GT Power Performer 2020 Owner's Manual Supplement

Hide thumbs

Advertisement

Quick Links

Download this manual
Power Performer
Owner's Manual Supplement
READ THIS SUPPLEMENT AND YOUR GT
BICYCLE OWNER'S MANUAL. Both contain
important safety information. Keep both for
future reference.
English

Advertisement

loading
Need help?

Need help?

Do you have a question about the Power Performer 2020 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GT Power Performer 2020

Summary of Contents for GT Power Performer 2020

  • Page 1 English Power Performer Owner’s Manual Supplement READ THIS SUPPLEMENT AND YOUR GT BICYCLE OWNER’S MANUAL. Both contain important safety information. Keep both for future reference.
  • Page 2 Safety Messages In this supplement, particularly important information is presented in the following ways: Indicates a hazardous situation which, if not avoided, may result in death or serious injury. NOTICE Indicates special precautions that must be taken to avoid damage.
  • Page 3 E-Bike Maintenance ......41-33 your bike; obtain and read all of them. Notes ............44 Please contact your Authorized GT Dealer immediately if you need a manual or supplement, or have a question about your bike. You may also contact us using the...
  • Page 4 Indentification Drive System Parts Power Performer OMS INDENTIFICATION Drive System Parts Actual bike appearance will differ. Identification 1. Drive, display 5. Charge port 2. Drive, hub 6. Key 3. Battery 7. Serial number 4. Wheel Sensor Serial Number The frame serial number is located on the barcode label on the underside of the bottom bracket.
  • Page 5 Indentification Handlebar Controls Handlebar Controls Identification 1. Drive, display 5. Grip, left 2. Drive, lever, throttle 6. Grip, right 3. Horn 7. Brake, lever, front 4. Shifter 8. Brake, lever, rear...
  • Page 6 Using your bike the wrong way is held. Releasing the throttle stops drive dangerous. assist. Please read your GT Bicycle Owner’s At anytime, if you stop pedaling, (or release Manual for more information about the throttle) the drive-assist will dis- Intended Use and Conditions 1-5.
  • Page 7 OBSERVE MINIMUM OPERATOR AGE - Follow any national, state, or local laws for any minimum age restrictions for the operator of the E-Bike. Ask your local Authorized GT Dealer for more information about operating an electrically assisted pedal bicycle in your area.
  • Page 8 Safety Information Operation Power Performer OMS Operation Always wear an approved bicycle helmet and all other protective gear (e.g., gloves, pads, and cycling shoes). Importance of practice & rider training - before you ride this bike, practice riding in a safe area free from hazards.
  • Page 9 Safety Information Operation continued from previous page... Wired system control: If the drive system control device is detached from the mount or if the cables are disconnected or damaged, the drive system will automatically shut off. If this happens, you will have to stop the bike, turn the system off , re-attach the computer to the base, and then turn the system back on to resume operation.
  • Page 10 Safety Information Operation Power Performer OMS Batteries & Chargers REPLACEMENT - Only use the battery pack and charger indicated in the Specifications section of this supplement. Do not use other batteries or chargers. Do not use the charger to charge other batteries. PREVENT DAMAGE - Do not drop the battery or charger.
  • Page 11 Technical Information Specifications TECHNICAL INFORMATION Specifications Item Specification Drive System 250W Bafang Hub Drive Motor. 45 Nm of (drive) torque Battery 418Wh Removable Rechargeable Li Ion Battery. Samsung 29E cells Drive-Assist Owner’s Manual https://www.bafang-e.com/ Head Tube UPR: 1-1/8” LWR: 1-1/8” Headset Semi Integrated, 1-1/8”...
  • Page 12 Keep your spare key in a safe place. To purchase a replacement or duplicate key contact an Authorized GT Dealer in your region. Be sure to have the key number Please Note: available.
  • Page 13 Technical Information HAN-WIN Battery User Manual HAN-WIN Battery User SAFE Manual User Manual The fo are not ® HAN-WIN Tech INNO-SAFETY Lithium-ion Battery bicycle 911HWTCAH16 If t IMPORTANT Before using this HAN-WIN Tech INNO-SAFETY battery on Electrically Power Assisted Cycles (EPAC), please read ®...
  • Page 14 Technical Information HAN-WIN Battery User Manual Power Performer OMS SAFETY INSTRUCTIONS AND WARNING The following points should be noted when using this battery pack with your electric bicycle. If the below guidelines are not strictly followed, the running time will be reduced and the usage life of the battery pack and your electric bicycle may also be shortened.
