NSD VS-QA262B-V2 User Manual

Melsec-q plc module converter, applicable sensor: vre-16ts062
Hide thumbs

Advertisement

Quick Links

Download this manual
ZEF006083201
MELSEC-Q
PLC Module Converter
VS-QA262B-V2
User's Manual
Applicable sensor:
VRE-16TS062

Advertisement

loading
Need help?

Need help?

Do you have a question about the VS-QA262B-V2 and is the answer not in the manual?

Questions and answers

Related Manuals for NSD VS-QA262B-V2

Summary of Contents for NSD VS-QA262B-V2

  • Page 1 ZEF006083201 MELSEC-Q PLC Module Converter VS-QA262B-V2 User’s Manual Applicable sensor: VRE-16TS062...
  • Page 3 CONTENTS SAFETY PRECAUTIONS ..........................i INTRODUCTION ...............................iv TRADEMARKS ..............................iv REVISION HISTORY ............................v 1. OVERVIEW ........................1 1.1 Features ..............................3 1.2 Definitions ..............................4 2. SYSTEM CONFIGURATION ................... 5 2.1 Overall Configuration ..........................5 2.2 Applicable System ............................. 6 2.3 Function Block Diagram ..........................
  • Page 4 APPENDIX 3 KC MARK ....................37 APPENDIX 4 ABSOCODER SENSOR SPECIFICATIONS ..........39 Appendix 4.1 ABSOCODER Sensor for VS-QA262B-V2 ................39 Appendix 4.1.1 Specifications ........................39 Appendix 4.1.2 ABSOCODER Sensor Dimensions ................. 40 Appendix 4.2 ABSOCODER Cable ......................41 Appendix 4.2.1 Specifications ........................41 Appendix 4.2.2 Cable length restrictions ....................
  • Page 5 NSD. This product is designed to be used under the industrial environments categorized in Class A device.
  • Page 6 [ Installation Precautions ] CAUTION - Use the programmable controller in an environment that meets the general specifications contained in the CPU User's Manual. Failure to do so may result in electrical shock, fire, malfunction, product damage, or deterioration of performance. - Install the module while pressing the mounting lever at the bottom of module, verifying that the module's mounting protuberance is properly inserted into the base unit's mounting hole.
  • Page 7 [ Start-up and Maintenance Precautions ] WARNING - Be sure to shut off all power before cleaning this module or tightening screws. Failure to do so may result in failure or malfunction of this module. Loose screws can cause drops of the screws, short circuit or malfunction. Overt-tightening screws may damage the screws and/or the module, This can cause drops, short circuit or malfunction.
  • Page 8 INTRODUCTION Thank you for purchasing the VS-QA262B module. Always read through this manual, and fully comprehend the functions and performance of VS-QA262B before starting use to ensure correct usage of this product. Please submit this manual to the end user. TRADEMARKS MELSEC is the trademark or registered trademark of Mitsubishi Electric Corporation.
  • Page 9 REVISION HISTORY The document No. appears at the upper right of this manual's cover page. Document No. Date Revision Description ZEF006083200 28, Jan., 2022 1st Edition Japanese document: ZEF006081500 ZEF006083201 26, Dec., 2022 2nd Edition Japanese document: ZEF006081501...
  • Page 10 1. OVERVIEW This user's manual contains the specifications, and operation/programming procedures for VS-QA262B-V2 (*1) which is to be used in combination with a Mitsubishi Electric corp. MELSEC-Q Series programmable controller. VS-QA262B combines a rotary position sensor to detect the position of the machine being controlled.
  • Page 11 Current Position Detection Function VS-QA262B's current position detection function detects the current position using an ABSOCODER sensor. Conventionally, this was detected using an incremental format encoder in conjunction with a counter unit. The above conventional method has several disadvantages; origin-point return is necessary when power supply is interrupted due to power failure, etc.
  • Page 12 1.1 Features VS-QA262B has the following features: (1) Absolute position detection: Rotational position is detected by an absolute position detection method. Even when a power outage, etc., occurs, the correct position of the ABSOCODER sensor will be instantly detected when power is turned back ON. (2) High resolution: The rotary-type ABSOCODER sensor (the VRE series) offers a resolution factor of 65536 divisions per 1 turn of the sensor shaft.
