MIA SINGLE ARMLESS
706
1
BEFORE BEGINNING. Carefully remove contents from box. Make sure
that all parts and hardware are included using the Parts List below. Drill
torque setting should be set to 3 for all Phillips head screws.
Tools Required:
Back Assembly
1-3/4" Phillips Head Screw
Actual Size
Part Code: 316-8X1.75PFDS
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | sales@seasidecasual.com
ASSEMBLY INSTRUCTIONS
PLEASE READ INSTRUCTIONS COMPLETELY
#2 Phillips Head Screwdriver, Rubber Mallet and High Powered Drill
x 1
50mm Hex Lag
Actual Size
Part Code: 316-1/4-10-50HL
Seat Assembly
x 1
x 10
Part Code: 316-1/4-10-80HL
x 3
Left and Right Side Assemblies
Left
80mm Hex Lag
Actual Size
3/8" Tap
x 4
706-MIA SINGLE ARMLESS REV-B
Right
x 1ea
x 6
Page 1