  • Page 15 Technical Information To remove the battery: To remove the battery: 1. Power off battery pack by pressing and holding the power button for three seconds. When the LED lights flash, the power is off. FIG. A FIG. A 2. Insert the battery key and turn counter-clockwise.
  • Page 16 Technical Information To install the battery: Power Performer OMS To install the battery: 1. Power off battery pack by pressing and holding the power button for three seconds. When the LED lights flash, the power is off. FIG. A FIG. A 2.
  • Page 17 Technical Information To install the battery: 4. Hold battery on the handle area and do not touch the power switch button. FIG. F FIG. F 5. Push the battery pack downward until it clicks (audible), and the battery pack fixed securely. FIG. G 6.
  • Page 18 Technical Information To operate the electric assist: Power Performer OMS To operate the electric assist: Pedaling assist: Set the level of pedal assist from the display by pressing the +/- buttons: Button (1) Turns the drive system ON and changes the display mode. Button (2) marked “+”...
  • Page 19 Technical Information Drive System Display - DP C15.URT Drive System Display - DP C15.URT • Real-time speed indication: Indicate real- time speed unit km/h or MPH. ON/OFF/Mode • Intelligent battery capacity indication: Show Down the percentage of remaining battery capacity Intelligent battery capacity indication which accounts for total battery capacity.
  • Page 20 Technical Information Using the Display Power Performer OMS Using the Display “press and hold” ..means press and hold for more than two seconds “ briefly press ” ..means press for less than 0.5 second. • ON/OFF • 6KM/H push assistance Press and hold power button, the display Press and hold the “-”...
  • Page 21 Technical Information Using the Display • Multiple functions interface Error code indication After starting up, the default interface is When the failure occurs, the display will • “TRIP” (single trip distance). Press "Mode" show the error code and the display will briefly circularly, it can circularly switch as flicker at the same time.
  • Page 22 Technical Information Using the Display Power Performer OMS Press and hold “+”button & “-”button at • Reset single-trip distance the same time to enter into the menu list Enter into “Display Setting” menu and briefly (“Display Setting”, “Information”, “EXIT”). press “+” or “-” to select “TRIP Reset” and Briefly press “+”button or “-”button to briefly press “ON/OFF”.
  • Page 23 Technical Information Using the Display “press and hold” ..means press and hold for more than two seconds “ briefly press ” ..means press for less than 0.5 second. • Unit switch between Metric and Imperial • Backlight luminance setting Enter into “Display Setting”...
  • Page 24 Technical Information Using the Display Power Performer OMS • Check speed limit • “Auto O ” time setting Enter into “Information” interface and briefly Enter into “Display Setting” interface and press “+” or “-” to select “Speed Limit” and briefly press “+” or “-” to select “Auto O ” briefly press “power”...
  • Page 25 Technical Information Using the Display • Check history of error codes Information Definition Unit Enter into “Information” interface and briefly code press “+” or “-” to select “Error Code” and Current briefly press “power” to check history. Briefly ℃ temperature press “+”...
  • Page 26 Technical Information Using the Display Power Performer OMS This HMI DP C15.UART can indicate all errors occurring on the pedelec. Error Explanation Troubleshooting Brakes enabled Check whether a brake cable is stuck. Bring your Pedelec to your dealer or to a High voltage protection specialist to have the error fixed.
  • Page 27 Technical Information Drive System Display - DP C11 Drive System Display - DP C11 NORMAL INDICATION AREA Headlight/Backlight indication: Only display when headlight/backlight is on. Indicate the current speed unit: km/h or MPH Multi-function indication: Including single-trip distance TRIP, total distance ODO, maximum speed MAX, aver - age speed AVG, remaining distance RANGE, output power POWER, Calorie Cal, riding...
  • Page 28 Technical Information Drive System Display - DP C11 Power Performer OMS NORMAL OPERATION “Press and hold” means press and hold for more than two seconds, briefly press means press for less than 0.5 second. • On/o Press and hold power key, the display starts working. Press and hold the power key again, it will turn o .
