Circuit diagram
•Connector for wireless adapter
No.
1
2
3
4
*1: Use the wireless adapter cable specified to connect to the wireless adapter.
*2: Do not turn on the power supply.
*1
Signal
24V
24V：Output
Internal BUS B
Communication B
0V
Internal BUS A
Communication A
Description
M8, 4-pin, socket
3
*
2
0V
1
-19-
4
2
Doc.DOC1104200-1
