  • Page 1 2004 W O R K S H O P Deutsch English Français Nederlands Italiano Español...

  • Page 2: Table Of Contents

    w w w . m a g u r a . c o m s e r v i c e @ m a g u r a . d e Summary 1. Introduction 2. ISafety instructions before the first ride 3.

  • Page 3: Introduction

    w w w . m a g u r a . c o m s e r v i c e @ m a g u r a . d e 1. Welcome to the Brake People! Congratulations! You have purchased a fully hydraulic MAGURA rim brake proudly „Made in Germany“.

  • Page 4: Isafety Instructions Before The First Ride

    w w w . m a g u r a . c o m s e r v i c e @ m a g u r a . d e 2. Before the first ride 1. Are you already familiar with hydraulic rim brakes? Our brakes might be much more powerful than the stoppers on which you relied so far.

  • Page 5: Transport Of The Bicycle

    w w w . m a g u r a . c o m s e r v i c e @ m a g u r a . d e Contaminating the pads with oil and lubricants will cause a permanent loss of braking power.

  • Page 6: Brake Installation

    w w w . m a g u r a . c o m s e r v i c e @ m a g u r a . d e 6. Brake Mounting 1. Tools for mounting (+maintenance) Allen key 2*, (3), and 5mm 8mm open end wrench sharp knife (*delivered with the brake)
  • Page 7 w w w . m a g u r a . c o m s e r v i c e @ m a g u r a . d e Mount the brake lever onto the handlebar. (Tightening torque 4Nm/34 in.lbs) In the following pictures the wheel is often is often not in place, this is purely to help show the details better.
  • Page 8 w w w . m a g u r a . c o m s e r v i c e @ m a g u r a . d e 8.When installing a MAGURA on a suspension fork, some fork boosters may cause clearance problems.

  • Page 9: Rat Brake Booster For Manitou Forks

    w w w . m a g u r a . c o m s e r v i c e @ m a g u r a . d e 7. RAT Booster für Manitou Reverse Arch System 1. For Manitou forks with “Reverse Arch Technology” (fork brace BEHIND the upper legs) the standard booster does NOT fit.

  • Page 10: Installation Firm-Tech

    w w w . m a g u r a . c o m s e r v i c e @ m a g u r a . d e 8. Installation of FIRM-tech® models If you are the proud owner of a MAGURA suspension fork with FIRM-tech equipment, mounting the brakes is a breeze.

  • Page 11: Shortening And Routing The Hose

    w w w . m a g u r a . c o m s e r v i c e @ m a g u r a . d e 9. Shorten and route the hose 1. HS 33 models. Turn the red Turbo Pad Adjuster (TPA) fully back in the direction of arrow “A”.
  • Page 12 w w w . m a g u r a . c o m s e r v i c e @ m a g u r a . d e 7. Put the hose on a hard surface. Cut the hose squarely just behind the olive using a cutter, never use pliers or a saw.

  • Page 13: Maintenance/Brake Pad Change

    w w w . m a g u r a . c o m s e r v i c e @ m a g u r a . d e 10. Maintenance / brake pad change 1. brake pad wear adjustment HS 33 models 2.

  • Page 14: Filling And Bleeding

    w w w . m a g u r a . c o m s e r v i c e @ m a g u r a . d e 11. Filling and bleeding The filling and bleeding of a MAGURA brake is not a routine work. This is due to the fact that the MAGURA Royal Blood hydraulic oil does not absorb water like DOT brake liquid in cars and on motorcycles.

  • Page 15: Repairs

    w w w . m a g u r a . c o m s e r v i c e @ m a g u r a . d e 12. Repairs 1. Repair of a HS 11 main hose with barbed adaptor connection. 2.

  • Page 16: Brake Pads

    w w w . m a g u r a . c o m s e r v i c e @ m a g u r a . d e 13. brake pads MAGURA offers four different brake pad compounds for different riding styles and rim surfaces.

  • Page 17: Accessories

    w w w . m a g u r a . c o m s e r v i c e @ m a g u r a . d e 14. accessories 1. Suspension spacers (0720 433) When installing a MAGURA on a suspension fork, some fork boosters may cause clearance problems.

  • Page 18: Spare Parts Exploded View

    w w w . m a g u r a . c o m s e r v i c e @ m a g u r a . d e 15. spare parts 2004/max. tightening torques HS 33 Race-line yellow left 0721 585 right...
  • Page 19 w w w . m a g u r a . c o m s e r v i c e @ m a g u r a . d e HS 33 HS 33, 10x: 0720 921 10x: 0720 924 HS 11, 10x: 0720 927 10x: 0720 931/ 2,5 Nm/22 in.lbs.
  • Page 20 Spain Casa Masferrer Hong Kong MAGURA Bike Parts GmbH & Co. phone 93-8463444 MAGURA ASIA Inc. Heinrich Kahn Straße 24 fax 93-8465355 phone +886-4-23283739 D-89150 Laichingen cmcenter@casamasferrer.com fax +886-4-23283734 phone +49-(0)7333/9626-0 Comet service@magura.com.tw fax +49-(0)7333/9626-17 phone 943-331393 info@magura-bikeparts.de Hungary Mali Bicycle Technology fax 943-551407 phone 01-4207563 comet@comet.es...
