  • Page 1 TS8 · TS6 WNER S MANUAL...

  • Page 3: Table Of Contents

    ONTENTS IAGRAMS NTRODUCTION Preface .......16 Legend .......16 ECHNICAL PECIFICATIONS Specifications ....17 Dimensions ......17 AFETY Intended use ......18 Basic safety instructions ..18 NSTALLATION Installing the fork ....20 Fitting the front wheel ..21 Fitting the remote control lever (RCL²) ......22 Taking eLECT into operation .23 Air pressure guidelines..25 Adjusting the suspension (air pressure) ......25...
  • Page 4 Ø 28,6 mm Ø 28,6 mm Ø 38,1 mm DLO² DLO³ e-lect Ø 30,0 mm Ø 39,8 mm Ø 39,8 mm PM 7" / MAGURA M15 PM 6" / QR (9 mm) 9 mm Ø 15 mm THE PASSION PEOPLE...
  • Page 5 IAGRAMS 25 mm max.
  • Page 6 IAGRAMS 2,5 mm 2 N·m (18 lbf·in) max. 10 N·m (89 lbf·in) 3 N·m (27 lbf·in) max. THE PASSION PEOPLE...
  • Page 7 IAGRAMS 2,5 mm 2 N·m (18 lbf·in) max.
  • Page 8 IAGRAMS sag ≈ 20–30 % MIN MAX ≈ 12–14 clics THE PASSION PEOPLE...
  • Page 9 IAGRAMS...
  • Page 10 IAGRAMS THE PASSION PEOPLE...
  • Page 11 IAGRAMS (1s –1s –1s …) (1s –1s –1s …) 3 h => 100 % 3 h => 100 %...
  • Page 12 IAGRAMS 8 s min. 8 s min. 1× THE PASSION PEOPLE...
  • Page 13 IAGRAMS 3 – 30 s 3 – 30 s 3 s min. 3 – 30 s 2 s min.
  • Page 14 IAGRAMS DLO² – ON DLO² – OFF 2× (0,5s) 2 cm +1,5° +1,5° 0° 0° 2 cm −1,5° −1,5° 3 s – 5 s 1× (2s) 2× (0,5s) 4× (0,25s) 1× (2s) 4× (0,25s) 1× 1× THE PASSION PEOPLE...
  • Page 15 IAGRAMS 1× (2s) 2× (0,5s) 4× (0,25s) 1× 1× CR 2032...

  • Page 16: Introduction

    You can find the diagrams that this manual refers to in the folder in the If you sell or give away your MAGURA product, be sure to hand over this front and back covers.

  • Page 17: Dimensions

    ECHNICAL PECIFICATIONS Some of the features detailed are optional variants. Your MAGURA suspension fork is equipped as designed by your dealer or the bicycle manufacturer. Type name Variant Suspension Air pressure max. bar (psi) 10 (150) Damping DLO³ albert SL • eLECT • DLO³ • DLO²...

  • Page 18: Technical Specifications

    (Ø 180–210 mm). the steerer, milling the disc brake bridge, removing the hanger on the for use of the MAGURA M15 thru axle and a front wheel hub suitable dropouts, drilling, painting, opening the eLECT unit, etc.).
  • Page 19 0 °C (32 °F). Before each ride, work the suspension multiple times to make sure that your MAGURA suspension fork is leak tight and shows no sign of oil leaks on screws, sliders and seals, or any other visible mechanical Transport &...

  • Page 20: Installation

    NSTALLATION Using a suitable installation aid, tap the adjusting nut carefully and NSTALLING THE SUSPENSION FORK straight into the steerer Make sure that the frame, headset, stem, and adjusting nut match the steerer on your suspension fork – see , page 17. ECHNICAL PECIFICATIONS Installing the suspension fork...

  • Page 21: Fitting The Front Wheel

    MAGURA M15 must be combined exclusively with MAGURA suspension Danger of accident due to faulty installation work. forks with dropouts for thru axle (PM 7"). MAGURA suspension forks with dropouts for thru axle (PM 7") must be Insert the front wheel into the dropouts on your MAGURA suspen- combined exclusively with the MAGURA M15 thru axle clamping system.

  • Page 22: Fitting The Remote Control Lever (Rcl²)

    – only for direct fitting to brake levers of MAGURA (18 lbf·in). MT Series and HS Series (MAGURA rim brakes) as of model year 2011. Trim the inner cable to a length of approx 2 cm after the clamping RCL² for DLO² is generally mounted on the right –...

  • Page 23: Taking Elect Into Operation

    When charging the rechargeable battery, exclusively use intact micro- The MAGURA eLECT rear shock does not have the automatic mode of USB mains adapters that are also suitable for mobile smartphones.
  • Page 24 NSTALLATION Assigning the arrow keys on the eLECT remote control Synchronising the eLECT remote control The front arrow key of the eLECT remote control is best assigned to The eLECT remote control and the eLECT unit must be synchronised your suspension fork, and the rear key to your rear shock. (paired) when used for the first time and after replacing the battery.

  • Page 25: Set Up

    Before you go for your first ride with your new MAGURA suspension fork, take some time to adjust the suspension and damping to match your Material damage due to severe bottoming out caused by insufficient air personal weight and style of riding. This is absolutely necessary to make pressure.

  • Page 26: Adjusting The Damping (Rebound Damper)

    REBOUND DAMPER The negative suspension stroke – or sag – is the distance by which The rebound damping setting defines the speed at which your MAGURA your suspension fork is lowered when it is subject to your body weight suspension decompresses.

  • Page 27: Adjusting The Damping (Compression Damper)

    DLO² on steeper inclines. to your requirements. – DLO² For more information: – see , page 28. OCKING OUT THE SUSPENSION FORK This refers to your suspension fork (master) – your MAGURA rear shock uses the same calibration.

  • Page 28: O N The Road Before Each Ride

    Before each ride, work the suspension multiple times to make sure that Sensitivity (compression behaviour) is greatly reduced. your MAGURA suspension fork is leak tight and shows no sign of oil Uphill riding is favoured. leaks on screws, sliders and seals, or any other visible mechanical The negative suspension stroke –...
  • Page 29 … with eLECT in automatic mode Every time one of the two arrow keys is pressed you switch between eLECT takes over automatic control of the DLO² of your MAGURA activating and deactivating DLO² (ON–OFF or LOCKOUT–OPEN). suspension fork. It is a precondition that the system must have been...

  • Page 30: Maintenance

    Danger of accident due to pressurised parts. , page 23. battery Never open your MAGURA suspension fork via the top screws in the fork crown or the screws at the bottom end of the stanchions. Contact your authorised MAGURA service centre if your suspension fork needs EGULAR a major service.

  • Page 31: Exchanging The Battery Rechargeable Battery

    Once a year, you will need to Damage to material due to faulty installation work. have your MAGURA suspension fork serviced in a professional bicycle The rechargeable battery of the eLECT unit is exclusively allowed to be workshop or by an authorised MAGURA service centre.

  • Page 32: Rectifying Elect Faults

    Make sure that the direction arrow is point- ing forward in the riding direction eLECT unit defective. MAGURA service center. LED flashes 4× very quickly (0.25 s) red. Rechargeable battery capacity exhausted. Charge the rechargeable battery. Sleep mode.

  • Page 33: Rules

    Changing the surface (e.g. painting, machining or facing of the disc mounts, ...). The staff at MAGURA work continuously on improving our products in the context of ongoing technical Changing of the structure (e.g. drilling holes, assembly of lowriders, ...).