  • Page 13 1.2 Definitions (1) ABSOCODER ABSOCODER is the generic name given to the NSD-developed position sensor which detects rotational/linear displacement, speed, and acceleration, using an absolute position detection method with a digital (or analog) output. ABSOCODER consists of two main components:...
  • Page 14 2. SYSTEM CONFIGURATION 2. SYSTEM CONFIGURATION 2.1 Overall Configuration The overall configuration of the Mitsubishi Electric corp. MELSEC-Q Series using VS-QA262B is shown below. Q××CPU I/O Module Main base unit(Q3[ ]B) QY×× Refer to the Remarks below. Extension cable(QC[ ]B) VS-QA262B ABSOCODER cable Extension base unit(Q6[ ]B)
  • Page 15 VS-QA262B can be used in the following system. (1) Applicable CPU module Refer to NSD web site for CPU module models with which VS-QA262B can be used. (2) Number of mountable modules Pay attention to the power supply capacity before mounting modules.
  • Page 16 3. VS-QA262B SPECIFICATIONS 3. VS-QA262B SPECIFICATIONS 3.1 General Specifications Shown below are the VS-QA262B specifications. About the ABSOCODER sensor specifications, refer to Appendix 4, "ABSOCODER SENSOR SPECIFICATIONS". Table 3.1 General Specifications Items Specifications Operating ambient temperature 0 to 55°C Storage ambient temperature -25 to 75°C Operating ambient humidity 5 to 95%RH...
  • Page 17 Internal current consumption (5VDC) Outline dimensions [mm] 98 (H)×27.4 (W)×90 (D) Mass [kg] Display of module model names 008 VS-QA262B-V2 in PLC UL508 CSA C22.2 No.142 (Compliance with c-RU standard) Applicable standard CE Marking (EMC directive) KC mark (Korea Certification Mark) 3.3 Function List...
  • Page 18 3.4 Input/Output Signals between VS-QA262B and PLC CPU Below shows the input and output signals to the PLC CPU. (1) In the table below, the input/output signals are classified as follows: (a) Device X: Input signals from VS-QA262B to PLC CPU. (b) Device Y: Output signals from PLC CPU to VS-QA262B.
  • Page 19 3.4.1 Input/output signal details The ON/OFF timing and other conditions for signal input/output between VS-QA262B and PLC CPU are explained below. (1) Unit ready (X0): This signal comes OFF when a watchdog timer error is detected by VS-QA262B’s self-diagnosis function. When ‘X0’...
  • Page 20 (4) Error detection (X5 [X9]): This signal comes ON when any of the ‘X4 [X8]’ signal comes ON, or when any of the errors shown section 6.1 occur. ‘X5 [X9]’ will go OFF after the cause of the error has been corrected, and the ‘Y1C’ (error reset signal) has been turned ON by the sequence program.
  • Page 21 3.5 Buffer Memory VS-QA262B contains a buffer memory which is used for data communication with the PLC CPU. The buffer memory configuration and content is shown below. Data readout of all areas can be executed by the sequence program. Buffer memory space is provided for 2 axes (same content). Addresses 0 to 702 are for Axis 1, and addresses 1000 to 1702 are for Axis 2.
  • Page 22 3.5.3 Input status storage area This area is used to store the input status of the Current position setting command (Y13 [Y16]). The input status is stored as follows: Address 6 [1006] Current position setting command (1) Current position setting command status When the Current position setting command is ON, '1' is stored.
  • Page 23 3.5.7 Axis enabled/disabled setting area This area determines whether to enable or disable a particular axis. When buffer memory address 702 is set to "99", the axis 1 will be disabled. When buffer memory address 1702 is set to "99", the axis 2 will be disabled. This area can be written at any time by the sequence program.
  • Page 24 4. HANDLING and WIRING 4. HANDLING and WIRING This section explains how to unpack and connect VS-QA262B. 4.1 VS-QA262B Handling Precautions The following precautions should be observed when handling VS-QA262B. (1) As VS-QA262B is constructed from a resin-based material, it should not be dropped or subjected to severe shocks.
  • Page 25 4.2 Wiring Precautions for ABSOCODER Cables The wiring precautions for the ABSOCODER cable are explained in this section. (1) The ABSOCODER cable should be located as far as possible from power lines and other lines which generate a high level electrical noise. (2) If location near the above power lines is unavoidable, the cable duct should be separated, with individual wiring conduits being provided.
  • Page 26 ● Mounting of Turn-type ABSOCODER sensor Item Explanation Precaution A “direct-link” format will 1) Coupling of machine result in shaft fatigue shaft and sensor and / or breakage after shaft long periods. Therefore, be sure to use a coupling device to link the shafts.