  • Page 29 Technical Information Drive System Display - DP C11 • Headlight / backlight switch Turn on the light: press and hold the “+” key, it will turn on the backlight of display and headlight, the display will show icon for the headlight. turn o the light: press and hold the “+”key again, it will turn o the backlight of display and headlight, and the icon for the headlight will disappear.
  • Page 30 Technical Information Drive System Display - DP C11 Power Performer OMS • Sate of charge indication for battery It displays the state of charge for battery with one to five grids. When it display all five grids, it means the battery has full capacity. If the frame of the battery icon flickers at the frequency 1 HZ, it means battery needs to be charged immediately.
  • Page 31 Technical Information Drive System Display - DP C11 FUNCTIONS SETTING Press and hold “+” key & “-” key at the same 1) Display setting time to enter into the menu list (“Display • Reset the single-trip distance Setting”, “Information”, “EXIT”). Briefly press Enter into “Display Setting”...
  • Page 32 Technical Information Drive System Display - DP C11 Power Performer OMS interface, the all information will be metric; • “auto o ” time setting if selecting the imperial, the all information Enter into “Display Setting” interface and will be imperial.) briefly press “+”...
  • Page 33 Technical Information Drive System Display - DP C11 2) Indication information introduction • Check battery information • Check wheel diameter Enter into “Information” interface and briefly press “+” key or “-” key to select “Battery Enter into “Information” interface and briefly Info.”...
  • Page 34 Technical Information Drive System Display - DP C11 Power Performer OMS Recently not charging Hour time Number of battery cell Voltage of cell 1 Voltage of cell 2 … … Voltage of cell n • Check record of error code Enter into “Information”...
  • Page 35 Technical Information Drive System Display - DP C11 BESST CONNECTION • If it is successful for display to connect to • When writing SN, if the display show “Write BESST, the display will show: “Connected OK!”, it means it is successful for BESST Tool OK!”.
  • Page 36 Technical Information Drive System Display - DP C11 Power Performer OMS ERROR CODE DEFINITION DP C11.UART display can show e-bike faults. When a fault is detected, the icon will be displayed. One of the following error codes will be displayed. Error code Error definition Error-shooting method...
  • Page 37 Technical Information Rear Wheel Rear Wheel To remove the wheel : 1. Use the shifter to shift the chain to a lower ring on the rear cassette. This makes it easier to re-installs the wheel later. 2. Remove the battery. See „To remove the battery“...
  • Page 38 Technical Information Rear Wheel Power Performer OMS 6. Pull off the non-drive side plastic nut NON-DRIVE SIDE DRIVE SIDE cover. Slide the drive side plastic cover back onto the cable to expose the drive side axle flanged nut. FIG. RW4 FIG.
  • Page 39 Technical Information Rear Wheel To install the wheel : 1. Remove the battery. See „To remove the battery“ in this manual. Failure to remove the battery can result in accidental activation of the drive system. You can be seriously FIG. RW8 injured.
  • Page 40 Replacement Parts Service Power Performer OMS REPLACEMENT PARTS The following service and replacement parts are available through an Authorized GT Dealer: Part Number Description K8736129 BMX Power Disc RR Wh Hub Motor 6B 29 K8734129 BMX Street Disc FR Wh 100x3/8 6B 29...
  • Page 41 Before and After Each Ride: • Clean and visually inspect the entire bike for cracks or damage. See “Inspect for Safety” in your GT Bicycle Owner’s Manual. • Fully charge the battery make sure it is securely attached to the bike. Follow the drive system charging instructions.
  • Page 42 3. Every 1000 km, (600 miles), bring your bike in to your Authorized GT Dealer for a regular detailed inspection, adjust- ment, and replacement of wear items across the entire bike.
  • Page 43 E-Bike Maintenance Cleaning Cleaning When cleaning your bike, use a damp sponge or a soft brush with only a mild soap and water solution. Rinse the sponge often. Do not spray water directly on controls or on drive system components. NOTICE Do not use a pressure washer or dry with compressed air.
  • Page 44 Record NOTES Record Power Performer OMS NOTES Use NOTES pages to write /record important information about your bike : (e.g. maintenance history, dealer contact information, settings, etc.) 138247 Rev 1 (01/21)
  • Page 46 © 2020 Cycling Sports Group Power Performer OMS 138247 Rev. 1 GT USA CSG EUROPE GT UK Cycling Sports Group, Inc. Cycling Sports Group Europe B.V. Cycling Sports Group 1 Cannondale Way, Geeresteinselaan 57 Vantage Way, The Fulcrum, Wilton CT, 06897, USA...
