●Curved surface mounting
(1) Thread the top and bottom cable ties through the installation plate.
(2) Secure the wireless adaptor to the mount by tightening the cable ties. Trim back the loose ends of the
cable ties.
●Mounting the Wireless Adaptor
(1) Attachment of installation plate
Secure the base and installation plate with the two tapping screws (M3 x 8) included with the wireless
adaptor. The tightening torque should be 0.4 N•m +/- 10%.
-24-
Doc.DOC1104200-1
