Refer to the system configuration example below. For details, check the instruction manual of each product.
System configuration example
Wireless
No.
Base
*1
1 EXW1
*1
2 EXW1
3 EX600-W
4 EX600-W
*5
5 EXA1
*1 When paired with EXW1-BMJ (CC-Link wireless base), EXW1-RAXZA2C cannot be used in operation
mode 1.
*2 For more details, check the system settings of the Base.
*3 Only available in Protocol V.2.0.
*4 Up to 100 m between an EXW1 series Base and Remote, and up to 10 m between an EXW1 series
Base and an EX600-W series Remote.
*5 When paired with the EXA1 series air management system, the IO map and parameter settings
operate with the values set on the remote.
○ System configuration example 1
Wireless Base : EXW1 series
Wireless Remote: EXW1 series
<Wireless Base>
<Wireless Remote>
Wireless Communication
Remote
Up to 100 m
EXW1
EXW1+EX600-W
Up to 10 m
EXW1
Up to 10 m
EXW1+EX600-W
Up to 100 m
EXW1
Applicable function
Protocol
distance
V.1.0/V.2.0
*4 V.1.0
V.1.0
V.1.0
V.2.0
-13-
Frequency channel
select function (F.C.S.)
x
*2 *3
-
-
-
-
Doc.DOC1104200-1
