Summary of Contents for MAXHUB ND43CMA
- Page 1 Commercial Display Quick Start Guide Model: ND43CMA / ND55CMA / ND65CMA ND75CMA / ND86CMA / ND98CMA All the pictures in this manual are for reference only, subject to our available products.
- Page 2 (7) This power cable comes with the device exclusively for this device only. LCD Screen (1) Do NOT use hard nor sharp objects on the screen other than MAXHUB stylus. (2) Please unplug the power before cleaning the product. Please clean the screen with a soft, dustless and dry cloth.
-
Page 3: Maintenance
Please contact authorised reseller for maintenance or repairing. Warranty Exclusions MAXHUB does not warranty Products that match any one or few of the following descriptions: (1) Product damage caused by violating the user manual. (2) Hardware damage caused by improper setup. - Page 4 WiFi Module (SI07B) ×1 Remote Control×1 Power Cord ×1 HDMI Cable (2M)×1 Note:【*】Power cord could be di erent for di erent regions , pls refer to the actual product. II. Installation Guide 1.Confirm the panel installation position. Align the wall-mounted screw holes with the studs on the back panel and fasten with 2 wall-mounted strips.
- Page 5 2.Steps to install the wall mount Take out the wall mount plate accessory package from the accessory box. a-1pcs b-8pcs c-8pcs d-8pcs Take the panel out of the box and place it on a soft surface, such as a mat, to protect it during installation.
- Page 6 Tighten the safety screw counter-clockwise Hang the panel vertically on the bracket to make the top of screw reach the second and then finish installation. screw hole. Mounting arms Tilt the Device & Screen Wall Plate Note: This step is especially important for Note: Please keep the panel in the center of installation on the mobile stand.
- Page 7 III. Installing the WiFi Module Please make sure that the following items are ready before setting up the wireless module. 1×Commercial Display 1×WiFi Module 2×Screws (CM3×6mm) Please make sure the power cord of the Commercial Display is disconnected before installation. Step1: Use a Phillips screwdriver toloosen two screws and remove the cover.
- Page 8 IV. Installing the PC module/Android Module Please make sure the power cord of the Commercial Display is disconnected before installation. Step1: Unscrew and remove the cover. Step 2: Prepare the PC module/ Android Module. PC module Android Module Note: Android Module is only available in select market Step3: Unscrew and remove the cover.
- Page 9 V. Removing the PC module/Android Module Please make sure the power is o before proceeding with the removal. To remove the module, press up on the module and release the lock. VI.Power On/0 Plug the power cable into the power socket of the product. Plug the power cable into the power supply.
- Page 10 VII. Control Panel (1) Please check connections are correct before starting. Number Items Power indicator light : Tap to enter energy-saving, press at least 2 seconds to enter standby mode MENU: Pop up Settings menu INPUT: Pop up channel Setting : Press to scroll left : Press to scroll right : Press to scroll down / Volume down...
-
Page 11: Terminal Interface
(2) Terminal Interface Type 1: Type 2: Number Items Function description Connect USB devices such as mobile hard disk, U disk, USB keyboard and mouse, USB drives, etc. RS232 Serial interface, used for mutual transfer of data between devices. Connect USB devices such as mobile hard disk, U disk, USB keyboard and mouse, USB drives, etc. Support charging, data transmission, extension for audio and video output interface, etc. - Page 12 Note: (1) 43~55 inch: USB Type-C、HDMI 1、HDMI 2 support HDMI OUT; Android channel: not support HDMI OUT. (2) 65~98 inch: PC channel、 USB Type-C、HDMI 1、HDMI 2 Support HDMI OUT；Android channel、 HDMI 3 not support HDMI OUT. (3) Remote Control • Remote Control Button Instruction •...
- Page 13 Remote Control Instruction • Install Batteries ① Open back cover of battery component on the back of remote control. ② Install AAA type battery according to the corresponding electrode, make sure battery positive and negative pole are correct ("+"to"+", "-" to "-"), please do not mix using old and new batteries. ③...
- Page 14 IX.Wired Screen Share from your laptop to the display Through USB Type-C Type-C...
- Page 15 X.Frequently Connected Ports USB Type-C Cable Type-C Computer USB cable USB device...
- Page 16 Audio cable AUDIO OUT AUDIO IN Amplifier/Acoustics/Earpone XI. First Start of MAXHUB Commercial Display To start the MAXHUB ND**CMA, press the power key. Once the device is on, it is ready for use with all of its features. ND**CMA Series...
- Page 17 XII. Maintenance To ensure the proper functioning of the product, it is important to keep it free of dust and moisture. Regular cleaning with a soft, dust-free, and dry cloth is recommended. Remember to unplug the product before cleaning. Cleaning the Screen 1.
- Page 18 MAXHUB MAXHUB.Global...
