DIGITRAK FALCON F1 USER MANUAL
DCI DigiGuide 05.18.2024
Fore/Aft Offset
For a given pitch, you can calculate actual or projected depth:
IN-GROUND CALIBRATION
This calibration procedure is rarely needed. If you find it necessary to
calibrate with the transmitter in the ground, contact DCI customer service for
information on this option, and perform the procedure with caution.
GET TRANSMITTER INFO
STEP 1 OF 6
From the Main menu, select Settings.
41
DIGITAL CONTROL, INC