  • Page 27 ● Coupling of Turn-type ABSOCODER sensor Item Explanation Precaution 1. Selection of the coupling device should be based on the The selection of a 1) Coupling device following factors; larger coupling than selection precaution - The amount of a mounting error caused by the machine necessary will increase design.
  • Page 28 4.4 Name of Parts The illustration below shows the nomenclature of VS-QA262B. Operation status display area Axis display selection switch Sensor connector (Axis 1) Sensor connector (Axis 2) Functions of operation status display area Lower: "5" LED (Axis 1 Error LED) Upper: 0 to F LED Switches on or blinks when an Axis 1 ０...
  • Page 29 MEMO...
  • Page 30 5. CURRENT POSITION DETECTION FUNCTION 5. CURRENT POSITION DETECTION FUNCTION 5.1 Function Description 5.1.1 Current position detection function VS-QA262B's current position detection function detects the current position using an ABSOCODER sensor. Conventionally, this was detected using an ABSOCODER incremental format encoder in conjunction with a sensor counter unit.
  • Page 31 5.1.2 Current position setting function "Current position setting" is a function to change VS-QA262B's current position value to a value corresponding to the current and actual machine position. The Current Position Value in CW Direction (Address 2, 3 [1002, 1003]) or the Current Position Value in CCW Direction (Address 4, 5 [1004, 1005]) in buffer memory will be changed to a pre-entered Current Position Setting Value (Address 690, 691 [1690, 1691]).
  • Page 32 Current position setting timing Writing by TO instruction ▼ Buffer memory Previous Current position setting value New setting value setting value (Address 690, 691 [1690 ,1691]) Current position setting command (Device Y13 [Y16]) Buffer memory Current position value in CW direction (Address 2, 3 [1002, 1003]) Previous current New current position value...
  • Page 33 5.2 Pre-Operation Setting Sequence This section explains the setting sequence for the current position detection function. Start Installation on base unit: Install VS-QA262B on the base unit. External connections: Refer to Section 4.2 and 4.3. Connect the ABSOCODER sensor to VS-QA262B. Programming: Create a sequence program to read out the current position...
  • Page 34 5.3 Programming This section explains how to create the sequence program using VS-QA262B. 5.3.1 Program creation precautions (1) VS-QA262B is an intelligent function module that occupies thirty two I/O points. (2) In response to ‘FROM/TO’ instructions, the first input/output No. of VS-QA262B’s slot will be designated.
  • Page 35 5.3.2 Program for current position monitor display A program example for the current position monitor display is given below. This program example is for Axis 1. Axis 2 programs can be generated in the same way. Conditions The following signal assignments are used to control VS-QA262B. VS-QA262B ‘online’...
  • Page 36 5.3.3 Program for error code readout and reset A program example for the error code readout and error reset operation which is used when a VS-QA262B 'error detection' occurs is given below. This program example is for Axis 1. Axis 2 programs can be generated in the same way. Conditions The following signal assignments are used to control VS-QA262B.
  • Page 37 (2) Example of program using an intelligent function device (U[ ]¥G[ ]). │ X0032 │ 0├─┤ ├──────────────────────────────────────────────────────────────(Y0010 )┤ │ VS-QA262B PLC read │ │ ‘onli │ │ ne’ com │ │ mand │ │ │ │ X0001 X0004 │ Sensor error monitor output 2├─┤...
  • Page 38 5.3.4 Remote I/O station programming The master station (CPU) programming which is required when VS-QA262B is installed in a remote station is explained below. This program example is for Axis 1. Axis 2 programs can be generated in the same way. (1)System configuration Remote master station (Station No.0) QCPU...
  • Page 39 (2) Program example │ SB0047 │ 0├─┤ ├────────────────────────────────────────────────────────(T0 )┤ │ Host bat 1ms time │ │ on pass │ │ status │ │ │ │ │ │ SB0049 │ 5├─┤ ├────────────────────────────────────────────────────────(T1 )┤ │ Host dat 1ms time │ │ a link s │...
  • Page 40 6. TROUBLESHOOTING 6. TROUBLESHOOTING VS-QA262B operation errors and troubleshooting procedures are described in this section. 6.1 Error Code List VS-QA262B error codes are described below. When VS-QA262B detects an error, the corresponding error code is stored in Address 7 [1007] of the buffer memory.
