- Page 1 Operation manual / Installation manual Europa Mini EWP Domestic Hot Water Heat Pump BA_PM_Europa Mini EWP Tiptronic V024_EN_20100409_V04.doc 1/24...
- Page 2 Table of Contents Notes on the documentation ..............................3 Guarantee ....................................3 Safety instructions ................................3 CE Labelling .................................... 4 Description .................................... 4 Function of heat pump ................................4 Delivery ....................................4 Transportation ..................................4 Installation location .................................. 4 Installation of Source (WQA) ..............................4 4.5.1 Ground collector ..................................
- Page 3 2 Guarantee any work is carried out on the termi- nal strips or electrical connections All Ochsner heat pumps carry a guarantee of (wiring). 24 months, if the installation and operating in- structions are adhered.
- Page 4 The hot water tank, piping systems and all valves are to be protected The Europa Mini EWP is a split device. It is used against freezing. for external hot water tanks with a volume of max.
- Page 5 The collector pipes with 75 m length have to be completely used for the heat extraction and are only allowed to be cut by the Ochsner service technicians. The ends of the circuits should reach ca. 70 cm Picture 1: Connection 1 collector into the room.
- Page 6 4.6.2 Connection pipes NOTE: The company Ochsner is not carrying out wall ducts. No liability can The useable delivery height of the circulation be accepted by Ochsner for damages pump is 50 mbar.
- Page 7 The general and local directives and unplug the heat pump from the 230V power sup- standards have to be applied! ply. Ochsner assumes no liability and no warranty for trapped circulation pumps. 5.1 Functional test After finishing all connections and filling of the plant (see description) the heat pump is ready for start up.
- Page 8 5.3.2 Configuration of sensor input as gate input To control the heat pump 2 options are available. Factory configuration is the option “sensor”. a) Control by sensor at terminal „F1“ b) Control by gate input at terminal „F1“ - The gate input hast to be made for electronic circuits. (relay with golden contacts) - After the heat pump is cut off a time out of 15 min.
- Page 9 6 Operation The heat pump is monitored and controlled by a digital controller. For operation the operator can use a display and operating elements. The operator can adjust the “operating mode” and “setpoints”: OPERATING MODE Heat pump AUTO Legionella safety function AUTO SETPOINTS 52.0°...
- Page 10 6.1 Settings Heat pump – switching on and off LED off: heat pump OFF LED blinking: heat pump ON LED glowing: heat pump OFF; STANDBY mode the set value S1 was reached compressor downtime (20 minutes) active Press button for min. 2 seconds Circulation pump –...
- Page 11 6.2 Setting of Legionella safety function It is possible to set a single hot water charging that is started periodically (t1 in days) The hot water temperature the heat pump has to charge is set with the setpoint S2. Is it not possible to reach the value for S2 within 4 hours the program stops.
- Page 12 6.3 Error messages displayed on the controller Display Error Reason / Troubleshooting - Sensor defect Sensor F1 short - check sensor/connection - Sensor defect Sensor break sensor F1 - check sensor/connection - Sensor defect Sensor F2 short - check sensor/connection - Sensor defect Sensor break sensor F2 - check sensor/connection...
- Page 13 6.4 Error chart heat pump Error Cause Solution Hot water temperatu re too W ater demand too high Reduce demand or activate auxiliary heating element Thermostat not set on max Turn up thermostat Circulation runs continually Check timer, thermost at, and check valve Non-return valve stuck open Tap valve to loosen mechanism Heating gate valve open...
- Page 14 18 months) and to exchange if needed. OCHSNER service technician every 1,5 to 2 years. 7.1 Service interval If desired, OCHSNER offers a service contract. The control and exchange of the anodes is the If you are interested, please contact our cus- requirement for guaranteeing.
- Page 15 8 Appendix 8.1 Technical data - controller F1: resistance sensor NTC 5 kOhm/25° C Inputs - analogue F2: resistance sensor NTC 5 kOhm/25° C precision of measurements according to controller at 25°C: +/-0,5 K and +/-0,5 % of measuring range E1: input for 230V~ high pressure alert Inputs - digital K1: relay, 6(0,5)A 250V~, (6A at cosϕ=1), NOC...
- Page 16 8.1.1 Temperature Sensors All temperature sensors have the same characteristic: NTC 5000 at 25° C. The sensor values are shown in chart 3: Temperature ° C Resistance [Ohm] Temperature ° C Resistance [Ohm] 48322,7 4029,2 43071,6 3702,3 38447,9 3405,3 34370,5 3135,1 30769,4 2889,1...
- Page 17 8.2 Heat pump – Technical data Europa MINI EWP R407C Performance data Performance data at G4/W15-55 G4/W35 Heating capacity Refrigeration capacity Power consumption 0,73 0,67 Coefficient Of Performance Operating current Max. start-up current 16,5 Compressor Type Full hermetic/Rolling piston Number...
- Page 18 8.3 Hydraulic schemes BA_PM_Europa Mini EWP Tiptronic V024_EN_20100409_V04.doc 18/24...
- Page 19 8.4 Circuit diagram Digital Output Digitale Ausgänge Digitaler Digital Eingang Input failure Störung -Pin -Pin -Pin -Pin -Pin -Pin -Pin -Pin -Pin -Pin -Pin -Pin Tiptronic Light Fühler NTC 5kOhm/25° C rot/red 28bar - 21bar sw/bl sw/bl Power 1.7bar - 2.6bar Einspeisung Supply braun/brown...
- Page 20 8.5 Dimensions LEGEND: 1) Hot water return 3/4" (flat-sealing screw joint) 2) Hot water supply 3/4" (flat-sealing screw joint) 3) Suction pipe (male) 4) Injection pipe (female) 5) Terminal sensor F1 (NTC5K) 6) Power cable with grounding type plug 7) Fastening points (4 pieces underneath) for wall connection with wall bracket Floor Ansicht Rückseite...
- Page 21 8.6 Disassembling cover When the distance to the floor is too short the cover can be disassembled as follows: Remove cover bolts on the shell and heave the whole cover hood ca. 10 cm Picture 5: heave the whole cover hood Rotate the top of the cover hood anticlockwise and heave it Picture 6: rotate and heave top Disarrange the individual parts of the shell of the cover hood and remove it...
- Page 22 8.7 Installation details BA_PM_Europa Mini EWP Tiptronic V024_EN_20100409_V04.doc 22/24...
- Page 23 Ochsner Straße 1 EC – Directive confirms that the following indicated devices intro- duced into the market by Ochsner fulfil all applica- EC – Machinery Directive 1998/37/EC ble product guidelines and safety standards of the EC – Low Voltage Directive 73/23/EEC harmonized European Community.
- Page 24 ........................... Service technician ........................... OCHSNER OCHSNER Wärmepumpen GmbH Wärmepumpen GmbH Ochsner Straße 1 Elxlebenerweg 10 A 3350 Haag D 99310 Arnstadt Tel. +43 5 04245 - 499 Tel. +49 3628 6648 - 495 Fax. +43 5 04245 - 498 Fax +49 3628 6648 - 497 www.ochsner.at...
