- Page 1 MAXHUB XBoard V7 Series For Microsoft Teams Room Quick Start Guide Model: V655T, V865T, V925T V1.6 All the pictures in this manual are for reference only, subject to our available products.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Contents —————————————————————————————————————————————————————— I. Package Contents -————————————————————————————————————————————— II. Overview -———————————————————————————————————————————————————— III. Installation ———————————————————————————————————————————————————— 1. Hang the Display on the Wall with a Wall Mount ———————————————————————————— ————————————————————————————————————————— 2. Insert the Wireless Module 3. Install the PC Module -—————————————————————————————————————————— 4. Remove the PC Module -——————————————————————————————————————————... -
Page 3: Power Supply
CAN AND WILL CAUSE DAMAGE TO THE OS. Do not power down the device during updates. If this had happened, please navigate to maxhub.com, and open a support ticket. We will guide you through re-imaging the device, to recover it. -
Page 4: Temperature And Humidity
Please contact authorised reseller for maintenance or repairing. Warranty Exclusions MAXHUB does not warranty Products that match any one or few of the following descriptions: (1) Product damage caused by violating the user manual. (2) Hardware damage caused by improper setup. -
Page 5: Package Contents
I. Package Contents Interactive Display x1 Wall Mount ×1 MAXHUB XBoard V7 Series For Microsoft Teams Room Quick Start Guide Model: V655T, V865T, V925T V1.5 All the pictures in this manual are for reference only, subject to our available products. -
Page 6: Overview
II. Overview 65 / 86 inch: Front 11 12 13 14 23 24 Bottom Side Power Switch Kensington Security Slot (optional) Loudspeaker Ethernet Port Magnetic Zone Touch Console Port Remote Control Sensor Touch USB Light Sensor Mic In Microphone HDMI In 1/2 (2.0) Camera RS232 Wi-Fi Module... - Page 7 92 inch: Front 12 13 -DTM1- Bottom Side Power Switch Power Indicator Loudspeaker Kensington Security Slot (optional) Magnetic Zone Ethernet Port Remote Control Sensor Touch Console Port Light Sensor Mic In Microphone Analog Audio In Camera Touch USB Wi-Fi Module HDMI In 1/2 (2.0) HDMI Out 1/2 (2.0) Analog Audio Out...
-
Page 8: Installation
III. Installation 1. Hang the Display on the Wall with a Wall Mount Step 1. Confirm the location of the wall mount Align the holes in each vertical bracket with the screw holes on the back of the display. Ensure they are level, and at your specified height. - Page 9 Before wall mounting, locate specified studs and a reinforcement plate inside the wall to hold the wall up. (It can protect the display from falling o the wall.) Studs Reinforcement plate Wall Hexagon head bolt Attach the wall mount bracket on the reinforcement plate with 8 pcs of washer e and separately.
- Page 10 With the wall mount strip attached on the display, hang the display vertically on the wall mount bracket, keeping the display in the middle of the wall mount bracket. Firmly tighten the safety screws to hold the bracket to display. Ensure that the screws counter-clockwise to make the top of screw reach the second screw hole.
- Page 11 Step 3. Check the installation of the wall mount •• • • •• •• • • • • • • • •• • • • • • • • • • • •• •• • • •• • •• • • • • • •••• • • • ••• • • • ••••• • •• • • • • • • •••• ••• • •••• •• •• • • • • • • • •••• • ••• • •• • • • • • • •• To ensure ease of use, please take into consideration the physical dimensions of the display before wall mounting.
