- Page 1 MAXHUB XBoard V7 Series Quick Start Guide All the pictures in this manual are for reference only, subject to our available products.
- Page 2 -——————————————————————————————————————— VI. Power On/0 -———————————————————————————————————————————————— VII. Control Panel -———————————————————————————————————————————————— 1. Prepare to install -———————————————————————————————————————————————— 2. Terminal interface -——————————————————————————————————————————————— IX. Bring Your Own Device -———————————————————————————————————————— X. Frequently Connected Ports -————————————————————————————————————— XI. First Start of MAXHUB Interactive Display -————————————————————————— XII. Maintenance -—————————————————————————————————————————————————...
- Page 3 LCD Screen (1) Do NOT use hard nor sharp objects on the screen other than MAXHUB stylus. (2) Please unplug the power before cleaning the product. Please clean the screen with a soft, dustless and dry cloth. (3) Please do NOT use water or liquid detergent to clean the product.
- Page 4 Please contact authorised reseller for maintenance or repairing. Warranty Exclusions MAXHUB does not warranty Products that match any one or few of the following descriptions: (1) Product damage caused by violating the user manual. (2) Hardware damage caused by improper setup.
- Page 5 I. Unboxing Checklist MAXHUB XBoard V7 Series Quick Start Guide All the pictures in this manual are for reference only, subject to our available products. Interactive Display x1 Wall Mounting ×1 Quick Start Guide×1 Passive Stylus×2 The Wireless Module×1 Power Cord* HDMI Cable (1.5M)×1...
- Page 6 2. Steps to install the wall mount Take out the wall mount plate accessory package from the accessory box. a-1pcs / b-2pcs c-4pcs d-2pcs e-8pcs f-8pcs g-8pcs Take the panel out of the box and place it on a soft surface, such as a mat, to protect it during installation. Take 8 pcs of expansion rubber plug Fix the wall bracket on 8 pcs expansion g and screw it into the wall.
- Page 7 Hang the panel vertically on the bracket, Tighten the safety screw counter-clockwise keep the panel in the center of the bracket. to make the top of screw reach the second screw hole. 3. Reference on wall mount • •• • • •• •• • • • • • • • •• • • • • • • • •...
- Page 8 III. Installing the Wireless Module Please make sure that the following items are ready before setting up the wireless module. 1 × Interactive Flat Panel 1 × Wireless Module Please make sure the power cord of the Interactive Flat Panel is disconnected before installation. Step1: Remove the Mylar strip on the bottom of the interactive flat panel.
- Page 9 Installing the PC Module Please make sure the power cord of the Interactive Flat Panel is disconnected before installation. Step1: Unscrew and remove the cover. Step2: Prepare the PC module. PC module cover Step3: Align the PC module with the slot in the correct orientation. Slot Bottom Step4: Installation of PC module.
- Page 10 V. Removing the PC Module Please make sure the power is o before proceeding with the removal. To remove the module, loosen the screws and release the lock. VI. Power On/0 Plug the power cable into the power socket of the product. Plug the power cable into the power supply.
- Page 11 VII. Control Panel To ensure the proper functioning of the product, it is important to keep it free of dust and moisture. Regular cleaning with a soft, dust-free, and dry cloth is recommended. Remember to unplug the product before cleaning. 1.
- Page 12 2. Terminal Interface Items Function description Supports being connected to call camera, microphone, speaker, and touch panel TOUCH for additional functionality. High-definition multimedia interface signal input, connect to devices with HDMI HDMI IN1/2 output interface (personal computer with HDMI output, set-top box, or another video device).
- Page 13 IX. Bring Your Own Device Function: 1.Wired Screen Share from your laptop to the display 2.Control your laptop from the touch display 3.Access to the display's camera/speaker/Microphone from your laptop HDMI IN TOUCH 2. Through USB Type-C Type-C...
- Page 14 X. Frequently Connected Ports USB Type-C Cable Type-C Computer USB cable USB device USB Touch Cable TOUCH HDMI Cable HDMI IN Serial Port Cable Computer RS232 USB cable USB device Audio cable AUDIO OUT AUDIO IN Amplifier/Acoustics/Earpone...
- Page 15 XI. First Start of MAXHUB Interactive Display To start the MAXHUB V7, press the power key. Once the device is on, it is ready for use with all of its features. Power Button...
- Page 16 XII. Maintenance To ensure the proper functioning of the product, it is important to keep it free of dust and moisture. Regular cleaning with a soft, dust-free, and dry cloth is recommended. Remember to unplug the product before cleaning. Cleaning the Screen 1.
- Page 17 Hereby, Guangzhou Shirui Electronics Co., Ltd. declares that the this product is compliant with the essential requirements. The complete Declaration of Conformity may be requested through the following postal address: MAXHUB EUROPE B.V. BEURSPLEIN 37, 3011AA ROTTERDAM, NETHERLANDS This symbol, a ixed to the product or its packaging, indicates that the product must not be processed with household waste.
- Page 18 MAXHUB MAXHUB.Global maxhub-overseas/...
