EX-1594HMS

4. Hardware Installation

Because there are large differences between computers, we can give you only a general

installation guide. Please refer your computer's reference manual whenever in doubt.

1. Mount the EX-1594HMS on a wall or DIN-Rail if required.

2. Connect the USB cable to the USB-B port on the hub.

3. Connect the optional power supply to the terminal block on the hub.

4. Connect the other end of the USB cable (USB-A connector) to the USB-A port on your PC.

5. Driver Installation

All Operating Systems

After the hardware installation the OS will recognize the device automatically and install the

drivers.

CHECK INSTALLED DRIVER

Open the >Device manager<. Now you should see at „Ports (COM & LPT)" & „USB-Controller" the

following new entry's:

DIN-Rail mount

English

Holes for

wall installation
