Digital Control DIGITRAK FALCON F1 User Manual page 51

HAG is not factored into the target depth setting. Elevate the
locator and add that height to the target depth if drilling
shallower than 1.5 ft (46 cm) or if elevating the locator to
distance it from rebar.
STEP 4 OF 8
Hold briefly to change the cursor to a box. Click to scroll through numeric
values. Then hold briefly to set.
Click to move the cursor to the next digit, hold briefly to select, click to
change, and hold again to set.
When the desired target depth number is shown, click to underline the check
mark and then hold to set.
1. Current selection
2. Select to confirm setting when done
If you click past your desired value, wait about five seconds to
exit without saving and try again.
DIGITAL CONTROL, INC
DIGITRAK FALCON F1 USER MANUAL
DCI DigiGuide 05.18.2024
51
