MIA DOUBLE LEFT ARM
710
1
BEFORE BEGINNING. Carefully remove contents from box. Make sure
that all parts and hardware are included using the Parts List below. Drill
torque setting should be set to 3 for all Phillips head screws.
Tools Required:
Back Assembly
1-3/4" Phillips Head Screw
Actual Size
Part Code: 316-8X1.75PFDS
Part Code: 316-1/4-10-50HL
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | sales@seasidecasual.com
ASSEMBLY INSTRUCTIONS
PLEASE READ INSTRUCTIONS COMPLETELY
#2 Phillips Head Screwdriver, Rubber Mallet and High Powered Drill
x 1
50mm Hex Lag
Actual Size
Seat Assembly
x 1
x 14
Part Code: 316-1/4-10-80HL
x 5
Left and Right Side Assemblies
Left
80mm Hex Lag
Actual Size
5/8" Tap
3/8" Tap
x 2
710-MIA DOUBLE LEFT ARM REV-B
Right
x 1ea
x 7
x 1
Page 1
Advertisement
Related Manuals for Seaside Casual MIA DOUBLE LEFT ARM
Summary of Contents for Seaside Casual MIA DOUBLE LEFT ARM
- Page 1 5/8” Tap 3/8” Tap Actual Size Part Code: 316-1/4-10-50HL WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114 Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | sales@seasidecasual.com Page 1 710-MIA DOUBLE LEFT ARM REV-B...
- Page 2 Page 2 710-MIA DOUBLE LEFT ARM REV-B...
- Page 3 THE REAR LEGS AND PUT IN TAPS The back should sit flush against the rear legs. Screw the back to the rear legs using (2) 1-3/4” Phillips head screws. Using a rubber mallet, put (2) 3/8” taps Page 3 710-MIA DOUBLE LEFT ARM REV-B...
