・Input range 0 to 20 mA (Default)
110%
100%
・Input range 4 to 20 mA (Default)
110%
100%
Same as or less
than -6.25%
Output data
Scale 100% -> 10000
Scale 0% -> 0
0
Output data
% Hexadecimal
0x2AF8
0x2710
0% 0x0000
Output data
Scale 100% -> 10000
Scale 0% -> 0
Scale -6.25% -> -625
Output data
% Hexadecimal
0x2AF8
0x2710
0% 0x0000
0xFD8F
-37-
mA
20
Current [mA]
Decimal
22
11000
20
10000
0
0
mA
4
20
Current [mA]
Decimal
22
11000
20
10000
4
0
Same as or
-625
less than 3
