CLASSIC BAY 1200 PELLET STOVE & INSERT

Heat Exchanger & Exhaust Cleaning Instructions

www.quadrafire.com

WARNING

Fire Risk

For trouble free use of your pellet appliance you must perform cleaning

as called for in these instructions. Not doing so will result in:

• Poor operating performance

• Smoke spillage into the home

• Overheating of components

Not properly cleaning your appliance on a regular basis will void your

warranty.

Refer to your Owner's Manual for complete cleaning

instructions for all components.

7014-145

May 9, 2008

Table of Contents

Need help?

Do you have a question about the CLASSIC BAY 1200 and is the answer not in the manual?

Page 1 CLASSIC BAY 1200 PELLET STOVE & INSERT Heat Exchanger & Exhaust Cleaning Instructions WARNING Fire Risk For trouble free use of your pellet appliance you must perform cleaning as called for in these instructions. Not doing so will result in: •...
Page 2 PROPER SHUTDOWN PROCEDURE CAUTION Shock and Smoke Hazard • Turn down thermostat, let appliance completely cool and exhaust blower must be off. Now you can unplug appliance before servicing. • Smoke spillage into room can occur if appliance is not cool before un- plugging.
Page 3 1200 Pellet Insert Tools Needed: Shop Vac, Phillips head and flat head screwdriver A. Cleaning the Heat Exchanger Chambers D. Clean Firebox Exhaust Exits & Exhaust Blower 1. There are exhaust exits at the back of the firebox on 1.
Page 4 1200 Pellet Stove Tools Needed: Shop Vac and Phillips head screwdriver A. Cleaning the Heat Exchanger Chambers D. Clean Exhaust Exit Behind the Exhaust Blower 1. Lift the hopper lid to access the cleaning rods. Both 1. Open both the upper and lower right side panels. black bent handle pull rods are located close to the face Figure 4.3.