-
Page 12: Insert The Wireless Module
2. Insert the Wireless Module WARNING Please make sure the power cord of the Interactive Flat Panel is disconnected before installation. Step 1: Make sure that the following items are available before setting up the wireless module: Interactive Flat Panel × 1 Wireless Module ×... -
Page 13: Install The Pc Module
3. Install the PC Module WARNING Please make sure the power cord of the Interactive Flat Panel is disconnected before installation. Step1: Unscrew and remove the cover. cover Step2: Prepare the PC module. Step3: Align the PC module with the slot in the correct orientation. Slot Bottom... -
Page 14: Remove The Pc Module
Step4: Installation of PC module. Rail up Insert the module 4. Remove the PC Module Step 1: Make sure the power is o before removing the PC module. Step 2: Unsrew and release the lock to remove. Lock... -
Page 15: Connections
IV. Connections The connector panel is at the right side of the interactive display. The following diagram shows the examples of devices that can be connected to the interactive display: Power, computer, touch console, speaker, microphone, etc. Touch Console (TCP30T) USB device Network Power... - Page 16 The following diagrams show the examples of how these devices can be connected to the interactive display and the corresponding cables. 65 / 86 inch: HDMI Cable USB Cable HDMI Cable Network Cable Network Cable USB Touch Cable Network Cable USB to RS232 Cable USB Cable Audio Cable...
- Page 17 92 inch: HDMI Cable USB Cable HDMI Cable Network Cable Network Cable Network Cable Audio Cable USB Touch Cable Audio Cable USB Cable AC In RS232 USB to RS232 Cable Power Cable...
-
Page 18: Power
V. Power On/0 (optional) Plug one end of the power cord into the device and the other end into the wall outlet. Optional: Press the AC Switch to open AC power. “I” means power on, and “O” means power o . (only available for 65 inch and 86 inch.) Press the power button to turn on the device or put the device on standby. -
Page 19: Software And Deployment
VI. Software and Deployment Initial Launch Setup 1. Turn on the display, the Welcome Page will be displayed, then click Get Started to begin setup. 2. Select Accept to accept the End User Agreement, or it will decline and exit. 3. - Page 20 4. Enter the “email address and password” of your account. 5. Click Finish to go to the Home Screen page, and all the installed applications can be accessed.
-
Page 21: Switch Account
Switch Account By default, XBoard system has two built-in Windows accounts: Skype and Administrator accounts. You can switch between the Skype and Adminitrator accounts as needed for di erent use. Skype: Skype is the default account when the system starts, and is limited to running Microsoft Teams Rooms. The Skype user interface is set to Microsoft Teams Mode. - Page 22 2. At Setting page, select Windows Settings to go to the Administrator log page. 3. Enter the password (default: sfb), then go to the Home Screen page of Administrator account. NOTE If you plug in a physical keyboard, and press the windows key 5 times, it will bring you directly to the Windows Settings login page.
- Page 23 Switch to Skype NOTE Switching the Windows Mode to the Microsoft Teams Mode. 1. In the Windows mode, select the Windows key in taskbar. 2. Select Administrator > Skype, then go to the Skype log page. 3. Click Login to switch to Skype account.
-
Page 24: Change Admin Password
Change Admin Password The administrator password is set to “sfb” by default, and you can change the password if needed. 1. Open Setting in the Windows mode, and select Accounts > Login to Administrator. 2. At Accounts page, select Sign-in Options > Password > Change. - Page 25 Enter the original password (default: sfb) and the new password as prompted, then the Admin password will be changed. WARNING Do not turn o or reboot the device while the system is in the update process.
-
Page 26: Maintenance
VII. Maintenance To ensure the proper functioning of the product, it is important to keep it free of dust and moisture. Regular cleaning with a soft, dust-free, and dry cloth is recommended. Remember to unplug the product before cleaning. Cleaning the Screen 1. -
Page 27: Energy Star Statement
Hereby, Guangzhou Shirui Electronics Co., Ltd. declares that the this product is compliant with the essential requirements. The complete Declaration of Conformity may be requested through the following postal address: MAXHUB EUROPE B.V. BEURSPLEIN 37, 3011AA ROTTERDAM, NETHERLANDS Energy Star Statement ENERGY STAR is a U.S. - Page 28 MAXHUB MAXHUB.Global maxhub-overseas/...
