GT Fury Owner's Manual Supplement

Hide thumbs Also See for Fury:

Advertisement

Quick Links

Download this manual
Fury
Owner's Manual Supplement
READ THIS SUPPLEMENT AND YOUR
GT BICYCLE OWNER'S MANUAL.
Both contain important safety information.
Keep both for future reference.
English

Advertisement

loading
Need help?

Need help?

Do you have a question about the Fury and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GT Fury

Summary of Contents for GT Fury

  • Page 1 English Fury Owner’s Manual Supplement READ THIS SUPPLEMENT AND YOUR GT BICYCLE OWNER’S MANUAL. Both contain important safety information. Keep both for future reference.
  • Page 2 Apply carbon gel (friction paste) KF115/ NGLI-2 synthetic grease Apply NGLI-2 synthetic grease. Medium-strength removable thread lock Apply Loctite® 242 (blue) or equivalent. GT Support Illustrations: Our online SUPPORT contains helpful Throughout this manual, all product resources to consult about our bikes.
  • Page 3 Please contact your Authorized GT Dealer immediately if you need a manual or supplement or have a question about your bike. You may also contact us using the...
  • Page 4 · An unusual or strange feel to the Ask your GT Dealer for help. frame We urge you to read PART II, Section · Carbon which has a soft feel or D.
  • Page 5 Understand your bike and its intended use. Using your bike the wrong way is Find Tightening Torque Information : dangerous. Please read your GT Bicycle Owner’s The wide range of bicycle models and Manual for more information about components used means that a listing Intended Use and Conditions 1-5.
  • Page 6 The judgment, lack of judgment or insanity of a rider who may ride a GT Bicycle cannot be completely predicted, so it’s flat-out impossible to predict how anyone’s equipment is going to hold up.
  • Page 7 Even so, your sweet rig isn’t going to last forever. Nothing does, particularly bikes and parts that are built to minimize weight and then are subjected to abuse. GT frames carry a warranty, but that’s to cover issues with workmanship and/or materials. (See the GT Limited Warranty in this manual). The warranty doesn’t mean that they’re going to last forever.
  • Page 8 Your retailer MUST follow and observe this specification for your bike. For Maximum Fork Length specifications for GT bicycles, see www.gtbicycles.com. You can be severely injured, paralyzed, or killed in an accident if you ignore this warning.
  • Page 9 Safety Information Tire Size x Maximum Width Tire Size x Maximum Width Observe the Tire Size x Maximum Width for your bike found in the “Specifications” page of this manual. Mounting the wrong size tires can result in the tires hitting the fork or frame when riding.
  • Page 10 Safety Information Rear Tire Clearance : Full Suspension Fury Owner’s Manual Supplement Rear Tire Clearance : Full Suspension Applies to: • saddles • seat posts 10 mm • rear racks • dropper posts • any accessory with possible collision with the moving tire.
  • Page 11 Safety Information Rear Shock Rear Shock Minimum Seat Post Insert Tinimum seat post insert length for Select only compatible shocks and forks your frame is found in the Frame for your bike. Do not modify your bike in SPecifications table in this manual. any way to mount one.
  • Page 12 Technical Information Specifications Sensor Owner’s Manual Supplement TECHNICAL INFORMATION Specifications Item Specification Wheel Size REAR: 27.5 or 29 FRONT: 29 in only Rear Travel 29: 205mm 27.5: 213mm Head Tube UPR: ZS49, LWR ZS49 Headset FSA Orbit Z 1.5r Semi-Integrated ZS49/28.6 top, ZS49/30 Lower Bottom Bracket: Type/Width BSA Threaded/83mm Front Derailleur...
  • Page 13 Technical Information Geometry TTL_H REACH TTL_A SEAT_H STACK WDIA_F WDIA_R STA_E 75.00 STA_A STL_A DROP RAKE TRAIL Geometry Dimensions = millimeter Sizes (mm) STL_A Seat tube length STA_E Seat tube angle effective 75.0 ° 75.0 ° 75.0 ° TTL_H Top tube horizontal TTL_A Top tube actual Head tube angle...
  • Page 14 1. Unthread and remove idler, idler bolt , and spacer if present (only on main pivot). 2. Using an M6 bolt of threaded length > 30mm, thread the bolt through the exposed wedge thread. Continue until the wedge is loosened.
  • Page 15 Technical Information Pivot Axles N·m N·m N·m N·m N·m Removal Order:...
