MIA CORNER UNIT
711
1
BEFORE BEGINNING. Carefully remove contents from box. Make sure
that all parts and hardware are included using the Parts List below. Drill
torque setting should be set to 3 for all Phillips head screws.
Tools Required:
Back Assembly
Left
2" Phillips Head Screw
Actual Size
Part Code: 316-8X2PFDS
50mm Hex Lag
Part Code: 316-1/4-10-50HL
3/8" Bungs
x 6
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | sales@seasidecasual.com
ASSEMBLY INSTRUCTIONS
PLEASE READ INSTRUCTIONS COMPLETELY
#2 Phillips Head Screwdriver, Rubber Mallet and High Powered Drill
Right
x 1
Actual Size
Seat Assembly
x 1
x 6
Part Code: 316-1/4-10-80HL
x 10
Part Code: 316-8X1.25PFDS
Side Assemblies
Left
Right
80mm Hex Lag
Actual Size
1-1/4" Phillips Head Screw
Actual Size
711-MIA CORNER UNIT
Corner
Leg
x 1ea
x 6
x 16
Page 1
