STEP 10 OF 12
Ensure the locator is on the line connecting the two marked locate points.
Position the locator so the LL passes through the center of the box. The drill
head should be beneath this point as long as the transmitter is relatively level
(see Steep and Deep under Advanced Topics).
The locator can face toward or away from the drill as long as it is
parallel to the direction of drilling.
STEP 11 OF 12
Hold the trigger to take a depth reading.