  • Page 16 Technical Information Rear Shock Fury Owner’s Manual Supplement Rear Shock NOTICE Setting Sag Install shock with adjusters/reservoirs positioned to the front of the bike. 1. Follow the shock manufacturer’s instruc- tions for setting the shock according to • Install the lower shock bolt into the rider weight.
  • Page 17 Technical Information Rear Shock 5 Nm 15 Nm LINEAR PROGRESSIVE Identification 1. Shock 5. Left leverage chip 2. Link 6. Right leverage chip a. socket 3. Shock bolt, upper (2X) 7. Shock bolt, lower 4. Bearing, spacer (2X)
  • Page 18 Technical Information Shock Link Fury Owner’s Manual Supplement Shock Link Identification 1. Link 7. Link, pivot bearings (4X) 12. Rear shock 2. Seatstay 8. Link, pivot axle bearing 13. Pivot axle (2X) 3. Seatstay/Link chip (2X) spacer 4. Bearing spacer (2X) 9.
  • Page 19 Technical Information Bottom Bracket BSA Threaded (Euro) Bottom Bracket BSA Threaded (Euro) 1. Thoroughly grease the threads and cup torque spec faces 6. Wipe off excess grease 3. Apply BB spacers to the BB cups 7. The chainring should be in-line with the depending on the specification found in idler sprocket OR slighter outboard of the the BB manufacturers manual.
  • Page 20 Technical Information Changing Rear Wheel Size Fury Owner’s Manual Supplement Changing Rear Wheel Size The seatstay/link chips can be installed for either a 27.5” or 29” rear wheel. See next figure, lower. The selected position of the chip in either the 27.5” or 29” wheel position can be made independently of the positions of either the rear shock leverage or rear dropout chips.
  • Page 21 Technical Information Changing Rear Wheel Size 27.5 in REAR WHEEL 29 in REAR WHEEL Note gap when in this position...
  • Page 22 Technical Information Changing Wheelbase Length Fury Owner’s Manual Supplement Changing Wheelbase Length The dropout chips can be installed for either a shorter or longer bicycle wheelbase. See next figure, lower. The selected position of the chip in either the longer or shorter position can be made independently of the positions of either the rear shock leverage or seatstay/ link chips.
  • Page 23 Technical Information Changing Wheelbase Length 4 Nm LONGER SHORTER 450mm WHEELBASE 440mm WHEELBASE...
  • Page 24 Technical Information Dropouts Fury Owner’s Manual Supplement Dropouts Identification 1. Seatstay 5. Bearing (4X) a. Groove 2. Chainstay 6. Ring clip (2X) b. Small side 3. Axle Bolt (2X) 4. Bearing spacer (4X) 192927 Rev 0 (11/23)
  • Page 25 Damaged, loose, missing, or incorrectly-positioned protectors can lead to frame damage. Damage of this type is not covered by the GT Limited Warranty. Make sure all frame protectors and guards are present, are installed correctly, and are in good condition.
  • Page 26 Technical Information Tightening Torques Fury Owner’s Manual Supplement Tightening Torques 4X 1 Nm (2X 8 Nm) 2X 7 Nm 2X 7 Nm 2X 5 Nm 2X 5 Nm 6 Nm IDLER BOLT 2 Nm (3X 6 Nm) MAIN PIVOT ASSEMBLY...
  • Page 27 Technical Information Cable Routing Cable Routing • Please note that at the fender cable guide the two housing cross. • Please note that the housing in the area of the fender cable guide are to be secured to the frame on the frame guides (3) using zip ties.
  • Page 28 Replacement Parts Fury Owner’s Manual Supplement REPLACEMENT PARTS The following service and replacement parts are available through an Authorized GT Dealer: Part Number Description VIEW K34033 Fury Fork Bumpers L+R K22011 FS Idler Pulley w/ Bearing K22091 Force/Fury Idler Bolt and Spacer K91003 Fury Shock Link (incl.
  • Page 29 Replacement Parts REF# 3 VIEW I 2X 8 Nm 2X 7 Nm 4 Nm 4X 1 Nm Unless otherwise speci ed, apply medium strength (Loctite 242 (blue) removable thread locker 180 degrees on all bolt threads. Lightly grease all bearings before press t. Lightly grease under all counter-sink bolt heads.
  • Page 30 Replacement Parts Fury Owner’s Manual Supplement REF# 3 VIEW 2 5 Nm 5 Nm 1 Nm NO THREAD LOCK 1 Nm 10 Nm 2 Nm 6 Nm 3X 6 Nm Unless otherwise speci ed, apply medium strength (Loctite 242 (blue) removable thread locker 180 degrees on all bolt threads.
  • Page 31 Maintenance Scheduling MAINTENANCE Scheduling The following table lists only supplemental maintenance items. Please consult your GT Bicycle Owner’s Manual for more information on basic bike maintenance. Item Frequency Cable Routing - Make sure control cables are in place, Before first ride undamaged and attached securely.