  • Page 41 6.2 Troubleshooting Flowchart The VS-QA262B troubleshooting procedure is explained below. For CPU module related problems, consult the manual for the CPU module in question. Error Occurs If the signal doesn’t go ON even when the PLC CPU is reset, a VS-QA262B hardware problem is likely.
  • Page 42 6.3 Flowchart when Current Position Setting is Impossible Current position setting can not be executed. Note the error code, and Does an error status check the causes. exist at VS-QA262B? ‘Online’ status Designate the ‘online’ status. established? Turn Y13 [Y16] ON Current Position Setting Is Y13 [Y16] turned ON Command Y13 [Y16] will be...
  • Page 43 6.4 Flowchart when the ABSOCODER Sensor’s Current Position Value doesn't Change The ABSOCODER sensor’s current position value doesn’t change. Does an error status Note the error code, and check the exist at VS-QA262B? causes. Does the ABSOCODER Rotate the ABSOCODER sensor. sensor rotate? Refer to Section 4.2 and Appendix Is the ABSOCODER...
  • Page 44 APPENDIX APPENDIX 1 CE MARKING VS-QA262B series conforms to EMC directive, but stands outside scope of the low voltage directive. (1) EMC Directives It is necessary to do CE marking in the customer’s responsibility in the state of a final product. Confirm EMC compliance of the machine and the entire device by customer because EMC changes configuration of the control panel, wiring, and layout.
  • Page 45 APPENDIX 2 UL STANDARD The VS-QA262B Series corresponds to the UL standard. Read this page carefully and use the VS-QA262B Series by following the described items. (1) Installation - Install inside the control cabinet. - For use in pollution degree 2 environment. - Within the surrounding air temperature 0℃...
  • Page 46 APPENDIX 3 KC MARK Notification for users 사용자안내문 This product complied with the relevant Korean Safety Standard for use in the industrial environment. Thus, radio frequency interference could occur if it is used in a domestic environment. 이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은 기기로서 가정용...
  • Page 47 MEMO...
  • Page 48 APPENDIX 4 ABSOCODER SENSOR SPECIFICATIONS Appendix 4.1 ABSOCODER Sensor for VS-QA262B-V2 Appendix 4.1.1 Specifications Items Specifications Sensor model VRE-16TS062FAL Total number of turns Number of divisions 65536 (2 Mass 1.3kg Linearity error 0.067° Max. 7.4 x 10 kg･m (7.5 x 10 kgf･cm･s...
  • Page 49 Appendix 4.1.2 ABSOCODER Sensor Dimensions Units: mm ■VRE-16TS062FAL ■ RB-02 (Option) (L type flange-mount fixture)
  • Page 50 The permissible length of the ABSOCODER cable varies according to the ABSOCODER sensor model, as shown in the following table Cable model 3S-RBT Sensor model VRE-16TS062 100m REMARKS Contact your NSD representative when the ABSOCODER cable combines different types of cables.
  • Page 51 Appendix 4.2.3 ABSOCODER Cable Dimensions ■ 3S-RBT-0102-[L] Units: mm NOTE: [L] is given in terms of meter. ■ 3S-RBT-0103-[L] Units: mm NOTE: [L] is given in terms of meter.
  • Page 52 Appendix 4.2.4 ABSOCODER Cable Connection ABSOCODER sensor Extension cable VS-QA262B 3S-RBT-0103-[L] VRE-16TS062 3S-RBT-0103-[L] 3S-RBT-0102-[L]...
  • Page 53 APPENDIX 5 DIMENSIONS Appendix 5.1 VS-QA262B Position Detection Module Units: mm...
  • Page 54 APPENDIX 6 ABSOCODER SENSOR CHECK LIST ● Applicable ABSOCODER models VRE-16TS062 ● Connection configuration ● Connector appearance and pin position VS-QA262B ABSOCODER sensor Extension sensor cable View A VRE-16TS062 View B Checks at Point B should be carried out with Point A connected. ●...
  • Page 55 *1: If checks are done at Point B, the measurement value is [Standard coil resistance + extension sensor cable resistance (cable length (m) x 0.2 (Ω))]. The resistance value of the NSD special cable is 0.2Ω/m (loop resistance). Consider resistance variations due to temperature, which, relative to the standard temperature (25 increases 0.4% when the temperature rises 1...
  • Page 56 APPENDIX 7 I/O SIGNALS and BUFFER MEMORY FUNCTION LIST ◯: enabled ×: disabled Signal VS-QA262B (online/offline) Online Offline Remarks type Device No., address, and name Unit ready ○ ○ (VS-QA262B detection item) VS-QA262B operation status Signal (online/offline) inputs to Sensor error detection ○...
  • Page 58 Manufacturer NSD Corporation 3-31-28, OSU, NAKA-KU, NAGOYA, JAPAN 460-8302 Distributor NSD Trading Corporation 3-31-23, OSU, NAKA-KU, NAGOYA, JAPAN 460-8302 Phone: +81-52-261-2352 Facsimile: +81-52-252-0522 URL: www.nsdcorp.com E-mail: foreign@nsdcorp.com Copyright©2023 NSD Corporation All rights reserved.
