Product Placement
Product Placement
Product can be placed on decking or shelves. Proper airflow is critical to maintaining proper product temperature.
Product should not be placed on air grills inside of the case and have at least 1 inch of clearance between product and
shelf. See load line illustration below.
Fusion® MD User Manual Fusion® User Manual
Model MD485R Shown Above
X
Product Stop
1" Minimum Load Line
1" Minimum Load Line
1" Minimum Load Line
1" Minimum Load Line
1" Minimum Load Line
1" Minimum Load Line
