E.F03 Input 3 of mobile unit E.F04 Input 4 of mobile unit E.F0A Input A of stationary unit E.F0B Input B of stationary unit E.F0C Input C of stationary unit FEIG ELECTRONIC GmbH Page 42 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 43 Relativ humidity up to 95% non condensing Noise emission < 20 dB (A) Vibration low-vibration installation, e.g. on a concrete wall Protection class IP54 (only in respect of enclosure) Weight approx. 5 kg FEIG ELECTRONIC GmbH Page 43 of 45 FUZ-A_Montageanleitung_5_GB...
  • Page 44 Assembly Instructions FUZ-A Equipment mobility: stationary Equipment type: motor appliance, external motor is not part of the delivery from FEIG ELECTRONIC GMBH Protection Class Protection Class I Type tested to: Standards: Machinery Directive device complies with Annex IV categories of machinery - Section 21: "logic unit for safety functions"...
  • Page 45 Assembly Instructions FUZ-A 14 EC- Declaration of conformity FEIG ELECTRONIC GmbH Lange Straße 4 D- 35781 Weilburg EC Declaration of conformity in accordance with the EC Machinery Directive 2006/42/EC, Annexe II A We declare that the machine Description Gate controller with integrated frequency converter...
