Structural Concepts Fusion MD User Manual page 6

Installation: Case Removal From Skid
Remove Lower Front Panel From Case:
• To prevent damage to the case, remove the lower front
panel from the case before removing it from the pallet.
• The lower front panel is held in place by magnets only. No
screw removal is required.
• Place the lower front panel in a secure location while
removing the case from the pallet.
Remove Lower Rear Panel From Case:
• To prevent damage to the case, if the lower rear panel is
on the case, lift it UP and OFF.
• The lower rear panel is held in place by magnets.
• Place lower rear panel in a secure location while
removing the case from the pallet.
Disconnect Case From Pallet:
• Remove screws from shipping brackets. Remove and
discard shipping brackets from the pallet.
• Place J-bar/pry under base frame. Raise the case up
from the pallet to take the weight off the casters.
• With the case raised, lower the casters all the way down
against the pallet.
Fusion® User Manual Fusion® MD User Manual
Lower Front Panel
Lower Rear Panel
Shipping Bracket
