English Sensor Owner’s Manual Supplement READ THIS SUPPLEMENT AND YOUR GT BICYCLE OWNER’S MANUAL. Both contain important safety information. Keep both for future reference.
Apply carbon gel (friction paste) KF115/ NGLI-2 synthetic grease Apply NGLI-2 synthetic grease. Medium-strength removable thread lock Apply Loctite® 242 (blue) or equivalent. GT Support Illustrations: Our online SUPPORT contains helpful Throughout this manual, all product resources to consult about our bikes.
Page 3
Please contact your Authorized GT Dealer immediately if you need a manual or supplement or have a question about your bike. You may also contact us using the...
Understand your bike and its intended use. Using your bike the wrong way is Find Tightening Torque Information : dangerous. Please read your GT Bicycle Owner’s The wide range of bicycle models and Manual for more information about components used means that a listing Intended Use and Conditions 1-5.
Your retailer MUST follow and observe this specification for your bike. For Maximum Fork Length specifications for GT bicycles, see www.gtbicycles.com. You can be severely injured, paralyzed, or killed in an accident if you ignore this warning.
Page 7
Safety Information Tire Size x Maximum Width Tire Size x Maximum Width Observe the Tire Size x Maximum Width for your bike found in the “Specifications” page of this manual. Mounting the wrong size tires can result in the tires hitting the fork or frame when riding.
Page 8
Safety Information Rear Tire Clearance : Full Suspension Sensor Owner’s Manual Supplement Rear Tire Clearance : Full Suspension Applies to: • saddles • seat posts 10 mm • rear racks • dropper posts • any accessory with possible collision with the moving tire.
Safety Information Rear Shocks Rear Shocks Minimum Seat Post Insert Make sure at least 100 mm of the seat Select only compatible shocks and forks for your bike. Do not modify your bike in post is inserted into the frame at all any way to mount one.
Page 14
Technical Information Geometry - Alloy Sensor Owner’s Manual Supplement Geometry - Alloy TTL_H REACH SEAT_H TTL_A FORK_L STACK STL_A TRAVEL_R STA_E TRAVEL_F STA_A DROP RAKE Dimensions = millimeter TRAIL Sensor Size Wheel Size STL_A Seat Tube Length TTL_H Top Tube Hori-zontal TTL_A Top Tube Actual Head Tube Angle...
Page 15
NOTICE Damaged, loose, missing, or incorrectly-positioned protectors can lead to frame damage. Damage of this type is not covered by the GT Limited Warranty. Make sure all frame protectors and guards are present, are installed correctly, and are in good...
Technical Information Rear Shock Sensor Owner’s Manual Supplement Rear Shock Setting Sag 4. Remove the upper and lower shock mounting bolts and remove the shock. 1. Follow the shock manufacturer’s instruc- 5. Remove the upper spacers. tions for setting the shock according to rider weight.
Page 17
Technical Information Rear Shock Alloy frame shown 2X 5 Nm 8 Nm Identification 1. Link 5. Shock bushings, lower 9. O-Ring 2. Shock 6. Shock bolt, lower, long 3. Shock bolt, upper (2X) 7. Shock bolt, lower, short a. Small side 4.
Page 18
Technical Information Dropouts Sensor Owner’s Manual Supplement Dropouts Identification 1. Seatstay 5. Bearing (4X) a. Groove 2. Chainstay 6. Ring clip (2X) b. Small side 3. Axle Bolt (2X) 4. Bearing spacer (4X) 151949 Rev. 0 (09/22)
Page 19
Technical Information Link Assembly - Carbon Link Assembly - Carbon 2X 5 Nm 2X 5 Nm See LockR Axles Connecting the Link To prevent misalignment and/or potential Identification damage, follow this assembly order routine: 1. Link Connect link to frame. See „LockR Axles.“ 2.
Page 20
Technical Information Link Assembly - Alloy Sensor Owner’s Manual Supplement Link Assembly - Alloy 2X 7 Nm 2X 5 Nm 10 Nm Connecting the Link To prevent mis-alignment and/or potential Identification damage, follow this assembly order routine: 1. Link 2. Seatstay Connect link to frame.
Page 21
Technical Information Link Assembly - Alloy Identification 1. Carbon link 4. Bearing a. Inner lip 2. Alloy link 5. Bearing b. Ring clip groove 3. Ring clip, carbon only 6. Bearing Inspection • Inspect bearing condition periodically. Bearings wear out with use. Inspect and plan to replace them as part of normal maintenance.
Page 22
Technical Information LockR Axles - Carbon Frames Sensor Owner’s Manual Supplement LockR Axles - Carbon Frames To remove the LockR from the frame: 1. Loosen the screw 4-6 turns using a T25 Torx key. 2. Tap head of screw with a rubber mallet to un-seat the wedge bolt located on the opposite side.
Page 23
Technical Information LockR Axles - Carbon Frames • Do not install assembled. • Clean thoroughly while disassembled. • Re-apply grease as shown. N·m N·m N·m N·m Insert 5mm & Unthread Unthread & dislodge & turn to free Remove tap mallet remove Remove...
Page 24
Technical Information Cabling - Sensor Sensor Owner’s Manual Supplement Cabling - Sensor Identification 1. Rear brake line 2. Rear derailleur line 3. Seat post remote line 4. Downtube cable clamp 5. Bolt 6. Cable tie 7. Grommet 151949 Rev. 0 (09/22)
Page 27
Technical Information ISCG Tab Instructions - Sensor ISCG Tab Instructions - Sensor BB Cup K22059 ISCG Bracket • On alloy frame models, the ISCG mounting tabs are fixed permanently to the frame and cannot be removed. • On carbon frames, the ISCG mount fits onto a spline. Correct positioning is certain due to the alignment of the splines.
Replacement Parts SENSOR - Carbon Frame Sensor Owner’s Manual Supplement REPLACEMENT PARTS The following service and replacement parts are available through an Authorized GT Dealer: SENSOR - Carbon Frame Part Number Description VIEW(S) K36112 Sensor Crb Link/CS/SS/Pivot Bearings K36122 Sensor Crb Link/CS/SS/Pivot Hardware...
Page 31
Replacement Parts SENSOR - Carbon Frame REF# 3 VIEW I Link/Seatstay/Chainstay SRAM P/N : 00.7918.093.000...
Page 32
Replacement Parts SENSOR - Carbon Frame Sensor Owner’s Manual Supplement VIEW 2 Front Triangle 151949 Rev. 0 (09/22)
Page 33
Replacement Parts SENSOR - Alloy Frame The following service and replacement parts are available through an Authorized GT Dealer: SENSOR - Alloy Frame Part Number Description VIEW(S) K36142 Sensor Alloy Link/CS/SS/Pivot Bearings K36152 Sensor Alloy Link/CS/SS/Pivot Hardware K32112 27mm Slide Guides 30mm Bolt Qty6...
Sensor Owner’s Manual Supplement MAINTENANCE Scheduling The following table lists only supplemental maintenance items. Please consult your GT Bicycle Owner’s Manual for more information on basic bike maintenance. Item Frequency Cable Routing - Make sure control cables are in place, Before first ride undamaged and attached securely.
